The GraphicSheet is a working sheet where any set of GraphicObject can be displayed. More...
#include <GraphicSheet.h>
Public Slots | |
| Q_SCRIPTABLE void | addLayers () |
| GraphicObject * | addObject () |
| Q_SCRIPTABLE void | addSelect (GraphicObject *obj) |
| Q_SCRIPTABLE void | addSelectNextChild () |
| Q_SCRIPTABLE void | alignBottom () |
| Q_SCRIPTABLE void | alignHCenter () |
| Q_SCRIPTABLE void | alignLeft () |
| Q_SCRIPTABLE void | alignRight () |
| Q_SCRIPTABLE void | alignTop () |
| Q_SCRIPTABLE void | alignVCenter () |
| Q_SCRIPTABLE void | alignX (double localPosition) |
| Q_SCRIPTABLE void | alignY (double localPosition) |
| Q_SCRIPTABLE void | clear () |
| Q_SCRIPTABLE void | copy () |
| Q_SCRIPTABLE void | copyImage () |
| Q_SCRIPTABLE void | copyMakeUp () |
| Q_SCRIPTABLE void | cut () |
| virtual Q_SCRIPTABLE void | deepUpdate () |
| Q_SCRIPTABLE void | exportFile (QString fileName=QString::null, QString fileFormat=QString::null, int dpi=0) |
| Q_SCRIPTABLE void | exportImage (QString fileName=QString::null, QString imageFormat=QString::null, int dpi=0) |
| Q_SCRIPTABLE void | fileNew () |
| Q_SCRIPTABLE void | fileOpen () |
| Q_SCRIPTABLE void | fileOpen (QString fileName, double dx=0, double dy=0) |
| Q_SCRIPTABLE void | fileSave () |
| Q_SCRIPTABLE void | fileSave (QString fileName) |
| Q_SCRIPTABLE void | fileSaveAs () |
| Q_SCRIPTABLE QPixmap | image (int dpi=0) |
| Q_SCRIPTABLE void | lowerSelection () |
| void | moveObject (GraphicObject *obj=0) |
| Q_SCRIPTABLE GraphicObject * | object (QString objectName) |
| Q_SCRIPTABLE GraphicObject * | object (int index) |
| Q_SCRIPTABLE void | paste () |
| Q_SCRIPTABLE void | pasteMakeUp () |
| Q_SCRIPTABLE void | print (int dpi=0) |
| Q_SCRIPTABLE void | print (bool outputToFile, QString name, int dpi) |
| Q_SCRIPTABLE void | raiseSelection () |
| Q_SCRIPTABLE void | redo () |
| Q_SCRIPTABLE bool | removeObject (GraphicObject *obj) |
| void | resizeObject () |
| Q_SCRIPTABLE void | restoreMakeUp (QString fileName=QString::null) |
| Q_SCRIPTABLE void | saveLayers (QString fileName=QString::null) |
| Q_SCRIPTABLE void | saveMakeUp (QString fileName=QString::null) |
| Q_SCRIPTABLE void | select (GraphicObject *obj) |
| Q_SCRIPTABLE void | selectAll () |
| Q_SCRIPTABLE bool | selectAll (QString actionTitle) |
| Q_SCRIPTABLE void | selectNextChild () |
| Q_SCRIPTABLE void | selectObjects (GraphicObject *obj, Qt::KeyboardModifiers m=Qt::NoModifier) |
| Q_SCRIPTABLE void | setPreferences () |
| Q_SCRIPTABLE void | showOrderIndex (bool isOn) |
| Q_SCRIPTABLE void | showProperties () |
| void | startDragging () |
| Q_SCRIPTABLE void | undo () |
| Q_SCRIPTABLE void | unSelectAll () |
| virtual Q_SCRIPTABLE void | update () |
| void | updatePageLimits (QPrinter &p) |
Signals | |
| void | activeSelectionChanged (GraphicObject *obj) |
| void | currentFileChanged (const QString &fileName) |
Public Member Functions | |
| GraphicObject * | activeObject (const char *inherits=0) |
| void | addEditActions (QMenu *m, QToolBar *tb, bool shortcuts=true) |
| void | addFileActions (QMenu *m, QToolBar *tb, bool shortcuts=true) |
| void | addFormatActions (QMenu *m, bool shortcuts=true) |
| void | addInsertActions (QMenu *m, QToolBar *tb, bool shortcuts=true) |
| void | addMenu (QMenu *m) |
| void | addObject (GraphicObject *obj) |
| void | addProperties (PropertyProxy *pp) |
| SelectionWidget * | addSelection (GraphicObject *obj) |
| void | autoResizeContent () |
| void | clear (bool force) |
| Point2D | currentOrigin () |
| GraphicObject * | findObject (QString tag, QString name) |
| GraphicSheet (QWidget *parent=0) | |
| bool | isOrderIndex () const |
| int | maximumResolution () |
| virtual QSize | minimumSizeHind () const |
| int | objectCount () |
| QString | objectList () const |
| int | paletteCount () |
| void | print (QPrinter &printer) |
| double | printBottom () |
| double | printRight () |
| virtual void | properties (PropertyWidget *w) const |
| bool | removeObject (GraphicObject *obj, bool force) |
| void | removeProperties (PropertyProxy *pp) |
| template<typename T > | |
| QList< T > | selectedObjects () const |
| void | setObjectList (QString list) |
| void | setObjectOrder (QString list) |
| void | setOrderIndex (GraphicObject *obj) |
| virtual void | setProperty (uint wid, int pid, QVariant val) |
| void | setStatusBar (QStatusBar *s) |
| void | setTransparency (int val) |
| void | setTransparentMask (bool val) |
| void | showAllObjects () |
| void | showObject (GraphicObject *obj) |
| QStatusBar * | statusBar () |
| int | transparency () const |
| bool | transparentMask () const |
| QString | uniqueName (GraphicObject *obj, QString newName) |
| virtual const QString & | xml_tagName () const |
| ~GraphicSheet () | |
Static Public Attributes | |
| static const QString | xmlGraphicSheetTag = "GraphicSheet" |
Protected Member Functions | |
| void | addActions () |
| virtual void | mousePressEvent (QMouseEvent *e) |
| virtual void | mouseReleaseEvent (QMouseEvent *e) |
| virtual XMLMember | xml_member (XML_MEMBER_ARGS) |
| virtual void | xml_polish (XML_POLISH_ARGS) |
| virtual void | xml_polishChild (XML_POLISHCHILD_ARGS) |
| virtual bool | xml_setProperty (XML_SETPROPERTY_ARGS) |
| virtual void | xml_writeChildren (XML_WRITECHILDREN_ARGS) const |
Properties | |
| DUMMY_PROPERTIES | |
| QString | name |
| int | objectCount |
| QString | objectList |
| QString | objectName |
| QString | objectOrder |
| bool | orderIndex |
| int | transparency |
| bool | transparentMask |
The GraphicSheet is a working sheet where any set of GraphicObject can be displayed.
| SciFigs::GraphicSheet::GraphicSheet | ( | QWidget * | parent = 0 | ) |
References addActions(), addSelectNextChild(), selectNextChild(), QGpGuiTools::setWidgetColor(), and TRACE.
:
QScrollArea(parent)
{
TRACE;
setAttribute(Qt::WA_OpaquePaintEvent);
setWidgetColor(viewport(), Qt::white);
setWidget(new QWidget(this));
_statusBar=0;
_currentActiveSelection=0;
new QShortcut(Qt::Key_Tab, this, SLOT(selectNextChild()));
new QShortcut(Qt::Key_Tab + Qt::SHIFT, this, SLOT(addSelectNextChild()));
_orderIndex=-1;
_transparency=255;
_transparentMask=false;
setSizePolicy(QSizePolicy::Expanding, QSizePolicy::Expanding);
_dragDelay.setSingleShot(true);
_dragDelay.setInterval(50);
connect(&_dragDelay, SIGNAL(timeout()), this, SLOT(dragObjectsDelayed()));
addActions();
}
References QGpGuiTools::PropertyContext::proxy(), removeProperties(), QGpGuiTools::PropertyProxy::saveStates(), selectObjects(), and TRACE.
{
TRACE;
if(proxy()) {
proxy()->saveStates();
selectObjects(0);
removeProperties(proxy());
}
}
| GraphicObject * SciFigs::GraphicSheet::activeObject | ( | const char * | className = 0 | ) |
Used only by GraphContent::zoom, GraphContent::unzoom and GraphicObject::keyPopupMenu() These functions are not used in general. Some general code review may eventuelly remove this function.
References TRACE, and SciFigs::SelectionWidget::widget().
Referenced by SciFigs::GraphicObject::activeObject().
| void SciFigs::GraphicSheet::activeSelectionChanged | ( | GraphicObject * | obj | ) | [signal] |
Referenced by selectObjects().
| void SciFigs::GraphicSheet::addActions | ( | ) | [protected] |
Initialize context menu
References showProperties(), QGpCoreTools::tr(), and TRACE.
Referenced by GraphicSheet().
{
TRACE;
QAction * a;
a=new QAction(tr("&Properties"), this);
a->setObjectName("Properties");
a->setToolTip(tr("Set properties of object"));
connect(a, SIGNAL(triggered(bool)) , this, SLOT(showProperties()));
QWidget::addAction(a);
}
| void SciFigs::GraphicSheet::addEditActions | ( | QMenu * | m, |
| QToolBar * | tb, | ||
| bool | shortcuts = true |
||
| ) |
References copy(), copyImage(), cut(), paste(), selectAll(), showOrderIndex(), QGpCoreTools::tr(), and TRACE.
Referenced by SciFigs::GraphicSheetMenu::addActions(), and DinverDCGui::DCModelViewer::addActions().
