A signal with samples in double precision with metadata (name, coordinates,...) More...
#include <Signal.h>
Public Types | |
enum | AmplitudeUnits { UndefinedUnit, Displacement, Velocity, Acceleration, CustomUnit } |
enum | Components { Vertical, North, East, All, Horizontal, UndefinedComponent } |
enum | PickWhat { Min = 1, Max = 2 } |
Public Member Functions | |
int | add (const Signal *sig, const TimeRange &tw, bool checkInvalid=false, double invalidValue=1e99) |
void | addMetaData (MetaData *d) |
double | amplitudeAt (double abscissa) const |
AmplitudeUnits | amplitudeUnit () const |
QString | amplitudeUnitStandardName () const |
QString | amplitudeUnitUserName () const |
double | averageAmplitude (int itmin=0, int itmax=0) const |
int | byteIncrement () const |
QString | comments () const |
int | compare (const Signal &o) const |
Components | component () const |
QString | componentStandardName () const |
QString | componentUserName () const |
virtual const double * | constLockSamples () const |
const double * | constLockSamples (char *file, int line) const |
void | copyBasicProperties (const Signal &p) |
void | copySamplesFrom (const Signal *sig) |
void | copySamplesFrom (const Signal *sig, const TimeRange &tw) |
double | correlation (const Signal *sig, const TimeRange &tw) |
void | correlation (const Signal *s1, const Signal *s2, double maxDelay) |
double | countPerUnit () const |
double | countPerVolt () const |
Signal * | cut (TimeRange r) const |
SignalDB * | database () const |
virtual QString | debugName () const |
QString | effectiveAmplitudeUnit () const |
double | endTime () const |
TIME | endTimeAsTIME () const |
SignalFile * | file () const |
const GuralpRecords & | guralpRecords () const |
bool | hasMetaData (int id) const |
QVariant | header (const MetaDataIndex &index) const |
int | id () const |
bool | isHeaderModified () const |
bool | isOriginalFile () const |
bool | isReadOnlySamples () const |
virtual double * | lockSamples () |
double * | lockSamples (char *file, int line) |
double | maximumAmplitude (int itmin=0, int itmax=0) const |
double | maximumAmplitudeAt (const TimeRange &r=TimeRange()) const |
MetaData * | metaData (int id) |
const MetaData * | metaData (int id) const |
const MetaDataMap & | metaDataMap () const |
const MiniSeedRecords & | miniSeedRecords () const |
QString | name () const |
QString | nameComponent () const |
void | normalizedCorrelation (const Signal *s1, const Signal *s2, double maxDelay) |
int | numberInFile () const |
int | offsetInFile () const |
bool | operator< (const Signal &o) const |
bool | operator== (const Signal &o) const |
bool | operator> (const Signal &o) const |
void | pickCoppens (const QString &pickName, double delta, double end, double start=0., bool relative=false, double mute=0.) |
void | pickMinMax (const QString &pickName, double from, double to, PickWhat what) |
bool | read (FILE *f, SignalDB *db) |
const Point & | receiver () const |
void | removeMetaData (int id) |
void | resetAmplitudes () const |
double | roundTimePick (const QString &name) const |
void | setAmplitudeUnit (AmplitudeUnits u) |
void | setByteIncrement (int i) |
void | setComments (QString c) |
void | setComponent (Components c) |
void | setCountPerVolt (double c) |
void | setDatabase (SignalDB *db) |
virtual void | setDeltaT (double newval) |
void | setFile (SignalFile *f) |
void | setGuralpRecords (const GuralpRecords &r) |
bool | setHeader (const MetaDataIndex &index, QVariant val) |
void | setHeaderModified (bool m) |
void | setId (int id) |
void | setMiniSeedRecords (const MiniSeedRecords &r) |
void | setName (QString n) |
virtual void | setNSamples (int n) |
void | setNumberInFile (int i) |
void | setOffsetInFile (int o) |
void | setReadOnlySamples (bool ro) |
void | setReceiver (const Point &p) |
void | setSource (const Point &p) |
void | setT0 (double t) |
void | setTemporary () |
void | setTimePick (const QString &name, double time) |
void | setTimeRange (const SparseTimeRange &r) |
void | setTimeReference (QDateTime t) |
void | setTimeReference (QString t) |
void | setUnitPerVolt (double c) |
void | setVoltPerCount (double c) |
void | setVoltPerUnit (double c) |
Signal (SignalDB *db) | |
Signal (const Signal &sig, SignalDB *db=0) | |
const Point & | source () const |
double | sourceReceiverAzimuth () const |
double | sourceReceiverDistance () const |
double | t0 () const |
TIME | t0AsTIME () const |
bool | taper (const TimeRange &tw, const TaperParameters ¶m) |
double | timePick (const QString &name) const |
int | timePickCount () const |
const SparseTimeRange & | timeRange () const |
QDateTime | timeReference () const |
QString | timeReferenceString () const |
double | unitPerCount () const |
double | unitPerVolt () const |
double | voltPerCount () const |
double | voltPerUnit () const |
bool | warnReadOnlySamples () const |
bool | writeAscii (QFile &f, int numInFile) const |
bool | writeGse (QFile &f) const |
bool | writeMiniSeed (QFile &f) const |
bool | writeSac (QDataStream &s) const |
bool | writeSeg2 (QFile &f) const |
bool | writeSegySu (QDataStream &s, int indexInFile, bool su) const |
virtual XMLMember | xml_member (XML_MEMBER_ARGS) |
virtual bool | xml_setProperty (XML_SETPROPERTY_ARGS) |
virtual const QString & | xml_tagName () const |
virtual void | xml_writeChildren (XML_WRITECHILDREN_ARGS) const |
virtual void | xml_writeProperties (XML_WRITEPROPERTIES_ARGS) const |
virtual | ~Signal () |
Static Public Member Functions | |
static QString | componentLetter (Components c) |
static Components | globalSeismographicNetworkComponent (const char *c) |
static Signal * | newCopy (Signal *sig) |
static AmplitudeUnits | standardAmplitudeUnit (QString u) |
static Components | standardComponent (QString c) |
static QString | standardName (Components c) |
static QString | standardName (AmplitudeUnits u) |
static AmplitudeUnits | userAmplitudeUnit (QString u) |
static Components | userComponent (QString c) |
static QString | userName (Components c) |
static QString | userName (AmplitudeUnits u) |
Static Public Attributes | |
static const QString | xmlSignalTag = "Signal" |
Protected Attributes | |
QMutex | _amplitudeMutex |
double | _averageAmplitude |
uint | _isHeaderModified:1 |
uint | _isReadOnlySamples:1 |
double | _maxAmplitude |
double | _t0 |
SparseTimeRange | _timeRange |
uint | _unused:30 |
A signal with samples in double precision with metadata (name, coordinates,...)
{Vertical, North, East, All, Horizontal, UndefinedComponent};
GeopsyCore::Signal::Signal | ( | SignalDB * | db | ) |
Construct a signal and add it to database db
References _isHeaderModified, _isReadOnlySamples, _t0, GeopsyCore::SignalDB::addSignal(), resetAmplitudes(), TRACE, Velocity, and Vertical.
Referenced by cut(), and newCopy().
: DoubleSignal (), SharedObject(), XMLClass(), _timeReference(QDate(2000, 1, 1), QTime(0, 0, 0)) { TRACE; _id=0; _t0=0; _component=Vertical; _countPerVolt=1.0; _voltPerUnit=1.0; _amplitudeUnit=Velocity; _numberInFile=-1; _file=0; _offsetInFile=0; _byteIncrement=0; _isReadOnlySamples=false; _isHeaderModified=false; resetAmplitudes(); _db=db; _db->addSignal(this); // _id is automatically set here }
GeopsyCore::Signal::Signal | ( | const Signal & | p, |
SignalDB * | db = 0 |
||
) |
Create a temporary copy of original This signal will be deleted once the last subpool containing it will be deleted. Samples are not copied.
References GeopsyCore::SignalDB::addSignal(), copyBasicProperties(), resetAmplitudes(), setTemporary(), and TRACE.
: DoubleSignal (p), SharedObject(), XMLClass() { TRACE; copyBasicProperties(p); resetAmplitudes(); if(db) _db=db; else _db=p._db; _db->addSignal(this); // _id is automatically set here setTemporary(); }
GeopsyCore::Signal::~Signal | ( | ) | [virtual] |
References GeopsyCore::MetaDataMap::clear(), QGpCoreTools::SharedObject::referenceCount(), GeopsyCore::SignalDB::signalDeleted(), and TRACE.
{ TRACE; ASSERT(!_db || referenceCount()<=0); // When the database is deleted, all signals are forced to be deleted. _optionalData.clear(); if(_db) _db->signalDeleted(this); }
int GeopsyCore::Signal::add | ( | const Signal * | sig, |
const TimeRange & | tw, | ||
bool | checkInvalid = false , |
||
double | invalidValue = 1e99 |
||
) | [inline] |
References GeopsyCore::TimeRange::lengthSeconds(), GeopsyCore::TimeRange::start(), t0(), and TRACE.
Referenced by StructureStationSignals::organizeSubPool(), and GeopsyGui::ChronogramLayer::rangeUpdate().