{
TRACE;
QAction * a;
/*a=new QAction(QIcon(":/images/editundo.png"), tr("&Undo"), this);
if(shortcuts) {
a->setShortcut(tr("Ctrl+Z"));
}
a->setStatusTip(tr("Undo last operation"));
connect(a, SIGNAL(triggered()), this, SLOT(undo()));
if(m)
m->addAction(a);
if(tb)
tb->addAction(a);
a=new QAction(QIcon(":/images/editredo.png"), tr("Re&do"), this);
if(shortcuts) {
a->setShortcut(tr("Ctrl+Shift+Z"));
}
a->setStatusTip(tr("Redo last operation"));
connect(a, SIGNAL(triggered()), this, SLOT(redo()));
if(m)
m->addAction(a);
if(tb)
tb->addAction(a);
if(m)
m->addSeparator();
if(tb)
tb->addSeparator();*/
a=new QAction(QIcon(":/images/editcut.png"), tr("Cu&t"), this);
if(shortcuts) {
a->setShortcut(tr("Ctrl+X"));
}
a->setStatusTip(tr("Cut the current selection's contents to the "
"clipboard"));
connect(a, SIGNAL(triggered()), this, SLOT(cut()));
if(m)
m->addAction(a);
if(tb)
tb->addAction(a);
a=new QAction(QIcon(":/images/editcopy.png"), tr("&Copy"), this);
if(shortcuts) {
a->setShortcut(tr("Ctrl+C"));
}
a->setStatusTip(tr("Copy the current selection's contents to the "
"clipboard"));
connect(a, SIGNAL(triggered()), this, SLOT(copy()));
if(m)
m->addAction(a);
if(tb)
tb->addAction(a);
a=new QAction(tr("Copy &image"), this);
if(shortcuts) {
a->setStatusTip(tr("Copy the sheet as an image to the clipboard"));
}
connect(a, SIGNAL(triggered()), this, SLOT(copyImage()));
if(m)
m->addAction(a);
a=new QAction(QIcon(":/images/editpaste.png"), tr("&Paste"), this);
if(shortcuts) {
a->setShortcut(tr("Ctrl+V"));
}
a->setStatusTip(tr("Paste the clipboard's contents in the sheet"));
connect(a, SIGNAL(triggered()), this, SLOT(paste()));
if(m)
m->addAction(a);
if(tb)
tb->addAction(a);
if(m)
m->addSeparator();
if(tb)
tb->addSeparator();
a=new QAction(tr("&Select all"), this);
if(shortcuts) {
a->setShortcut(tr("Ctrl+A"));
}
a->setStatusTip(tr("Select all object of the sheet"));
connect(a, SIGNAL(triggered()), this, SLOT(selectAll()));
if(m)
m->addAction(a);
a=new QAction(QIcon(":/images/ordertool.png"), tr("&Order"), this);
if(shortcuts) {
a->setShortcut(tr("Ctrl+O"));
}
a->setStatusTip(tr("Order objects of the sheet"));
a->setCheckable(true);
connect(a, SIGNAL(toggled(bool)), this, SLOT(showOrderIndex(bool)));
if(m)
m->addAction(a);
if(tb)
tb->addAction(a);
}
| void SciFigs::GraphicSheet::addFileActions | ( | QMenu * | m, |
| QToolBar * | tb, | ||
| bool | shortcuts = true |
||
| ) |
References exportImage(), fileNew(), fileOpen(), fileSave(), fileSaveAs(), print(), setPreferences(), QGpCoreTools::tr(), and TRACE.
Referenced by SciFigs::GraphicSheetMenu::addActions(), and DinverDCGui::DCModelViewer::addActions().
{
TRACE;
QAction * a;
a=new QAction(QIcon(":/images/filenew.png"), tr("&New"), this);
if(shortcuts) {
a->setShortcut(tr("Ctrl+N"));
}
a->setStatusTip(tr("Empty sheet"));
connect(a, SIGNAL(triggered()), this, SLOT(fileNew()));
if(m)
m->addAction(a);
if(tb)
tb->addAction(a);
a=new QAction(QIcon(":/images/fileopen.png"), tr("&Open"), this);
if(shortcuts) {
a->setShortcut(tr("Ctrl+O"));
}
a->setStatusTip(tr("Open an existing sheet and add it to the current one (*.page files)"));
connect(a, SIGNAL(triggered()), this, SLOT(fileOpen()));
if(m)
m->addAction(a);
if(tb)
tb->addAction(a);
a=new QAction(QIcon(":/images/filesave.png"), tr("&Save"), this);
if(shortcuts) {
a->setShortcut(tr("Ctrl+S"));
}
a->setStatusTip(tr("Save sheet to disk"));
connect(a, SIGNAL(triggered()), this, SLOT(fileSave()));
if(m)
m->addAction(a);
if(tb)
tb->addAction(a);
a=new QAction(tr("Save &As..."), this);
a->setStatusTip(tr("Save sheet to disk under a new name"));
connect(a, SIGNAL(triggered()), this, SLOT(fileSaveAs()));
if(m)
m->addAction(a);
if(m)
m->addSeparator();
a=new QAction(tr("&Preferences"), this);
a->setStatusTip(tr("Customize SciFigs"));
connect(a, SIGNAL(triggered()), this, SLOT(setPreferences()));
m->addAction(a);
if(m)
m->addSeparator();
a=new QAction(QIcon(":/images/fileprint.png"), tr("&Print"), this);
if(shortcuts) {
a->setShortcut(tr("Ctrl+P"));
}
a->setStatusTip(tr("Print sheet"));
connect(a, SIGNAL(triggered()), this, SLOT(print()));
if(m)
m->addAction(a);
if(tb)
tb->addAction(a);
a=new QAction(tr("&Export image"), this);
if(shortcuts) {
a->setShortcut(tr("Ctrl+E"));
}
a->setStatusTip(tr("Export sheet as image"));
connect(a, SIGNAL(triggered()), this, SLOT(exportImage()));
if(m)
m->addAction(a);
if(m)
m->addSeparator();
}
| void SciFigs::GraphicSheet::addFormatActions | ( | QMenu * | m, |
| bool | shortcuts = true |
||
| ) |
References addLayers(), copyMakeUp(), pasteMakeUp(), restoreMakeUp(), saveLayers(), saveMakeUp(), showProperties(), QGpCoreTools::tr(), and TRACE.
Referenced by SciFigs::GraphicSheetMenu::addActions(), and DinverDCGui::DCModelViewer::addActions().
{
TRACE;
QAction * a;
a=new QAction(tr("&Copy make-up"), this);
a->setStatusTip(tr("Copy the sheet format to the clipboard"));
connect(a, SIGNAL(triggered()), this, SLOT(copyMakeUp()));
if(m)
m->addAction(a);
a=new QAction(tr("&Paste make-up"), this);
a->setStatusTip(tr("Set the sheet format from the clipboard"));
connect(a, SIGNAL(triggered()), this, SLOT(pasteMakeUp()));
if(m)
m->addAction(a);
a=new QAction(tr("&Save make-up"), this);
if(shortcuts) {
a->setShortcut(tr("Ctrl+U"));
}
connect(a, SIGNAL(triggered()), this, SLOT(saveMakeUp()));
if(m)
m->addAction(a);
a=new QAction(tr("&Restore make-up"), this);
if(shortcuts) {
a->setShortcut(tr("Ctrl+Y"));
}
connect(a, SIGNAL(triggered()), this, SLOT(restoreMakeUp()));
if(m)
m->addAction(a);
if(m) m->addSeparator();
a=new QAction(tr("&Save layers"), this);
a->setToolTip(tr("Save all layers of selected plots in multiple .layer files"));
connect(a, SIGNAL(triggered(bool)) , this, SLOT(saveLayers()));
if(m)
m->addAction(a);
a=new QAction(tr("&Add layers"), this);
a->setToolTip(tr("Add layers to the selected plots from multiple .layer files"));
connect(a, SIGNAL(triggered(bool)) , this, SLOT(addLayers()));
if(m)
m->addAction(a);
if(m) m->addSeparator();
a=new QAction(tr("&Properties"), this);
connect(a, SIGNAL(triggered()), this, SLOT(showProperties()));
if(m)
m->addAction(a);
}
| void SciFigs::GraphicSheet::addInsertActions | ( | QMenu * | m, |
| QToolBar * | tb, | ||
| bool | shortcuts = true |
||
| ) |
References addObject(), SciFigs::GraphicObjectFactory::creator(), SciFigs::GraphicObjectCreator::icon(), SciFigs::GraphicObjectFactory::instance(), SciFigs::GraphicObjectCreator::menuTitle(), QGpCoreTools::XMLClassFactory::registeredTags(), SciFigs::GraphicObjectCreator::shortcut(), SciFigs::GraphicObjectCreator::tagName(), SciFigs::GraphicObjectCreator::toolTip(), and TRACE.
Referenced by SciFigs::GraphicSheetMenu::addActions(), and DinverDCGui::DCModelViewer::addActions().
{
TRACE;
QAction * a;
// Automatic detection of available GraphicObject's
QStringList tagList=GraphicObjectFactory::instance()->registeredTags();
QString tag;
foreach(tag, tagList) {
GraphicObjectCreator * c=GraphicObjectFactory::instance()->creator(tag);
a=new QAction(c->icon(), c->menuTitle(), this);
if(shortcuts) {
a->setShortcut(c->shortcut());
}
a->setStatusTip(c->toolTip());
a->setData(c->tagName());
connect(a, SIGNAL(triggered()), this, SLOT(addObject()));
if(m)
m->addAction(a);
if(tb)
tb->addAction(a);
}
}
| void SciFigs::GraphicSheet::addLayers | ( | ) | [slot] |
Add layers to selected axiswindows
References MSG_ID, selectAll(), QGpCoreTools::tr(), and TRACE.
Referenced by addFormatActions().
{
TRACE;
QList<AxisWindow *> objectList=selectedObjects<AxisWindow *>();
if(objectList.isEmpty()) {
if(!selectAll(tr("Add layers"))) return;
objectList=selectedObjects<AxisWindow *>();
}
QStringList fileNames;
fileNames=Message::getOpenFileNames(tr("Add layers"),
tr("Graph layers (*.layer)"));
if(!fileNames.isEmpty()) {
int n=objectList.count();
if(fileNames.count()!=n) {
if(Message::warning(MSG_ID, tr("Add layers"), tr("The number of selected graphs (%1) is not the same as the number "
"of files (%2). Do you want to continue?").arg(n).arg(fileNames.count()),
Message::yes(), Message::no())==Message::Answer1) return;
if(n>fileNames.count()) n=fileNames.count();
}
qSort(fileNames);
for(int i=0; i<n; i++) {
objectList.at(i)->graphContent()->addLayers(fileNames.at(i));
}
}
}
| void SciFigs::GraphicSheet::addMenu | ( | QMenu * | m | ) |
Populate context menu with submenus
This is mainly used by GraphicSheetMenu to copy the contextual menu bar to the context menu. Under Mac OS X, the contextual menu bar is not allowed, and Mac users have no access to the sheet actions. It gives the user an interface like in GIMP for Linux and Windows.
References TRACE.
Referenced by SciFigs::GraphicSheetMenu::addActions(), SciFigs::GraphicSheetMenu::addMenu(), and DinverDCGui::DCModelViewer::addMenu().
{
TRACE;
QAction * a;
if(actions().count()==1) {
a=new QAction(this);
a->setSeparator(true);
QWidget::addAction(a);
}
a=new QAction(m->title(), this);
a -> setMenu(m);
QWidget::addAction(a);
}
| void SciFigs::GraphicSheet::addObject | ( | GraphicObject * | obj | ) |
Add object obj and show it. No need to call showObject().
References SciFigs::GraphicObject::objectName, selectObjects(), SciFigs::GraphicObject::setObjectName(), showObject(), and TRACE.