{ TRACE; return DoubleSignal::add(sig, tw.start() - sig->t0(), tw.start() - t0(), tw.lengthSeconds(), checkInvalid, invalidValue); }
void GeopsyCore::Signal::addMetaData | ( | MetaData * | d | ) | [inline] |
Referenced by MatFormat::load().
{_optionalData.add(d);}
double GeopsyCore::Signal::amplitudeAt | ( | double | abscissa | ) | const [inline] |
Returns the amplitude of the signal at time or frequency abscissa (depends upon signal type). The index is rounded to the lowest sample. No interpolation is perfomed.
Reimplemented from GeopsyCore::DoubleSignal.
References _t0, GeopsyCore::DoubleSignal::_type, TRACE, and GeopsyCore::DoubleSignal::Waveform.
Referenced by GeopsyGui::PickLayer::mouseMoveEvent().
{ TRACE; if(_type==Waveform) return DoubleSignal::amplitudeAt(abscissa - _t0); else return DoubleSignal::amplitudeAt(abscissa); }
AmplitudeUnits GeopsyCore::Signal::amplitudeUnit | ( | ) | const [inline] |
Referenced by compare(), and writeSac().
{return _amplitudeUnit;}
QString GeopsyCore::Signal::amplitudeUnitStandardName | ( | ) | const [inline] |
Referenced by GeopsyCore::SignalHeaderObject::amplitudeUnit(), and xml_writeProperties().
{return standardName(_amplitudeUnit);}
QString GeopsyCore::Signal::amplitudeUnitUserName | ( | ) | const [inline] |
double GeopsyCore::Signal::averageAmplitude | ( | int | itmin = 0 , |
int | itmax = 0 |
||
) | const |
Returns the average amplitude and store it in _averageAmplitude if itmin==0 and itmax==nSamples()-1 If itmin==itmax==0, it returns directly _averageAmplitude without re-checking it.
Reimplemented from GeopsyCore::DoubleSignal.
References _amplitudeMutex, _averageAmplitude, and TRACE.
Referenced by GeopsyCore::SignalHeaderObject::averageAmplitude(), compare(), GeopsyGui::SignalLayer::drawSignal(), and header().
{ TRACE; // Better if amplitude mutex is not locked while signal mutex is blocked // A special case was encountered with DynamicSignal::set() and a drawing thread active // at the same moment. if(itmin==0 && itmax==0) { QMutexLocker ml(&_amplitudeMutex); if(_averageAmplitude!=1e99) return _averageAmplitude; itmax=_nSamples-1; } double v=DoubleSignal::averageAmplitude(itmin, itmax); if(itmin <= 0 && itmax >= _nSamples-1) { QMutexLocker ml(&_amplitudeMutex); _averageAmplitude=v; } return v; }
int GeopsyCore::Signal::byteIncrement | ( | ) | const [inline] |
Referenced by xml_writeProperties().
{return _byteIncrement;}
QString GeopsyCore::Signal::comments | ( | ) | const [inline] |
References metaData(), GeopsyCore::Comments::staticId(), and GeopsyCore::MetaString::value().
Referenced by SignalTableItem::data().
{ // Comments is always available in MetaDataFactory, hence o is never null const Comments * o=static_cast<const Comments *>(metaData(Comments::staticId())); return o->value(); }
int GeopsyCore::Signal::compare | ( | const Signal & | o | ) | const |
References GeopsyCore::MetaDataFactory::AmplitudeUnit, amplitudeUnit(), GeopsyCore::SortKey::at(), GeopsyCore::MetaDataFactory::AverageAmplitude, averageAmplitude(), GeopsyCore::MetaData::compare(), GeopsyCore::MetaDataFactory::Component, component(), GeopsyCore::SortKey::count(), GeopsyCore::MetaDataFactory::CountPerUnit, countPerUnit(), GeopsyCore::MetaDataFactory::CountPerVolt, countPerVolt(), GeopsyCore::MetaDataFactory::DataCount, GeopsyCore::SignalTemplate< double >::dataSizeMb(), GeopsyCore::DoubleSignal::deltaT(), GeopsyCore::MetaDataFactory::DeltaT, GeopsyCore::MetaDataFactory::Dummy, GeopsyCore::DoubleSignal::duration(), GeopsyCore::MetaDataFactory::Duration, GeopsyCore::MetaDataFactory::EndTime, endTime(), file(), GeopsyCore::MetaDataFactory::FileFormat, GeopsyCore::MetaDataFactory::FileName, GeopsyCore::MetaDataFactory::FileNumber, GeopsyCore::SignalDB::filePool(), GeopsyCore::SignalFile::format(), GeopsyCore::MetaDataFactory::HeaderModified, GeopsyCore::MetaDataIndex::id(), GeopsyCore::MetaDataFactory::ID, GeopsyCore::MetaDataIndex::index(), GeopsyCore::SignalFilePool::indexOf(), isHeaderModified(), GeopsyCore::MetaDataFactory::IsOriginalFile, isOriginalFile(), GeopsyCore::MetaDataFactory::MaximumAmplitude, maximumAmplitude(), metaData(), GeopsyCore::SignalFile::name(), GeopsyCore::MetaDataFactory::Name, name(), GeopsyCore::SignalTemplate< double >::nSamples(), GeopsyCore::MetaDataFactory::NSamples, GeopsyCore::MetaDataFactory::NumberInFile, numberInFile(), GeopsyCore::MetaDataFactory::Pointer, receiver(), GeopsyCore::MetaDataFactory::ReceiverX, GeopsyCore::MetaDataFactory::ReceiverY, GeopsyCore::MetaDataFactory::ReceiverZ, GeopsyCore::SortKey::reversed(), SAFE_UNINITIALIZED, GeopsyCore::MetaDataFactory::SampleSize, GeopsyCore::DoubleSignal::samplingFrequency(), GeopsyCore::MetaDataFactory::SamplingFrequency, GeopsyCore::MetaDataFactory::ShortFileName, GeopsyCore::SignalFile::shortName(), SIGNAL_COMPARE, SIGNAL_COMPARE_KERNEL, SIGNAL_COMPARE_STRING, source(), GeopsyCore::MetaDataFactory::SourceReceiverAzimuth, sourceReceiverAzimuth(), GeopsyCore::MetaDataFactory::SourceReceiverDistance, sourceReceiverDistance(), GeopsyCore::MetaDataFactory::SourceReceiverRoughAzimuth, GeopsyCore::MetaDataFactory::SourceX, GeopsyCore::MetaDataFactory::SourceY, GeopsyCore::MetaDataFactory::SourceZ, GeopsyCore::MetaDataIndex::subId(), GeopsyCore::MetaDataFactory::T0, t0(), GeopsyCore::MetaDataFactory::TimeReference, timeReference(), GeopsyCore::SignalFileFormat::toString(), TRACE, GeopsyCore::DoubleSignal::type(), GeopsyCore::MetaDataFactory::Type, GeopsyCore::MetaDataFactory::UnitPerCount, unitPerCount(), GeopsyCore::MetaDataFactory::UnitPerVolt, unitPerVolt(), GeopsyCore::MetaDataFactory::VoltPerCount, voltPerCount(), GeopsyCore::MetaDataFactory::VoltPerUnit, voltPerUnit(), and QGpCoreTools::XMLClass::xml_tagName().
Referenced by ToolLinearFKActive::initStations(), and ShotRecord::organizeSubPool().
{ TRACE; #define SIGNAL_COMPARE_KERNEL \ if(n1 < n2) comp=-1; \ else if(n1 > n2) comp=1; \ else continue; \ break; #define SIGNAL_COMPARE(type, function) \ { \ type n1=function; \ type n2=o.function; \ SIGNAL_COMPARE_KERNEL \ } #define SIGNAL_COMPARE_STRING(function) \ { \ QString n1=function; \ QString n2=o.function; \ comp=n1.localeAwareCompare(n2); \ if(comp==0) continue; \ break; \ } int n=SortKey::count(); for(int i=0; i<n; i++) { const SortKey& k=SortKey::at(i); int comp; SAFE_UNINITIALIZED(comp,0); // Standard meta data if(k.id()<MetaDataFactory::DataCount) { switch (k.id()) { case MetaDataFactory::ID: SIGNAL_COMPARE(int, id()) case MetaDataFactory::T0: SIGNAL_COMPARE(double, t0()) case MetaDataFactory::DeltaT: SIGNAL_COMPARE(double, deltaT()) case MetaDataFactory::NSamples: SIGNAL_COMPARE(int, nSamples()) case MetaDataFactory::SourceX: SIGNAL_COMPARE(double, source().x()) case MetaDataFactory::SourceY: SIGNAL_COMPARE(double, source().y()) case MetaDataFactory::SourceZ: SIGNAL_COMPARE(double, source().z()) case MetaDataFactory::ReceiverX: SIGNAL_COMPARE(double, receiver().x()) case MetaDataFactory::ReceiverY: SIGNAL_COMPARE(double, receiver().y()) case MetaDataFactory::ReceiverZ: SIGNAL_COMPARE(double, receiver().z()) case MetaDataFactory::Name: SIGNAL_COMPARE_STRING(name()) case MetaDataFactory::Type: SIGNAL_COMPARE(int, type()) case MetaDataFactory::FileNumber: { SignalFilePool& filePool=_db ->filePool(); int n1=filePool.indexOf(file()); int n2=filePool.indexOf(o.file()); SIGNAL_COMPARE_KERNEL } case MetaDataFactory::NumberInFile: SIGNAL_COMPARE(int , numberInFile()) case