Referenced by SciFigs::GraphicSheetMenu::addGraph(), PSViewer::addPlot(), addPlot(), SciFigs::GraphicSheetMenu::addText(), DinverDCGui::DCModelViewer::addText(), MonoStation::AbstractSummary::createBubbleGraph(), ResultsThread::createLegend(), TFAResults::createObjects(), ArrayGui::ArrayResponse::createObjects(), MonoStation::AbstractSummary::createSpectrumGridGraph(), createText(), DinverDCGui::DCModelViewer::DCModelViewer(), DinverDCGui::DCModelViewer::initGraphs(), Seismic1DThread::initModelGraphs(), MagnetoTelluricThread::initModelGraphs(), CurvesThread::initResultsGraphs(), MagnetoTelluricThread::initResultsGraphs(), DispersionGridThread::initResultsGraphs(), PSViewer::PSViewer(), HVRotateWinResults::setStations(), and SpectrumRotateWinResults::setStations().
{
TRACE;
if(obj) {
connect(obj, SIGNAL(wantToBeSelected(GraphicObject*, Qt::KeyboardModifiers)),
this, SLOT(selectObjects(GraphicObject*, Qt::KeyboardModifiers)));
obj->_sheet=this;
if(obj->objectName().isEmpty()) obj->setObjectName("object");
showObject(obj);
}
}
| GraphicObject * SciFigs::GraphicSheet::addObject | ( | ) | [slot] |
This slot create and add an object according to the sender. It must be a QAction and the data must contain a pointer to a GraphicObjectCreator structure.
References autoResizeContent(), SciFigs::GraphicObjectFactory::create(), currentOrigin(), SciFigs::GraphicObjectFactory::instance(), SciFigs::GraphicObject::setPrintAnchor(), SciFigs::GraphicObject::setRemovable(), and TRACE.
Referenced by addInsertActions(), and xml_member().
{
TRACE;
QAction * a=qobject_cast<QAction *>(sender());
if(!a || a->data().type()!=QVariant::String) return 0;
GraphicObject * obj=GraphicObjectFactory::instance()->create(a->data().toString());
if(!obj) {
qWarning("Unkwown class name %s", a->data().toString().toAscii().data());
return 0;
}
obj->setPrintAnchor(currentOrigin() + Point2D(1.0, 1.0));
obj->setRemovable(true);
addObject(obj);
autoResizeContent();
return obj;
}
| void SciFigs::GraphicSheet::addProperties | ( | PropertyProxy * | pp | ) |
References QGpGuiTools::PropertyProxy::addCategory(), QGpGuiTools::PropertyProxy::addReference(), QGpGuiTools::PropertyProxy::addTab(), QGpGuiTools::PropertyProxy::setCurrentCategory(), QGpGuiTools::PropertyProxy::setCurrentTab(), QGpCoreTools::tr(), TRACE, and w.
Referenced by showProperties().
{
TRACE;
if(!pp->setCurrentCategory(_category)) {
pp->addCategory(_category, tr("Sheet"), QIcon(":/images/graphicsheet.png"));
}
if(pp->setCurrentTab(_tabPrint)) {
pp->addReference(this);
} else {
GraphicSheetProperties * w=new GraphicSheetProperties;
pp->addTab(_tabPrint, tr("Print"), w, this);
}
}
| Q_SCRIPTABLE void SciFigs::GraphicSheet::addSelect | ( | GraphicObject * | obj | ) | [inline, slot] |
{selectObjects(obj, Qt::ShiftModifier);}
References SciFigs::SelectionWidget::height(), TRACE, SciFigs::SelectionWidget::width(), SciFigs::SelectionWidget::x(), and SciFigs::SelectionWidget::y().
Referenced by SciFigs::GraphicObject::enterEvent(), and selectObjects().
{
TRACE;
SelectionWidget * selObj=new SelectionWidget(obj, this);
selObj->setParent(widget());
selObj->move(selObj->x(obj->x()), selObj->y(obj->y()));
selObj->resize(selObj->width(), selObj->height());
selObj->stackUnder(obj);
return selObj;
}
| void SciFigs::GraphicSheet::addSelectNextChild | ( | ) | [slot] |
Select next child (in the stack order, just after the current object). Compared to selectNextChild(), the current object remains selected. This function is called after a SHIFT+TAB action.
References selectObjects(), TRACE, and SciFigs::SelectionWidget::widget().
Referenced by GraphicSheet().
{
TRACE;
QList<GraphicObject *> objectList=graphicObjects();
if(objectList.isEmpty()) return;
GraphicObject * cur;
if(_currentActiveSelection)
cur=_currentActiveSelection->widget();
else
cur=0;
QList<GraphicObject *>::iterator it;
for(it=objectList.begin(); it!=objectList.end(); ++it) {
if(*it==cur) {++it;break;}
}
if(it!=objectList.end()) {
selectObjects(*it, Qt::ShiftModifier);
} else {
selectObjects(objectList.first(), Qt::ShiftModifier);
}
}
| Q_SCRIPTABLE void SciFigs::GraphicSheet::alignBottom | ( | ) | [inline, slot] |
{alignY(1.0);}
| Q_SCRIPTABLE void SciFigs::GraphicSheet::alignHCenter | ( | ) | [inline, slot] |
{alignX(0.5);}
| Q_SCRIPTABLE void SciFigs::GraphicSheet::alignLeft | ( | ) | [inline, slot] |
{alignX(0.0);}
| Q_SCRIPTABLE void SciFigs::GraphicSheet::alignRight | ( | ) | [inline, slot] |
{alignX(1.0);}
| Q_SCRIPTABLE void SciFigs::GraphicSheet::alignTop | ( | ) | [inline, slot] |
{alignY(0.0);}
| Q_SCRIPTABLE void SciFigs::GraphicSheet::alignVCenter | ( | ) | [inline, slot] |
{alignY(0.5);}
| void SciFigs::GraphicSheet::alignX | ( | double | localPosition | ) | [slot] |
Align two objects with repect to a relative position along X axis
localPosition should be between 0 (left) and 1 (right)
References moveObject(), SciFigs::GraphicObject::printLeft(), SciFigs::GraphicObject::printWidth, SciFigs::GraphicObject::setPrintXAnchor(), TRACE, and SciFigs::SelectionWidget::widget().
{
TRACE;
if(!_currentActiveSelection)
return ;
GraphicObject * obj=_currentActiveSelection->widget();
double refPos=obj->printLeft() + localPosition * obj->printWidth();
QList<GraphicObject *> objectList=selectedObjects<GraphicObject *>();
foreach(obj, objectList) {
obj->setPrintXAnchor(refPos - localPosition * obj->printWidth());
moveObject(obj);
}
}
| void SciFigs::GraphicSheet::alignY | ( | double | localPosition | ) | [slot] |
Align two objects with repect to a relative position along Y axis
localPosition should be between 0 (bottom) and 1 (top)
References moveObject(), SciFigs::GraphicObject::printHeight, SciFigs::GraphicObject::printTop(), SciFigs::GraphicObject::setPrintYAnchor(), TRACE, and SciFigs::SelectionWidget::widget().
{
TRACE;
if(!_currentActiveSelection)
return ;
GraphicObject * obj=_currentActiveSelection->widget();
double refPos=obj->printTop() + localPosition * obj->printHeight();
QList<GraphicObject *> objectList=selectedObjects<GraphicObject *>();
foreach(obj, objectList) {
obj->setPrintYAnchor(refPos - localPosition * obj->printHeight());
moveObject(obj);
}
}
References objectList(), SciFigs::GraphicObject::printBottomMargin, SciFigs::GraphicObject::printRightMargin, SciFigs::SciFigsGlobal::screenResolution(), and TRACE.
Referenced by addObject(), createBands(), createCircles(), createManyCurves(), DinverDCGui::DCModelViewer::initGraphs(), CurvesThread::initResultsGraphs(), MagnetoTelluricThread::initResultsGraphs(), DispersionGridThread::initResultsGraphs(), moveObject(), removeObject(), resizeObject(), and xml_polish().
{
TRACE;
// greatest right-bottom coordinates of child graphs;
// iterate on all graphs
QList<GraphicObject *> objectList=graphicObjects();
int maxRight=-(int) RAND_MAX, maxBottom=-(int) RAND_MAX;
GraphicObject * obj;
foreach(obj, objectList) {
int right=obj->x() + obj->width() + (int) (obj->printRightMargin() * SciFigsGlobal::screenResolution());
int bottom=obj->y() + obj->height() + (int) (obj->printBottomMargin() * SciFigsGlobal::screenResolution());
if(right > maxRight)
maxRight=right;
if(bottom > maxBottom)
maxBottom=bottom;
}
if(maxRight > 0)
widget() ->resize(maxRight, maxBottom);
}
| void SciFigs::GraphicSheet::clear | ( | bool | force | ) |
Remove all objects of the sheet.
If force is true, remove all objects even those not removable (default value is true).
References MSG_ID, removeObject(), QGpCoreTools::tr(), and TRACE.
Referenced by AutocorrTargetWidget::clear().
{
TRACE;
QList<GraphicObject *> wList=graphicObjects();
int nRemoved=wList.count();
for(QList<GraphicObject *>::iterator it=wList.begin();it!=wList.end();++it) {
if(removeObject(*it, force))
nRemoved--;
}
switch(nRemoved) {
case 0:
break;
case 1:
Message::warning(MSG_ID, tr("Clearing sheet"), tr("1 object is not removable"), Message::ok());
break;
default:
Message::warning(MSG_ID, tr("Clearing sheet"), tr("%1 objects are not removable").arg(nRemoved), Message::ok());
}
}
| Q_SCRIPTABLE void SciFigs::GraphicSheet::clear | ( | ) | [inline, slot] |
| void SciFigs::GraphicSheet::copy | ( | ) | [slot] |
References SciFigs::XMLSciFigs::Page, SciFigs::XMLSciFigs::saveByteArray(), SciFigs::XMLSciFigs::Selection, and TRACE.
Referenced by addEditActions(), and cut().
{
TRACE;
QClipboard * cb=QApplication::clipboard();
XMLSciFigs s;
QByteArray selObjects=s.saveByteArray(this, XMLSciFigs::Page | XMLSciFigs::Selection);
QMimeData * mime=new QMimeData;
mime->setData("XMLSciFigs::Page", selObjects);
cb->setMimeData(mime, QClipboard::Clipboard);
}
| void SciFigs::GraphicSheet::copyImage | ( | ) | [slot] |
References image(), and TRACE.
Referenced by addEditActions().
| void SciFigs::GraphicSheet::copyMakeUp | ( | ) | [slot] |
Copy all properties of the sheet and included objects to the clipboard
References SciFigs::XMLSciFigs::MakeUp, SciFigs::MakeUpFilter::saveByteArray(), SciFigs::XMLSciFigs::saveString(), SciFigs::MakeUpFilter::setXml(), and TRACE.
Referenced by addFormatActions().
{
TRACE;
XMLSciFigs s;
MakeUpFilter * d=new MakeUpFilter(this);
d->setXml(s.saveString(this, XMLSciFigs::MakeUp));
if(d->exec()==QDialog::Accepted) {
QClipboard * cb=QApplication::clipboard();
QMimeData * mime=new QMimeData;
mime->setData("XMLSciFigs::SheetMakeUp", d->saveByteArray());
cb->setMimeData(mime, QClipboard::Clipboard);
}
delete d;
}
| void SciFigs::GraphicSheet::currentFileChanged | ( | const QString & | fileName | ) | [signal] |
Referenced by fileNew(), fileOpen(), fileSave(), and fileSaveAs().
Returns the coordinates of the current top left visible corner Used for example in Makepage to insert new objects at the top of the visible part and not at the top of the sheet.
References SciFigs::SciFigsGlobal::screenResolution(), QGpCoreTools::Point2D::setX(), QGpCoreTools::Point2D::setY(), and TRACE.
Referenced by addObject(), PSViewer::addPlot(), and paste().
{
TRACE;
Point2D o;
if(widget() ->width() > 0) {
o.setX(-widget() ->x()/SciFigsGlobal::screenResolution());
o.setY(-widget() ->y()/SciFigsGlobal::screenResolution());
} else {
o.setX(0);
o.setY(0);
}
return o;
}
| void SciFigs::GraphicSheet::cut | ( | ) | [slot] |
References copy(), SciFigs::GraphicObject::deleteObject(), TRACE, and SciFigs::SelectionWidget::widget().
Referenced by addEditActions().
{
TRACE;
copy();
if(_currentActiveSelection) {
_currentActiveSelection->widget()->deleteObject();
}
}
| void SciFigs::GraphicSheet::deepUpdate | ( | ) | [virtual, slot] |
Redraw all parts of all objects if autoDeepUpdate() is switched on, else do a normal update.
References SciFigs::GraphicObject::deepUpdate(), SciFigs::GraphicObject::selectionWidget(), and TRACE.
Referenced by DinverDCGui::DCModelViewer::loadModels(), pasteMakeUp(), DinverDCGui::DCModelViewer::setLimits(), PSViewer::setLimits(), MonoStation::AbstractSummary::setStations(), and PSViewer::synchronize().
{
TRACE;
QList<GraphicObject *> objectList=graphicObjects();
GraphicObject * obj;
foreach(obj, objectList) {
obj->deepUpdate();
if(obj->selectionWidget())
obj->selectionWidget() ->update();
}
}
| void SciFigs::GraphicSheet::exportFile | ( | QString | fileName = QString::null, |
| QString | fileFormat = QString::null, |
||
| int | dpi = 0 |
||
| ) | [slot] |
Export all objects of the sheet to a file, fileFormat may be any of the format accepted by QImage, PS, PDF, PAGE or LAYER.
If dpi is different from 0, it override the resolution specified in object properties.
References exportImage(), fileSave(), saveLayers(), selectAll(), and TRACE.
Referenced by main().
{
TRACE;
if(fileFormat.toLower()=="page") {
fileSave(fileName);
} else if(fileFormat.toLower()=="layer") {
selectAll();
saveLayers(fileName);
} else {
exportImage(fileName, fileFormat.toAscii().data(), dpi);
}
}
| void SciFigs::GraphicSheet::exportImage | ( | QString | fileName = QString::null, |
| QString | imageFormat = QString::null, |
||
| int | dpi = 0 |
||
| ) | [slot] |
Export all objects of the sheet to an image file, imageFormat may be any of the format accepted by QImage. Additionally, the 'PS' and 'PDF' are accepted.
If dpi is different from 0, it override the resolution specified in object properties.
References SciFigs::GraphicObject::allImageFilter, image(), maximumResolution(), MSG_ID, print(), DinverCore::qHash(), QGpCoreTools::tr(), and TRACE.
Referenced by addFileActions(), and exportFile().
{
TRACE;
if(fileName.isEmpty()) {
fileName=Message::getSaveFileName(tr("Export image as ..."), GraphicObject::allImageFilter);
}
if(!fileName.isEmpty()) {
if(imageFormat.isEmpty()) {
imageFormat=Settings::getFilter("filter-" + QString::number(qHash(GraphicObject::allImageFilter))).
section(' ', 0, 0);
}
if(imageFormat =="PS" || imageFormat =="PDF") {
QPrinter printer(QPrinter::HighResolution);
if(dpi==0)
printer.setResolution((int) maximumResolution());
else
printer.setResolution(dpi);
printer.setFullPage(true);
printer.setOutputFileName(fileName);
printer.setOutputFormat(imageFormat =="PDF" ? QPrinter::PdfFormat : QPrinter::PostScriptFormat);
QApplication::processEvents(QEventLoop::ExcludeUserInputEvents);
print(printer);
} else if(imageFormat =="SVG") {
printSvg(fileName, dpi);
} else { // Pixel based image format
QPixmap pixmap=image(dpi);
if(!pixmap.isNull()) {
// Save pixmap to disk
if(!pixmap.save(fileName, imageFormat.toAscii().data())) {
Message::warning(MSG_ID, tr("Exporting as image"), tr("Failed to export image to file %1 with format %2")
.arg(fileName).arg(imageFormat.toAscii().data()));
}
}
}
}
}
| void SciFigs::GraphicSheet::fileNew | ( | ) | [slot] |
References clear(), currentFileChanged(), and TRACE.
Referenced by addFileActions().
{
TRACE;
clear(false);
_currentFile="";
emit currentFileChanged(_currentFile);
}
| void SciFigs::GraphicSheet::fileOpen | ( | ) | [slot] |
References QGpCoreTools::tr(), and TRACE.
Referenced by addFileActions(), PSViewer::fileOpenPS(), and main().
| void SciFigs::GraphicSheet::fileOpen | ( | QString | fileName, |
| double | dx = 0, |
||
| double | dy = 0 |
||
| ) | [slot] |
Load the .page file with a shift of dx and dy (in cm)
References currentFileChanged(), QGpCoreTools::XMLErrorReport::exec(), fileName, moveObject(), SciFigs::XMLSciFigs::Page, SciFigs::GraphicObject::printXAnchor(), SciFigs::GraphicObject::printYAnchor(), SciFigs::XMLSciFigs::restoreFile(), QGpCoreTools::XMLErrorReport::setFileName(), SciFigs::GraphicObject::setPrintXAnchor(), SciFigs::GraphicObject::setPrintYAnchor(), QGpCoreTools::XMLErrorReport::setTitle(), QGpCoreTools::tr(), and TRACE.
{
TRACE;
if(fileName.length() > 0) {
QFileInfo fi(fileName);
fileName=fi.absoluteFilePath();
if(_statusBar)
_statusBar->showMessage(tr("Loading file ..."));
_loadedObjects.clear();
XMLSciFigs s;
XMLErrorReport xmler(XMLErrorReport::Read);
xmler.setTitle(tr("Open page file"));
xmler.setFileName(fileName);
if(xmler.exec(s.restoreFile(fileName, this, XMLSciFigs::Page))) {
// Move all loaded object by dx and dy
if(dx!=0 || dy!=0) {
GraphicObject * obj;
foreach (obj, _loadedObjects) {
obj->setPrintXAnchor(obj->printXAnchor() + dx);
obj->setPrintYAnchor(obj->printYAnchor() + dy);
moveObject(obj);
}
}
_loadedObjects.clear();
if(_currentFile.isEmpty()) {
_currentFile=fileName;
emit currentFileChanged(_currentFile);
}
}
if(_statusBar) {
_statusBar->showMessage(tr("Loading finished"));
}
}
}
| void SciFigs::GraphicSheet::fileSave | ( | ) | [slot] |
References fileSaveAs(), SciFigs::XMLSciFigs::Page, SciFigs::XMLSciFigs::saveFile(), and TRACE.
Referenced by addFileActions(), exportFile(), fileSave(), fileSaveAs(), and PSViewer::fileSavePS().
{
TRACE;
if(_currentFile.isEmpty()) {
fileSaveAs();
return ;
}
// Save current file
XMLSciFigs s;
s.saveFile(_currentFile, this, XMLSciFigs::Page);
}
| void SciFigs::GraphicSheet::fileSave | ( | QString | fileName | ) | [slot] |
References currentFileChanged(), fileName, fileSave(), and TRACE.
{
TRACE;
_currentFile=fileName;
fileSave();
emit currentFileChanged(_currentFile);
}
| void SciFigs::GraphicSheet::fileSaveAs | ( | ) | [slot] |
References currentFileChanged(), fileName, fileSave(), QGpCoreTools::tr(), and TRACE.
Referenced by addFileActions(), fileSave(), and PSViewer::fileSaveAsPS().
| GraphicObject * SciFigs::GraphicSheet::findObject | ( | QString | tag, |
| QString | name | ||
| ) |
References SciFigs::GraphicObject::objectName, TRACE, w, and SciFigs::GraphicObject::xml_tagName().
Referenced by xml_member().
{
TRACE;
QList<GraphicObject *> wList=graphicObjects();
GraphicObject * w;
foreach(w, wList) {
if(w->xml_tagName()==tagName &&
(objectName.isNull() || objectName==w->objectName()))
return w;
}
return 0;
}
| QPixmap SciFigs::GraphicSheet::image | ( | int | dpi = 0 | ) | [slot] |
References SciFigs::GraphicObject::colorMask(), QGpCoreTools::endl(), maximumResolution(), MSG_ID, SciFigs::GraphicObject::objectName, SciFigs::GraphicObject::print(), SciFigs::GraphicObject::restoreScaleFonts(), SciFigs::GraphicObject::scaleFonts(), SciFigs::SciFigsGlobal::screenResolution(), SciFigs::GraphicObject::setPrintSize(), QGpCoreTools::tr(), TRACE, SciFigs::GraphicObject::transparentMask, and SciFigs::GraphicObject::updateMask().
Referenced by copyImage(), and exportImage().