MetaDataFactory::TimeReference : SIGNAL_COMPARE(QDateTime , timeReference()) case MetaDataFactory::FileName: { QString n1=file() ? file()->name() : QString::null; QString n2=o.file() ? o.file()->name() : QString::null; comp=n1.localeAwareCompare(n2); if(comp==0) continue; break; } case MetaDataFactory::FileFormat: { QString n1=file() ? file()->format().toString() : QString::null; QString n2=o.file() ? o.file()->format().toString() : QString::null; comp=n1.localeAwareCompare(n2); if(comp==0) continue; break; } case MetaDataFactory::ShortFileName: { QString n1=file() ? file()->shortName() : QString::null; QString n2=o.file() ? o.file()->shortName() : QString::null; comp=n1.localeAwareCompare(n2); if(comp==0) continue; break; } case MetaDataFactory::Duration: SIGNAL_COMPARE(double, duration()) case MetaDataFactory::EndTime: SIGNAL_COMPARE(double, endTime()) case MetaDataFactory::Component: SIGNAL_COMPARE(int, component()) case MetaDataFactory::MaximumAmplitude: SIGNAL_COMPARE(double, maximumAmplitude()) case MetaDataFactory::AverageAmplitude: SIGNAL_COMPARE(double, averageAmplitude()) case MetaDataFactory::IsOriginalFile: SIGNAL_COMPARE(int, isOriginalFile() ? 0 : 1) case MetaDataFactory::SamplingFrequency: SIGNAL_COMPARE(double, samplingFrequency()) case MetaDataFactory::Pointer: if(this < &o) comp=-1; else if(this > &o) comp=1; else continue; break; case MetaDataFactory::CountPerVolt: SIGNAL_COMPARE(double, countPerVolt()) case MetaDataFactory::VoltPerCount: SIGNAL_COMPARE(double, voltPerCount()) case MetaDataFactory::VoltPerUnit: SIGNAL_COMPARE(double, voltPerUnit()) case MetaDataFactory::UnitPerVolt: SIGNAL_COMPARE(double, unitPerVolt()) case MetaDataFactory::CountPerUnit: SIGNAL_COMPARE(double, countPerUnit()) case MetaDataFactory::UnitPerCount: SIGNAL_COMPARE(double, unitPerCount()) case MetaDataFactory::AmplitudeUnit: SIGNAL_COMPARE(int, amplitudeUnit()) case MetaDataFactory::SampleSize: SIGNAL_COMPARE(double, dataSizeMb()) case MetaDataFactory::HeaderModified: SIGNAL_COMPARE(bool, isHeaderModified()) case MetaDataFactory::SourceReceiverDistance: SIGNAL_COMPARE(double, sourceReceiverDistance()) case MetaDataFactory::SourceReceiverAzimuth: SIGNAL_COMPARE(double, sourceReceiverAzimuth()) case MetaDataFactory::SourceReceiverRoughAzimuth: { // Return equal azimuth if diff less than 90 if(sourceReceiverDistance()==0.0 || o.sourceReceiverDistance()==0.0) { continue; } else { double n1=sourceReceiverAzimuth(); double n2=o.sourceReceiverAzimuth(); if(fabs(n2-n1)<0.5*M_PI || fabs(n2-n1)>1.5*M_PI) continue; else if(n1<1.5*M_PI && n1>0.5*M_PI && (n2>1.5*M_PI || n2<0.5*M_PI)) comp=-1; else if(n1>M_PI && n2<M_PI) comp=-1; else comp=1; } break; } case MetaDataFactory::Dummy: // Not comparable members case MetaDataFactory::DataCount: continue; } } else { // Optional meta data const MetaData * d1=metaData(k.id()); const MetaData * d2; if(d1) { d2=o.metaData(k.id()); ASSERT(d2 && d1->xml_tagName()==d2->xml_tagName()); } else { continue; } comp=d1->compare(k.subId(), k.index(), d2); if(comp==0) continue; } if(k.reversed()) { return -comp; } else { return comp; } } return 0; }
Components GeopsyCore::Signal::component | ( | ) | const [inline] |
Referenced by GeopsyCore::StationList::addSignal(), GeopsyCore::StationSignals::addSignal(), GeopsyCore::SubSignalPool::associate3Components(), compare(), GeopsyCore::StationSignals::component(), correlation(), GeopsyCore::SubSignalPool::mergeStations(), nameComponent(), normalizedCorrelation(), MonoStation::SpectrumStationSignals::organizeSubPool(), GeopsyCore::SubSignalPool::remove(), Process::run(), SpectrumStation::save(), MapWindow::subPoolUpdate(), writeGse(), writeMiniSeed(), and writeSac().
{return _component;}
QString GeopsyCore::Signal::componentLetter | ( | Components | c | ) | [static] |
References All, East, Horizontal, North, QGpCoreTools::tr(), TRACE, and Vertical.
Referenced by debugName(), nameComponent(), MapWindow::subPoolUpdate(), and writeSac().
QString GeopsyCore::Signal::componentStandardName | ( | ) | const [inline] |
Referenced by GeopsyCore::SignalHeaderObject::component(), and xml_writeProperties().
{return standardName(_component);}
QString GeopsyCore::Signal::componentUserName | ( | ) | const [inline] |
Referenced by GeopsyCore::StationList::addSignal(), GeopsyGui::ChronogramLayer::exportGaps(), and header().
{return userName(_component);}
const double * GeopsyCore::Signal::constLockSamples | ( | ) | const [virtual] |
Reimplemented from GeopsyCore::SignalTemplate< double >.
References GeopsyCore::GeopsyCoreEngine::cache(), file(), GeopsyCore::geopsyCore, GeopsyCore::SignalTemplate< double >::isAllocated(), QGpCoreTools::Cache::makeAvailable(), GeopsyCore::SignalTemplate< double >::samples(), and TRACE.
Referenced by GeopsyCore::SubSignalPool::subtractSignal().
{ TRACE; lockData(); if(isAllocated()) { return samples(); } if(isSaved() || !file()) { if(geopsyCore->cache()->makeAvailable(this)) { return samples(); } else { unlockData(); return 0; } } if(geopsyCore->cache()->makeAvailable(this)) { load(samples()); return samples(); } else { unlockData(); return 0; } }
const double* GeopsyCore::Signal::constLockSamples | ( | char * | file, |
int | line | ||
) | const [inline] |
Reimplemented from GeopsyCore::SignalTemplate< double >.
References GeopsyCore::SignalTemplate< double >::constLockSamples().
{return DoubleSignal::constLockSamples(file, line);}
void GeopsyCore::Signal::copyBasicProperties | ( | const Signal & | p | ) |
References _t0, _timeRange, and TRACE.
Referenced by Signal().
{ TRACE; _timeReference=o._timeReference; _t0=o._t0; _timeRange=o._timeRange; _receiver=o._receiver; _source=o._source; _name=o._name; _component=o._component; _countPerVolt=o._countPerVolt; _voltPerUnit=o._voltPerUnit; _amplitudeUnit=o._amplitudeUnit; _optionalData=o._optionalData; }
void GeopsyCore::Signal::copySamplesFrom | ( | const Signal * | sig | ) | [inline] |
void GeopsyCore::Signal::copySamplesFrom | ( | const Signal * | sig, |
const TimeRange & | tw | ||
) | [inline] |
References copySamplesFrom(), GeopsyCore::TimeRange::lengthSeconds(), GeopsyCore::TimeRange::start(), t0(), and TRACE.
{ TRACE; DoubleSignal::copySamplesFrom(sig, tw.start()-sig->t0(), tw.start()-t0(), tw.lengthSeconds()); }
double GeopsyCore::Signal::correlation | ( | const Signal * | sig, |
const TimeRange & | tw | ||
) | [inline] |
References GeopsyCore::TimeRange::lengthSeconds(), GeopsyCore::TimeRange::start(), t0(), and TRACE.
Referenced by GeopsyCore::SubSignalPool::correlations(), and T0Correlation::value().
{ TRACE; return DoubleSignal::correlation(sig, tw.start() - sig->t0(), tw.start() - t0(), tw.lengthSeconds()); }
void GeopsyCore::Signal::correlation | ( | const Signal * | s1, |
const Signal * | s2, | ||
double | maxDelay | ||
) |
Correlates signal s1 to s2 and saves results in this signal. If this signal has the correct number of samples and the correct sampling frequency, the value of this signal are not cleaned and the results are stacked on existing values. If not, the signal is initialized with 0.
References component(), GeopsyCore::DoubleSignal::correlation(), GeopsyCore::DoubleSignal::deltaT(), QGpCoreTools::Point::distanceTo(), QGpCoreTools::endl(), name(), nameComponent(), GeopsyCore::SignalTemplate< double >::nSamples(), receiver(), setComponent(), setName(), setReceiver(), setT0(), GeopsyCore::DoubleSignal::setType(), t0(), QGpCoreTools::tr(), TRACE, UndefinedComponent, and GeopsyCore::DoubleSignal::Waveform.