{
TRACE;
QApplication::processEvents(QEventLoop::ExcludeUserInputEvents);
QProgressDialog * progress=0;
QList<GraphicObject *> objectList=graphicObjects();
GraphicObject * obj;
int nObjects=objectList.count();
if(nObjects==0) {
Message::warning(MSG_ID, tr("Drawing image"), tr("No object in sheet, nothing to draw."), Message::cancel());
return QPixmap();
}
progress=new QProgressDialog(tr("Drawing ..."), QString::null, 0, objectList.count(), this);
progress->setWindowTitle(tr("Please wait"));
progress->setMaximum(nObjects-1);
if(dpi==0) dpi=maximumResolution();
double resolution=dpi/2.54;
double factor=resolution/SciFigsGlobal::screenResolution();
// Find limits of actual sheet
double x0, y0, x1, y1, mx0, my0, mx1, my1;
// Scale fonts and eventually adjust size of object for printing
int ** originalFonts=new int*[objectList.count()];
for(int i=0; i<nObjects; i++) {
obj=objectList.at(i);
originalFonts[i]=obj->scaleFonts(factor);
obj->setPrintSize(resolution);
}
printSize(x0, y0, x1, y1, mx0, my0, mx1, my1);
int totalw=(int) ((mx1-mx0)*resolution);
int totalh=(int) ((my1-my0)*resolution);
QPixmap pixmap;
if(totalw>0 && totalh>0) {
pixmap=QPixmap(totalw, totalh);
QPainter p;
p.begin(&pixmap);
p.eraseRect(0, 0, totalw, totalh);
p.save();
p.translate(-mx0 * resolution, -my0 * resolution);
// send print command to all graph positionning correctly like on the screen
// iterate on all graphs
for(int i=0; i<nObjects; i++) {
obj=objectList.at(i);
//App::stream() << tr("---- Drawing %1").arg(obj->objectName()) << endl;
obj->print(p, resolution, 0, 0, false);
if(progress) progress->setValue(i);
}
p.restore();
//SciFigsGlobal::footprint(p, resolution, totalw, totalh);
p.end();
if(_transparentMask) {
progress->reset();
QBitmap mask=GraphicObject::colorMask(pixmap, 0xFFFFFFFF);
p.begin(&mask);
p.translate(-mx0 * resolution, -my0 * resolution);
for(int i=0; i<nObjects; i++) {
obj=objectList.at(i);
App::stream() << tr("---- Setting mask %1").arg(obj->objectName()) << endl;
obj->print(p, resolution, 0, 0, true);
if(obj->transparentMask())
obj->updateMask();
if(progress) progress->setValue(i);
}
}
} else {
Message::warning(MSG_ID, tr("Drawing image"), tr("Null size for image (%1, %2).").arg(totalw).arg(totalh), Message::cancel());
}
// Restore fonts and eventually screen size of objects
for(int i=0; i<nObjects; i++) {
obj=objectList.at(i);
obj->restoreScaleFonts(originalFonts[i]);
obj->setPrintSize(SciFigsGlobal::screenResolution());
}
delete [] originalFonts;
if(progress) {
delete progress;
}
return pixmap;
}
| bool SciFigs::GraphicSheet::isOrderIndex | ( | ) | const [inline] |
{return _orderIndex >= 0;}
| void SciFigs::GraphicSheet::lowerSelection | ( | ) | [slot] |
Send to back all selected objects. It works also for stand-alone object because it is a classical re-organization of the children stack of a Qwidget.
References SciFigs::GraphicObject::selectionWidget(), showOrderIndex(), and TRACE.
{
TRACE;
QList<GraphicObject *> objectList=selectedObjects<GraphicObject *>();
GraphicObject * obj;
foreach(obj, objectList) {
obj->lower();
obj->selectionWidget() ->lower();
}
if(_orderIndex >= 0)
showOrderIndex(true);
}
References SciFigs::GraphicObject::printResolution, and TRACE.
Referenced by exportImage(), image(), and print().
{
TRACE;
QList<GraphicObject *> objectList=graphicObjects();
GraphicObject * obj;
int printResolution=0;
foreach(obj, objectList) {
int val=obj->printResolution();
if(printResolution < val)
printResolution=val;
}
return printResolution;
}
| virtual QSize SciFigs::GraphicSheet::minimumSizeHind | ( | ) | const [inline, virtual] |
{return QSize(100,100);}
| void SciFigs::GraphicSheet::mousePressEvent | ( | QMouseEvent * | e | ) | [protected, virtual] |
| void SciFigs::GraphicSheet::mouseReleaseEvent | ( | QMouseEvent * | e | ) | [protected, virtual] |
References selectObjects(), and TRACE.
{
TRACE;
switch (e->button()) {
case Qt::LeftButton:
selectObjects(0, e->modifiers());
break;
default:
break;
}
}
| void SciFigs::GraphicSheet::moveObject | ( | GraphicObject * | obj = 0 | ) | [slot] |
Move one object to its new position on screen and extend viewport if necessary. Coordinates are read from object data.
References autoResizeContent(), SciFigs::GraphicObject::printLeft(), SciFigs::GraphicObject::printTop(), QGpGuiTools::PropertyContext::proxy(), SciFigs::SciFigsGlobal::screenResolution(), SciFigs::GraphicObject::selectionWidget(), TRACE, SciFigs::GraphicObject::updateGeometryProperties(), SciFigs::SelectionWidget::x(), and SciFigs::SelectionWidget::y().
Referenced by addPlot(), alignX(), alignY(), createBands(), createCircles(), fileOpen(), paste(), and showObject().
{
TRACE;
if(!obj)
obj=(GraphicObject *) sender();
if(obj) {
obj->move((int) (obj->printLeft() * SciFigsGlobal::screenResolution()),
(int) (obj->printTop() * SciFigsGlobal::screenResolution()));
if(proxy()) {
obj->updateGeometryProperties(proxy());
}
SelectionWidget * selObj=obj->selectionWidget();
if(selObj)
selObj->move(selObj->x(obj->x()), selObj->y(obj->y()));
//if(obj->_orderTip) obj->_orderTip->move(obj->x()-widget()->x(),obj->y()-widget()->y());
autoResizeContent();
//ASSERT(false);
}
}
| GraphicObject * SciFigs::GraphicSheet::object | ( | QString | objectName | ) | [slot] |
References objectName, and TRACE.
{
TRACE;
return findChild<GraphicObject *>(objectName);;
}
| GraphicObject * SciFigs::GraphicSheet::object | ( | int | index | ) | [slot] |
References TRACE.
{
TRACE;
QList<GraphicObject *> objectList=graphicObjects();
QList<GraphicObject *>::iterator it;
if(index>=0 && index<(int)objectList.count()) {
return objectList.at(index);
} else {
qWarning("Index out of bounds (%i)\n", index);
return 0;
}
}
| QString SciFigs::GraphicSheet::objectList | ( | ) | const |
Referenced by autoResizeContent(), printBottom(), printRight(), and xml_writeChildren().
| void SciFigs::GraphicSheet::paste | ( | ) | [slot] |
References currentOrigin(), moveObject(), SciFigs::XMLSciFigs::Page, SciFigs::GraphicObject::printHeight, SciFigs::GraphicObject::printLeft(), SciFigs::GraphicObject::printTop(), SciFigs::GraphicObject::printWidth, SciFigs::GraphicObject::printXAnchor(), SciFigs::GraphicObject::printYAnchor(), SciFigs::XMLSciFigs::restoreByteArray(), SciFigs::GraphicObject::setPrintXAnchor(), SciFigs::GraphicObject::setPrintYAnchor(), QGpCoreTools::Point2D::setX(), QGpCoreTools::Point2D::setY(), TRACE, QGpCoreTools::Point2D::x(), and QGpCoreTools::Point2D::y().
Referenced by addEditActions().
{
TRACE;
QClipboard * cb=QApplication::clipboard();
const QMimeData * mime=cb->mimeData(QClipboard::Clipboard);
QByteArray objects;
if(mime->hasFormat("XMLSciFigs::Page")) {
objects=mime->data("XMLSciFigs::Page");
} else if(mime->hasFormat("XMLSciFigs")) { // Compatibility
objects=mime->data("XMLSciFigs");
} else {
return;
}
XMLSciFigs s;
_loadedObjects.clear();
s.restoreByteArray(objects, this, XMLSciFigs::Page);
// Move all pasted objects to current visible area
// First first the to left corner of the pasted objects
Point topLeft(1e99,1e99);
GraphicObject * obj;
foreach (obj, _loadedObjects) {
Point p(obj->printLeft(obj->printWidth()), obj->printTop(obj->printHeight()));
if(p.x()<topLeft.x()) topLeft.setX(p.x());
if(p.y()<topLeft.y()) topLeft.setY(p.y());
}
double dx=currentOrigin().x() - topLeft.x() + 1;
double dy=currentOrigin().y() - topLeft.y() + 1;
foreach (obj, _loadedObjects) {
obj->setPrintXAnchor(obj->printXAnchor() + dx);
obj->setPrintYAnchor(obj->printYAnchor() + dy);
moveObject(obj);
}
_loadedObjects.clear();
}
| void SciFigs::GraphicSheet::pasteMakeUp | ( | ) | [slot] |
Paste properties from the clipboard if there are
References deepUpdate(), QGpCoreTools::XMLErrorReport::exec(), SciFigs::XMLSciFigs::MakeUp, SciFigs::XMLSciFigs::restoreByteArray(), QGpCoreTools::XMLErrorReport::setTitle(), QGpCoreTools::tr(), and TRACE.
Referenced by addFormatActions().
{
TRACE;
static QString title=tr("Paste make-up");
QClipboard * cb=QApplication::clipboard();
const QMimeData * mime=cb->mimeData(QClipboard::Clipboard);
if(mime->hasFormat("XMLSciFigs::SheetMakeUp")) {
QByteArray makeup=mime->data("XMLSciFigs::SheetMakeUp");
XMLErrorReport xmler(XMLErrorReport::Read);
xmler.setTitle(title);
XMLSciFigs s;
xmler.exec(s.restoreByteArray(makeup, this, XMLSciFigs::MakeUp));
deepUpdate();
}
}
| void SciFigs::GraphicSheet::print | ( | QPrinter & | printer | ) |
References SciFigs::GraphicObject::print(), SciFigs::SciFigsGlobal::screenResolution(), QGpCoreTools::tr(), TRACE, and updatePageLimits().
Referenced by addFileActions(), exportImage(), and print().
{
TRACE;
updatePageLimits(printer);
QPainter p;
p.begin(&printer);
// send print command to all graph positionning correctly like on the screen
// iterate on all graphs to plot new points
QList<GraphicObject *> objectList=graphicObjects();
GraphicObject * obj;
// Get page area and number of pages in x and y direction
int wScrPage=(int) ((double) printer.widthMM() * SciFigsGlobal::screenResolution() * 0.1);
int hScrPage=(int) ((double) printer.heightMM() * SciFigsGlobal::screenResolution() * 0.1);
int wPtrPage=(int) ((double) printer.widthMM() * printer.resolution()/25.4);
int hPtrPage=(int) ((double) printer.heightMM() * printer.resolution()/25.4);
if(wScrPage==0 || hScrPage==0) {
printer.abort();
return ;
}
int xpages=1 + widget() ->width()/wScrPage;
int ypages=1 + widget() ->height()/hScrPage;
QProgressDialog * progress=0;
// TODO Batch hidden mode
//if(!app.qsa().hiddenMode()) {
progress=new QProgressDialog(tr("Printing ..."), QString::null, 0, objectList.count() * xpages * ypages, this);
progress->setWindowTitle(tr("Please wait"));
//}
int iprogress=0;
double dotpercm=(double) printer.resolution()/2.54;
for(int ix=0;ix < xpages;ix++) {
for(int iy=0;iy < ypages;iy++) {
if(ix > 0 || iy > 0)
printer.newPage();
QRect r(ix * wScrPage, iy * hScrPage, wScrPage, hScrPage);
foreach(obj, objectList) {
if(r.intersects(obj->geometry())) {
obj->print(p, dotpercm, ix * wPtrPage, iy * hPtrPage, false);
}
if(progress) {
++iprogress;
progress->setValue(iprogress);
}
}
}
}
p.end();
if(progress) {
progress->setValue(iprogress);
delete progress;
}
}
| void SciFigs::GraphicSheet::print | ( | int | dpi = 0 | ) | [slot] |
References maximumResolution(), print(), and TRACE.