{ TRACE; if(!DoubleSignal::correlation(s1, s2, maxDelay)) { App::stream() << tr("Error calculating correlation between signals %1 and %2, probably an allocation error") .arg(s1->nameComponent()).arg(s2->nameComponent()) << endl; } // Change t0 according to tw and set x as the interdistance, name is the compound of both name // Use the effective maxDelay (given by signal lenght) maxDelay=(nSamples()-1)*deltaT()*0.5; setT0(-maxDelay+s1->t0()-s2->t0()); // Adjust for differences in T0 (not sure if it is the correct direction) setReceiver(Point(s1->receiver().distanceTo(s2->receiver()), 0.0, 0.0)); if(s1->component()==s2->component()) { setName(s1->name() + " & " + s2->name()); setComponent(s1->component()); } else { setName(s1->nameComponent() + " & " + s2->nameComponent()); setComponent(UndefinedComponent); } setType(Waveform); }
double GeopsyCore::Signal::countPerUnit | ( | ) | const [inline] |
Referenced by compare(), GeopsyCore::SignalHeaderObject::countPerUnit(), header(), writeGse(), writeMiniSeed(), writeSac(), and writeSegySu().
{return _countPerVolt * _voltPerUnit;}
double GeopsyCore::Signal::countPerVolt | ( | ) | const [inline] |
Referenced by compare(), GeopsyCore::SignalHeaderObject::countPerVolt(), header(), writeSac(), and xml_writeProperties().
{return _countPerVolt;}
Signal * GeopsyCore::Signal::cut | ( | TimeRange | r | ) | const |
Creates a new signal on range r. If the range of this signal and r do not match, null is returned. If r limits do not match with signal sampling, range is rounded to first and last sample included in range r.
References copySamplesFrom(), GeopsyCore::DoubleSignal::deltaT(), GeopsyCore::TimeRange::end(), GeopsyCore::TimeRange::intersection(), GeopsyCore::TimeRange::lengthSamples(), GeopsyCore::TimeRange::lengthSeconds(), GeopsyCore::SparseTimeRange::range(), GeopsyCore::TimeRange::setEnd(), setNSamples(), GeopsyCore::TimeRange::setStart(), setT0(), setTimeRange(), Signal(), GeopsyCore::TimeRange::start(), t0(), timeRange(), and TRACE.
Referenced by GeopsyCore::SubSignalPool::cut(), and Process::run().
{ TRACE; // Find the intersection with the this time range // rthis has always a limits compatible with sampling TimeRange rthis=timeRange().range(); r=r.intersection(rthis); // Adjust start of r to match sig sampling double roundedStart=(r.start()-t0())/deltaT(); if(roundedStart<0.0) { r.setStart(t0()); } else { double sampleFrac=roundedStart-floor(roundedStart); if(sampleFrac>1e-7) { // 1/10000000 of sampling period precision r.setStart(t0()+ceil(roundedStart)*deltaT()); int n=r.lengthSamples(deltaT()); if(r.start()+n*deltaT()>r.end()) { // Check if rounding to sampling period passes over the end of range // If so, remove one sample. r.setEnd(r.start()+(n-1)*deltaT()); } } } // If not null, extract the cut signal if(r.lengthSeconds()>0.0) { Signal * newSig=new Signal(*this); newSig->setT0(r.start()); newSig->setNSamples(r.lengthSamples(deltaT())); newSig->setTimeRange(timeRange()); newSig->copySamplesFrom(this, r); return newSig; } else { return 0; } }
SignalDB* GeopsyCore::Signal::database | ( | ) | const [inline] |
Referenced by GeopsyCore::SignalDB::addSignal(), header(), GeopsyCore::XMLSignal::xml_writeBinaryData(), and GeopsyCore::XMLSignal::xml_writeProperties().
{return _db;}
QString GeopsyCore::Signal::debugName | ( | ) | const [inline, virtual] |
References componentLetter(), and TRACE.
{ TRACE; return _name + "_" + componentLetter(_component) + QString::number(_id); }
QString GeopsyCore::Signal::effectiveAmplitudeUnit | ( | ) | const |
Returns the name of the units for amplitude depends upon the availability of countPerVolt() and voltPerUnit() (these values must be different than 1).
References Acceleration, CustomUnit, Displacement, QGpCoreTools::tr(), TRACE, UndefinedUnit, and Velocity.
Referenced by SignalViewer::setSignals(), and GraphicWindow::updateLabels().