{
TRACE;
QPrinter printer(QPrinter::HighResolution);
if(dpi==0)
printer.setResolution((int) maximumResolution());
else
printer.setResolution(dpi);
printer.setFullPage(true);
if(Settings::printSetup(printer)) {
QApplication::processEvents(QEventLoop::ExcludeUserInputEvents);
print(printer);
}
}
| void SciFigs::GraphicSheet::print | ( | bool | outputToFile, |
| QString | name, | ||
| int | dpi | ||
| ) | [slot] |
References maximumResolution(), print(), and TRACE.
{
TRACE;
QPrinter printer(QPrinter::HighResolution);
if(dpi==0) printer.setResolution((int)maximumResolution());
else printer.setResolution(dpi);
printer.setFullPage(true);
if(outputToFile) printer.setOutputFileName(name);
else printer.setPrinterName(name);
print(printer);
}
| double SciFigs::GraphicSheet::printBottom | ( | ) |
Return the bottom of the sheet in cm. It is the maximum bottom of all objects.
References objectList(), SciFigs::GraphicObject::printBottom(), and TRACE.
Referenced by MonoStation::WinResults::loadResults(), HVRotateWinResults::setStations(), and SpectrumRotateWinResults::setStations().
{
TRACE;
QList<GraphicObject *> objectList=graphicObjects();
double maxv=0.0;
GraphicObject * obj;
foreach(obj, objectList) {
double v=obj->printBottom();
if(v > maxv)
maxv=v;
}
return maxv;
}
| double SciFigs::GraphicSheet::printRight | ( | ) |
Return the right of the sheet in cm. It is the maximum right of all objects.
References objectList(), SciFigs::GraphicObject::printRight(), and TRACE.
Referenced by Seismic1DThread::initModelGraphs(), MagnetoTelluricThread::initModelGraphs(), CurvesThread::initResultsGraphs(), MagnetoTelluricThread::initResultsGraphs(), and DispersionGridThread::initResultsGraphs().
{
TRACE;
QList<GraphicObject *> objectList=graphicObjects();
double maxv=0.0;
GraphicObject * obj;
foreach(obj, objectList) {
double v=obj->printRight();
if(v > maxv)
maxv=v;
}
return maxv;
}
| void SciFigs::GraphicSheet::properties | ( | PropertyWidget * | w | ) | const [virtual] |
| void SciFigs::GraphicSheet::raiseSelection | ( | ) | [slot] |
Bring to front all selected objects. It works also for stand-alone object because it is a classical re-organization of the children stack of a Qwidget.
References SciFigs::GraphicObject::selectionWidget(), showOrderIndex(), and TRACE.
{
TRACE;
QList<GraphicObject *> objectList=selectedObjects<GraphicObject *>();
GraphicObject * obj;
foreach(obj, objectList) {
obj->raise();
if(obj->selectionWidget())
obj->selectionWidget() ->stackUnder(obj);
}
if(_orderIndex >= 0)
showOrderIndex(true);
}
| void SciFigs::GraphicSheet::redo | ( | ) | [slot] |
| bool SciFigs::GraphicSheet::removeObject | ( | GraphicObject * | obj, |
| bool | force | ||
| ) |
Remove object obj from the sheet.
If object is not removable (see QObject::isRemovable()), it will be removed only if force is true (default value is true).
Return true if object correctly removed.
References autoResizeContent(), SciFigs::GraphicObject::isRemovable(), QGpGuiTools::PropertyContext::proxy(), SciFigs::GraphicObject::removeProperties(), SciFigs::GraphicObject::selectionWidget(), SciFigs::GraphicObject::setSelected(), TRACE, and SciFigs::SelectionWidget::widget().
Referenced by clear(), SciFigs::GraphicObject::deleteObject(), and SciFigs::GraphicSheetMenu::removeObject().
{
TRACE;
if(force || obj->isRemovable()) {
SelectionWidget * tmp=obj->selectionWidget();
if(proxy()) obj->removeProperties(proxy());
if(_currentActiveSelection==tmp)
_currentActiveSelection=0;
if(tmp) {
tmp->widget() ->setSelected(0);
tmp->deleteLater();
}
obj->close();
autoResizeContent();
return true;
} else
return false;
}
| Q_SCRIPTABLE bool SciFigs::GraphicSheet::removeObject | ( | GraphicObject * | obj | ) | [inline, slot] |
| void SciFigs::GraphicSheet::removeProperties | ( | PropertyProxy * | pp | ) |
References QGpGuiTools::PropertyProxy::removeTab(), QGpGuiTools::PropertyProxy::setCurrentCategory(), and TRACE.
Referenced by ~GraphicSheet().
{
TRACE;
if(pp->setCurrentCategory(_category)) {
pp->removeTab(_tabPrint, this);
}
}
| void SciFigs::GraphicSheet::resizeObject | ( | ) | [slot] |
Resize one object and extend viewport if necessary. Size is read from object data.
References autoResizeContent(), SciFigs::SelectionWidget::height(), SciFigs::GraphicObject::printHeight, SciFigs::GraphicObject::printWidth, SciFigs::SciFigsGlobal::screenResolution(), SciFigs::GraphicObject::selectionWidget(), TRACE, and SciFigs::SelectionWidget::width().
Referenced by showObject().
{
TRACE;
GraphicObject * obj=(GraphicObject *) sender();
obj->QWidget::resize((int) (obj->printWidth() * SciFigsGlobal::screenResolution()),
(int) (obj->printHeight() * SciFigsGlobal::screenResolution()));
SelectionWidget * selObj=obj->selectionWidget();
if(selObj)
selObj->resize(selObj->width(), selObj->height());
autoResizeContent();
}
| void SciFigs::GraphicSheet::restoreMakeUp | ( | QString | fileName = QString::null | ) | [slot] |
Restore all properties of the sheet and included objects from fileName
References QGpCoreTools::XMLErrorReport::exec(), SciFigs::XMLSciFigs::MakeUp, SciFigs::XMLSciFigs::restoreFile(), QGpCoreTools::XMLErrorReport::setFileName(), QGpCoreTools::XMLErrorReport::setTitle(), QGpCoreTools::tr(), and TRACE.
Referenced by addFormatActions(), main(), and MonoStation::StatisticResults::studentTest().
{
TRACE;
static QString title=tr("Open an exisiting make-up");
if(fileName.isEmpty()) {
fileName=Message::getOpenFileName(title, tr("Sheet make-up (*.mkup)"));
}
if(fileName.length() > 0) {
MessageContext mc;
XMLErrorReport xmler(XMLErrorReport::Read);
xmler.setTitle(title);
xmler.setFileName(fileName);
QFileInfo fi(fileName);
XMLSciFigs s;
xmler.exec(s.restoreFile(fileName, this, XMLSciFigs::MakeUp));
}
}
| void SciFigs::GraphicSheet::saveLayers | ( | QString | fileName = QString::null | ) | [slot] |
Save layers of selected axiswindows
References selectAll(), QGpCoreTools::tr(), and TRACE.
Referenced by addFormatActions(), and exportFile().
{
TRACE;
QList<AxisWindow *> objectList=selectedObjects<AxisWindow *>();
if(objectList.isEmpty()) {
if(!selectAll(tr("Save layers"))) return;
objectList=selectedObjects<AxisWindow *>();
}
if(fileName.isEmpty()) {
fileName=Message::getSaveFileName(tr("Save layers as..."),
tr("Graph layers (*.layer)"));
}
if(fileName.length() > 0) {
if(objectList.count()==1) {
objectList.first()->graphContent()->saveLayers(fileName);
} else {
QFileInfo fi(fileName);
QDir d(fi.absolutePath());
QString baseName;
if(fi.suffix()=="layer") {
baseName=d.absoluteFilePath(fi.completeBaseName() + "_%1.layer");
} else {
baseName=d.absoluteFilePath(fi.fileName() + "_%1");
}
for(int i=0; i<objectList.count(); i++) {
objectList.at(i)->graphContent()->saveLayers(baseName.arg(i, 4, 10, QChar('0')));
}
}
}
}
| void SciFigs::GraphicSheet::saveMakeUp | ( | QString | fileName = QString::null | ) | [slot] |
Save all properties of the sheet and included objects
References SciFigs::XMLSciFigs::MakeUp, SciFigs::MakeUpFilter::saveFile(), SciFigs::XMLSciFigs::saveString(), SciFigs::MakeUpFilter::setXml(), QGpCoreTools::tr(), and TRACE.
Referenced by addFormatActions().
{
TRACE;
XMLSciFigs s;
MakeUpFilter * d=new MakeUpFilter(this);
d->setXml(s.saveString(this, XMLSciFigs::MakeUp));
if(d->exec()==QDialog::Accepted) {
if(fileName.isEmpty()) {
fileName=Message::getSaveFileName(tr("Save make-up as ..."),
tr("Sheet make-up (*.mkup)"));
}
if(fileName.length() > 0) {
d->saveFile(fileName);
}
}
delete d;
}
| Q_SCRIPTABLE void SciFigs::GraphicSheet::select | ( | GraphicObject * | obj | ) | [inline, slot] |
{selectObjects(obj, Qt::NoModifier);}
| void SciFigs::GraphicSheet::selectAll | ( | ) | [slot] |
References QGpGuiTools::PropertyProxy::blockUpdates(), QGpGuiTools::PropertyContext::proxy(), QGpGuiTools::PropertyProxy::saveStates(), selectObjects(), and TRACE.
Referenced by addEditActions(), addLayers(), exportFile(), saveLayers(), MonoStation::WinResults::selectAll(), and selectAll().
{
TRACE;
QList<GraphicObject *> objectList=graphicObjects();
GraphicObject * obj;
if(proxy()) {
proxy()->saveStates();
proxy()->blockUpdates(true);
}
foreach(obj, objectList) selectObjects(obj, Qt::ShiftModifier);
if(proxy()) proxy()->blockUpdates(false);
}
| bool SciFigs::GraphicSheet::selectAll | ( | QString | actionTitle | ) | [slot] |
If not graph is selected, warns user and select all graphs if confirmed by user. It returns false if user answer no (cancel).
References MSG_ID, selectAll(), QGpCoreTools::tr(), and TRACE.
| QList< T > SciFigs::GraphicSheet::selectedObjects | ( | ) | const |
References SciFigs::SelectionWidget::Hoover, and w.
Referenced by SciFigs::GraphicObject::deleteObject().
{
QList<T> wList;
QList<SelectionWidget *> wSelList=findChildren<SelectionWidget *>();
SelectionWidget * wSel;
foreach(wSel, wSelList) {
if(wSel->state()!=SelectionWidget::Hoover) {
GraphicObject * w=wSel->widget();
T castedW=qobject_cast<T>(w);
if(castedW)
wList << castedW;
}
}
return wList;
}
| void SciFigs::GraphicSheet::selectNextChild | ( | ) | [slot] |
Select next child (in the stack order, just after the current object). This function is called after a TAB action.
References selectObjects(), TRACE, and SciFigs::SelectionWidget::widget().
Referenced by GraphicSheet().
{
TRACE;
QList<GraphicObject *> objectList=graphicObjects();
if(objectList.isEmpty()) return;
GraphicObject * cur;
if(_currentActiveSelection)
cur=_currentActiveSelection->widget();
else
cur=0;
QList<GraphicObject *>::iterator it;
for(it=objectList.begin(); it!=objectList.end(); ++it) {
if(*it==cur) {++it;break;}
}
if(it!=objectList.end()) {
selectObjects(*it, Qt::NoModifier);
} else {
selectObjects(objectList.first(), Qt::NoModifier);
}
}
| void SciFigs::GraphicSheet::selectObjects | ( | GraphicObject * | obj, |
| Qt::KeyboardModifiers | m = Qt::NoModifier |
||
| ) | [slot] |
References SciFigs::SelectionWidget::Activated, activeSelectionChanged(), SciFigs::GraphicObject::addProperties(), addSelection(), QGpGuiTools::PropertyContext::proxy(), QGpGuiTools::PropertyProxy::restoreStates(), QGpGuiTools::PropertyProxy::saveStates(), SciFigs::SelectionWidget::Selected, SciFigs::GraphicObject::selectionWidget(), SciFigs::GraphicObject::setSelected(), SciFigs::SelectionWidget::setState(), QGpGuiTools::PropertyProxy::setValues(), QGpCoreTools::tr(), TRACE, update(), and SciFigs::SelectionWidget::widget().
Referenced by addObject(), addSelectNextChild(), mouseReleaseEvent(), selectAll(), selectNextChild(), and ~GraphicSheet().
{
TRACE;
if(proxy()) proxy()->saveStates();
SelectionWidget * selObj;
if(obj)
selObj=obj->selectionWidget();
else
selObj=0;
if(obj && !obj->selectionWidget()) {
selObj=addSelection(obj);
selObj->show(); // Here and not in addSelection(), bug observed with Qt 4.6 under Mac, show() calls GraphicObject::enterEvent()
if(proxy()) obj->addProperties(proxy());
} else if(selObj) {
selObj->setState(SelectionWidget::Activated);
emit activeSelectionChanged(obj);
if(proxy()) obj->addProperties(proxy());
}
if(!(m & Qt::ShiftModifier)) {
// Unselect all
QList<SelectionWidget *> wList=findChildren<SelectionWidget *>();
SelectionWidget * tmp;
foreach(tmp, wList) {
if(tmp!=selObj) {
tmp->widget()->setSelected(0);
if(proxy()) tmp->widget()->removeProperties(proxy());
delete tmp;
}
}
// Bug fixed 28/10/04, if no shift key, all selection widgets are removed
// Object eventually pointed by current avtive selection is deleted.
_currentActiveSelection=0;
// Bug fixed for Qt 4.3 : selection mark remains visible if sheet not updated
#if(QT_VERSION < QT_VERSION_CHECK(4, 4, 0))
update();
#endif
// Bug fixed with Qt 4.4: update makes the selection quite slow with a lot of objects
}
if(_currentActiveSelection && _currentActiveSelection!=selObj) {
_currentActiveSelection->setState(SelectionWidget::Selected);
}
_currentActiveSelection=selObj;
if(_currentActiveSelection && _statusBar)
_statusBar->showMessage(tr("Hit CTRL+M to display popup menu of the active object"));
if(proxy()) {
proxy()->restoreStates();
proxy()->setValues();
}
}
| void SciFigs::GraphicSheet::setObjectList | ( | QString | list | ) |
| void SciFigs::GraphicSheet::setObjectOrder | ( | QString | list | ) |
| void SciFigs::GraphicSheet::setOrderIndex | ( | GraphicObject * | obj | ) |
References SciFigs::GraphicObject::selectionWidget(), showOrderIndex(), and TRACE.
Referenced by SciFigs::GraphicObject::mouseReleaseEvent().
{
TRACE;
if(_orderIndex >= 0) {
QList<GraphicObject *> objectList=graphicObjects();
QList<GraphicObject *>::iterator it;
int i=0;
for(it=objectList.begin();it!=objectList.end();++it, i++) {
if(i==_orderIndex)
break;
}
if(it==objectList.end()) {
it=objectList.begin();
_orderIndex=0;
}
GraphicObject * objAbove=*it;
if(objAbove) {
obj->stackUnder(objAbove);
if(obj->selectionWidget())
obj->selectionWidget() ->stackUnder(obj);
_orderIndex++;
}
showOrderIndex(true);
}
}
| void SciFigs::GraphicSheet::setPreferences | ( | ) | [slot] |
References SciFigs::SciFigsPreferences::savePluginList(), and TRACE.
Referenced by addFileActions().
{
TRACE;
SciFigsPreferences * d=new SciFigsPreferences(this);
Settings::getWidget(d);
if(d->exec()==QDialog::Accepted) {
Settings::setWidget(d);
d->savePluginList();
}
delete d;
}
| void SciFigs::GraphicSheet::setProperty | ( | uint | wid, |
| int | pid, | ||
| QVariant | val | ||
| ) | [virtual] |
Implements QGpGuiTools::PropertyItem.
References setTransparency(), setTransparentMask(), TRACE, SciFigs::GraphicSheetProperties::Transparency, and SciFigs::GraphicSheetProperties::TransparentMask.
{
TRACE;
switch(pid) {
case GraphicSheetProperties::Transparency:
setTransparency(val.toInt());
break;
case GraphicSheetProperties::TransparentMask:
setTransparentMask(val.toBool());
break;
}
}
| void SciFigs::GraphicSheet::setStatusBar | ( | QStatusBar * | s | ) | [inline] |
Referenced by PtMotionResults::createObjects(), LinearFKActiveResults::createObjects(), TFAResults::createObjects(), MonoStation::StatisticResults::createObjects(), DampingResults::createObjects(), MainWindow::MainWindow(), MonoStation::WinResults::setStations(), and MonoStation::AbstractSummary::setStations().
{_statusBar=s;}
| void SciFigs::GraphicSheet::setTransparency | ( | int | val | ) | [inline] |
Referenced by setProperty().
{_transparency=val;}
| void SciFigs::GraphicSheet::setTransparentMask | ( | bool | val | ) |
References TRACE.
Referenced by setProperty().
{
TRACE;
_transparentMask=val;
//if(!val) clearMask();
}
| void SciFigs::GraphicSheet::showObject | ( | GraphicObject * | obj | ) |
References moveObject(), SciFigs::GraphicObject::printHeight, SciFigs::GraphicObject::printLeft(), SciFigs::GraphicObject::printTop(), SciFigs::GraphicObject::printWidth, resizeObject(), SciFigs::SciFigsGlobal::screenResolution(), showOrderIndex(), startDragging(), and TRACE.
Referenced by SciFigs::GraphicSheetMenu::addGraph(), addObject(), PSViewer::addPlot(), SciFigs::GraphicSheetMenu::addText(), DinverDCGui::DCModelViewer::addText(), ResultsThread::createLegend(), TFAResults::createObjects(), DinverDCGui::DCModelViewer::initGraphs(), Seismic1DThread::initModelGraphs(), MagnetoTelluricThread::initModelGraphs(), CurvesThread::initResultsGraphs(), MagnetoTelluricThread::initResultsGraphs(), DispersionGridThread::initResultsGraphs(), and xml_polishChild().
{
TRACE;
connect(obj, SIGNAL(positionChanged()), this, SLOT(moveObject()));
connect(obj, SIGNAL(wantToStartDragging()), this, SLOT(startDragging()));
connect(obj, SIGNAL(dragged(Point2D)), this, SLOT(dragObjects(Point2D)));
connect(obj, SIGNAL(sizeChanged()), this, SLOT(resizeObject()));
obj->setParent(widget());
obj->QWidget::move((int) (obj->printLeft() * SciFigsGlobal::screenResolution()),
(int) (obj->printTop() * SciFigsGlobal::screenResolution()));
obj->resize((int) (obj->printWidth() * SciFigsGlobal::screenResolution()),
(int) (obj->printHeight() * SciFigsGlobal::screenResolution()));
// TODO Batch hidden mode
//if(app.qsa().hiddenMode()) {
// obj->polish();
// obj->updateGeometry();
//} else {
obj->show();
//}
if(_orderIndex >= 0)
showOrderIndex(true);
}
| void SciFigs::GraphicSheet::showOrderIndex | ( | bool | isOn | ) | [slot] |
References SciFigs::GraphicObject::setOrderIndex(), QGpCoreTools::tr(), and TRACE.
Referenced by addEditActions(), lowerSelection(), raiseSelection(), setOrderIndex(), and showObject().
{
TRACE;
QList<GraphicObject *> objectList=graphicObjects();
GraphicObject * obj;
if(isOn) {
if(_statusBar)
_statusBar->showMessage(tr("Select objects to change their order"));
if(_orderIndex < 0)
_orderIndex=0;
for(int i=0; i < objectList.count(); i++) {
obj=objectList.at(i);
obj->setOrderIndex(i + 1);
}
} else {
if(_statusBar)
_statusBar->showMessage("");
_orderIndex=-1;
foreach(obj, objectList) obj->setOrderIndex(-1);
}
}
| void SciFigs::GraphicSheet::showProperties | ( | ) | [slot] |
References addProperties(), SciFigs::GraphicObject::addProperties(), QGpGuiTools::PropertyContext::initProxy(), QGpGuiTools::PropertyContext::proxy(), QGpGuiTools::PropertyContext::raiseEditor(), QGpGuiTools::PropertyProxy::restoreStates(), QGpGuiTools::PropertyProxy::saveStates(), QGpGuiTools::PropertyContext::setPropertyTitle(), QGpGuiTools::PropertyProxy::setValues(), TRACE, and SciFigs::SelectionWidget::widget().
Referenced by addActions(), addFormatActions(), and SciFigs::GraphicObject::showProperties().
{
TRACE;
initProxy();
proxy()->saveStates();
addProperties(proxy());
QList<GraphicObject *> wList=selectedObjects<GraphicObject *>();
GraphicObject * curObj;
if(_currentActiveSelection)
curObj=_currentActiveSelection->widget();
else
curObj=0;
for(int i=wList.count()-1; i>=0; i--) {
GraphicObject * obj=wList.at(i);
if(obj!= curObj) obj->addProperties(proxy());
}
if(curObj) curObj->addProperties(proxy());
setPropertyTitle(this);
raiseEditor();
proxy()->restoreStates();
proxy()->setValues();
}
| void SciFigs::GraphicSheet::startDragging | ( | ) | [slot] |
Referenced by showObject().
| QStatusBar* SciFigs::GraphicSheet::statusBar | ( | ) | [inline] |
{return _statusBar;}
| int SciFigs::GraphicSheet::transparency | ( | ) | const [inline] |
Referenced by properties().
{return _transparency;}
| bool SciFigs::GraphicSheet::transparentMask | ( | ) | const [inline] |
Referenced by properties().
{return _transparentMask;}
| void SciFigs::GraphicSheet::undo | ( | ) | [slot] |
| QString SciFigs::GraphicSheet::uniqueName | ( | GraphicObject * | obj, |
| QString | newName | ||
| ) |
References SciFigs::GraphicObject::objectName, and TRACE.
Referenced by SciFigs::GraphicObject::setObjectName().
{
TRACE;
QList<GraphicObject *> wList=graphicObjects();
QList<GraphicObject *>::iterator it;
for(it=wList.begin();it!=wList.end();++it) {
if(namedW!=*it && newName==(*it) ->objectName()) {
int i=newName.lastIndexOf('_');
int n;
if(i > -1) {
bool ok;
n=newName.right(newName.length() - i - 1).toInt(&ok) + 1;
if(ok)
newName=newName.left(i);
else
n=0;
} else
n=0;
newName=(newName + "_") + QString::number(n);
it=wList.begin();
}
}
return newName;
}
| Q_SCRIPTABLE void SciFigs::GraphicSheet::unSelectAll | ( | ) | [inline, slot] |
{selectObjects(0, Qt::NoModifier);}
| void SciFigs::GraphicSheet::update | ( | ) | [virtual, slot] |
Redraw only some parts of the objects, generally not including the slow drawing actions.
Use deepUpdate() or deepUpdateNow() to redraw all parts.
References SciFigs::GraphicObject::selectionWidget(), TRACE, and SciFigs::GraphicObject::update().
Referenced by selectObjects(), and xml_polish().
{
TRACE;
QList<GraphicObject *> objectList=graphicObjects();
GraphicObject * obj;
foreach(obj, objectList) {
obj->update();
if(obj->selectionWidget())
obj->selectionWidget() ->update();
}
}
| void SciFigs::GraphicSheet::updatePageLimits | ( | QPrinter & | p | ) | [slot] |
Refresh the limits of pages
References SciFigs::PageLimit::Horizontal, SciFigs::SciFigsGlobal::screenResolution(), TRACE, and SciFigs::PageLimit::Vertical.
Referenced by print().
{
TRACE;
// Remove all existing limits
PageLimit * limit;
QList<PageLimit *> pageList=findChildren<PageLimit *>();
foreach(limit, pageList) delete limit;
// Create new limits
int wpage=(int) ((double) p.widthMM() * SciFigsGlobal::screenResolution() * 0.1);
int hpage=(int) ((double) p.heightMM() * SciFigsGlobal::screenResolution() * 0.1);
int w=wpage, h=hpage;
while(w < widget() ->width()) {
limit=new PageLimit(PageLimit::Vertical, widget());
limit->move(w, 0);
limit->show();
w += wpage;
}
while(h < widget() ->height()) {
limit=new PageLimit(PageLimit::Horizontal, widget());
limit->move(0, h);
limit->show();
h += hpage;
}
}
| XMLMember SciFigs::GraphicSheet::xml_member | ( | XML_MEMBER_ARGS | ) | [protected, virtual] |
Re-implement this function to offer XML restore (children and properties) support to your class.
From tag and map (with contains the attibute value) return a unique identifier under the format of a XMLMember. XMLMember is initialized with 3 types of contructors:
Map of attributes can be inspected in this way (can be achived also in xml_setProperty()):
static const QString tmp("childrenName"); XMLRestoreAttributeIterator it=map.find(tmp); if(it!=map.end()) { // found attribute "childrenName" }
If the map of attributes is not used:
Q_UNUSED(attributes);
if(tag=="x1") return XMLMember(0);
else if(tag=="y1") return XMLMember(1);
else if(tag=="x2") return XMLMember(2);
else if(tag=="y2") return XMLMember(3);
else return XMLMember(XMLMember::Unknown);
Arithmetic operations + and - apply to XMLMember to avoid confusion of property id numbers between inherited objects. Offset 3 corresponds to the number of properties defined in this object.
if(tag=="anInteger") return XMLMember(0); else if(tag=="aString") return XMLMember(1); else if(tag=="aDouble") return XMLMember(2); return AbstractLine::xml_member(tag, attributes, context)+3;
For the arguments of this function use Macro XML_MEMBER_ARGS.
Reimplemented from QGpCoreTools::XMLClass.
References addObject(), SciFigs::GraphicObjectFactory::create(), SciFigs::XMLSciFigs::data(), QGpCoreTools::endl(), findObject(), SciFigs::GraphicObjectFactory::instance(), SciFigs::XMLSciFigs::makeUp(), MSG_ID, SciFigs::GraphicObject::objectName, QGpCoreTools::XMLClass::qobject_member(), SciFigs::GraphicObject::setRemovable(), QGpCoreTools::tr(), and TRACE.
{
TRACE;
static const QString tmp("objectName");
XMLSciFigs * scifigsContext=static_cast<XMLSciFigs *>(context);
XMLRestoreAttributeIterator it=attributes.find(tmp);
if(it!=attributes.end()) {
if(scifigsContext->data()) {
GraphicObject * obj=GraphicObjectFactory::instance()->create(tag.toString());
if(obj) {
obj->setRemovable(true);
addObject(obj);
return XMLMember(obj);
} else {
App::stream() << tr("Unknown object type %1").arg(tag.toString()) << endl;
return XMLMember(XMLMember::Unknown);
}
} else {
GraphicObject * obj=findObject(tag.toString(), it.value().toString());
if(obj) return XMLMember(obj);
else {
obj=findObject(tag.toString(),0);
if(obj) {
if(Message::warning(MSG_ID,"Restore",
tr("Cannot find an object of type %1 and named %2,\n"
"but an object of type %3 and named %4 has been found.\n"
"Do you want to restore properties to this object?").
arg(tag.toString()).arg(it.value().toString()).
arg(tag.toString()).arg(obj->objectName()),
Message::yes(),Message::no(), true)==Message::Answer0) {
return XMLMember(obj);
} else return XMLMember(XMLMember::Unknown);
} else {
App::stream() << tr("Cannot find an object of type %1").arg(tag.toString()) << endl;
return XMLMember(XMLMember::Unknown);
}
}
}
} else if(scifigsContext->makeUp()) {
return qobject_member(this, tag, attributes, context);
}
return XMLMember(XMLMember::Unknown);
}
| void SciFigs::GraphicSheet::xml_polish | ( | XML_POLISH_ARGS | ) | [protected, virtual] |
Reimplemented from QGpCoreTools::XMLClass.
References autoResizeContent(), TRACE, and update().
{
TRACE;
Q_UNUSED(context);
autoResizeContent();
update();
}
| void SciFigs::GraphicSheet::xml_polishChild | ( | XML_POLISHCHILD_ARGS | ) | [protected, virtual] |
Reimplemented from QGpCoreTools::XMLClass.
References showObject(), and TRACE.
{
TRACE;
Q_UNUSED(context);
showObject(static_cast<GraphicObject *>(child));
_loadedObjects.append(static_cast<GraphicObject *>(child));
}
| virtual bool SciFigs::GraphicSheet::xml_setProperty | ( | XML_SETPROPERTY_ARGS | ) | [inline, protected, virtual] |
Re-implement this function to offer XML restore properties support to your class.
From memberID set the corresponding property with value content. The map of attributes is given as a supplementary information (not useful in all cases).
For a general case:
Q_UNUSED(attributes); double val=content.toDouble(); switch (memberID) { case 0: _x1=val; return true; case 1: _y1=val; return true; case 2: _x2=val; return true; case 3: _y2=val; return true; default: return false; }
For classes inheriting other classes (see also xml_member())
switch (memberID) { case 0: _anInteger=content.toString(); return true; case 1: _aString=content.toInt(); return true; case 2: _aDouble=content.toDouble(); return true; default: return AbstractLine::xml_setProperty(memberID-3, map, content);
For the arguments of this function use Macro XML_SETPROPERTY_ARGS.
Reimplemented from QGpCoreTools::XMLClass.
{return qobject_setProperty(this, memberID, tag, attributes, content, context);}
| virtual const QString& SciFigs::GraphicSheet::xml_tagName | ( | ) | const [inline, virtual] |
Implements QGpCoreTools::XMLClass.
{return xmlGraphicSheetTag;}
| void SciFigs::GraphicSheet::xml_writeChildren | ( | XML_WRITECHILDREN_ARGS | ) | const [protected, virtual] |
Reimplemented from QGpCoreTools::XMLClass.
References QGpCoreTools::XMLSaveAttributes::add(), objectList(), SciFigs::GraphicObject::objectName, SciFigs::XMLSciFigs::selection(), TRACE, and QGpCoreTools::XMLClass::xml_save().
{
TRACE;
QList<GraphicObject *> objectList;
XMLSciFigs * scifigsContext=static_cast<XMLSciFigs *>(context);
if(scifigsContext->selection())
objectList=selectedObjects<GraphicObject *>();
else
objectList=graphicObjects();
GraphicObject * obj;
static const QString key("objectName");
XMLSaveAttributes att;
QString& value=att.add(key);
foreach (obj, objectList) {
value=obj->objectName();
obj->xml_save(s, context, att);
}
}
const QString SciFigs::GraphicSheet::xmlGraphicSheetTag = "GraphicSheet" [static] |
QString SciFigs::GraphicSheet::name [read, write] |
int SciFigs::GraphicSheet::objectCount [read] |
Count the number of objects currently in the sheet. This function is not inlined and should not be used directly in a loop. If possible, it is better to store the returned value before entering a loop.
QString SciFigs::GraphicSheet::objectList [read, write] |
QString SciFigs::GraphicSheet::objectName [read, write] |
Referenced by object().
QString SciFigs::GraphicSheet::objectOrder [read, write] |
bool SciFigs::GraphicSheet::orderIndex [read, write] |
int SciFigs::GraphicSheet::transparency [read, write] |
bool SciFigs::GraphicSheet::transparentMask [read, write] |