{ TRACE; if(_voltPerUnit!=1.0) { switch (_amplitudeUnit) { case UndefinedUnit: return QObject::tr("Undefined"); case Displacement: return QObject::tr("m"); case Velocity: return QObject::tr("m/s"); case Acceleration: return QObject::tr("m/s^2"); case CustomUnit: return QObject::tr("Custom unit"); } } else if(_countPerVolt!=1.0) { return QObject::tr("Volts"); } return QObject::tr("Counts"); }
double GeopsyCore::Signal::endTime | ( | ) | const [inline] |
Referenced by compare(), GeopsyGui::TimeRangeParameterWidget::getParameters(), header(), GeopsyCore::StationSignals::maxTime(), GeopsyGui::TimeRangeParameterWidget::on_toType_activated(), Process::run(), GeopsySLink::SeedLink::run(), GeopsySLink::SeedLinkStream::set(), setDeltaT(), and setNSamples().
TIME GeopsyCore::Signal::endTimeAsTIME | ( | ) | const [inline] |
{return DateTime::capAddSecs(_timeReference, endTime());}
SignalFile* GeopsyCore::Signal::file | ( | ) | const [inline] |
Referenced by GeopsyCore::SubSignalPool::addFile(), compare(), constLockSamples(), header(), MatFormat::load(), lockSamples(), Process::run(), MonoStation::AbstractStation::shortFileName(), GeopsyCore::XMLSignal::xml_writeBinaryData(), and GeopsyCore::XMLSignal::xml_writeProperties().
{return _file;}
Signal::Components GeopsyCore::Signal::globalSeismographicNetworkComponent | ( | const char * | c | ) | [static] |
is
a tree-letter code from Global Seismographic Network naming convention for recording channels. This code is based on Seed manual appendix A (http://www.iris.edu/manuals/SEED_appA.htm).
If a geopsy component can be deduced, returned value is something else than UndefinedComponent.
References East, North, TRACE, UndefinedComponent, and Vertical.
{ TRACE; if(strlen(c)!=3) { return UndefinedComponent; } // First letter, Band Code switch(c[0]) { case 'F': // sample rate=[1000, 5000[ Hz, corner period >= 10 sec case 'G': // sample rate=[1000, 5000[ Hz, corner period < 10 sec case 'D': // sample rate=[250, 1000[ Hz, corner period >= 10 sec case 'C': // sample rate=[250, 1000[ Hz, corner period < 10 sec case 'E': // Extremely Short Period sample rate=[80, 250[ Hz, corner period < 10 sec case 'S': // Short Period sample rate=[10, 80[ Hz, corner period < 10 sec case 'H': // High Broad Band sample rate=[80, 250[ Hz, corner period >= 10 sec case 'B': // Broad Band sample rate=[10, 80[ Hz, corner period >= 10 sec case 'M': // Mid Period sample rate=]1, 10[ Hz case 'L': // Long Period sample rate=1 Hz case 'V': // Very Long Period sample rate=0.1 Hz case 'U': // Ultra Long Period sample rate=0.01 Hz case 'R': // Extremely Long Period sample rate=0.001 Hz case 'P': // On the order of 0.1 to 1 day sample rate=[0.00001, 0.0001[ case 'T': // On the order of 1 to 10 days sample rate=[0.000001, 0.00001[ case 'Q': // Greater than 10 days sample rate<0.000001 case 'A': // Administrative Instrument Channel case 'O': // Opaque Instrument Channel break; default: return UndefinedComponent; } // Second and third letters, Instrument Code and Orientation Code // Only seismometers and geophones are recognized switch(c[1]) { case 'H': // High Gain Seismometer case 'L': // Low Gain Seismometer case 'G': // Gravimeter case 'M': // Mass Position Seismometer case 'N': // Accelerometer case 'P': // Geophone switch(c[2]) { case 'Z': return Vertical; case 'N': return North; case 'E': return East; default: break; } break; default: break; } return UndefinedComponent; }
const GuralpRecords & GeopsyCore::Signal::guralpRecords | ( | ) | const [inline] |
References metaData(), and GeopsyCore::GuralpRecords::staticId().
{ // GuralpRecords is always available in MetaDataFactory, hence o is never null const GuralpRecords * o=static_cast<const GuralpRecords *>(metaData(GuralpRecords::staticId())); return *o; }
bool GeopsyCore::Signal::hasMetaData | ( | int | id | ) | const [inline] |
{return _optionalData.hasData(id);}
QVariant GeopsyCore::Signal::header | ( | const MetaDataIndex & | index | ) | const |
References GeopsyCore::MetaDataFactory::AmplitudeUnit, amplitudeUnitUserName(), GeopsyCore::MetaDataFactory::AverageAmplitude, averageAmplitude(), GeopsyCore::MetaDataFactory::Component, componentUserName(), GeopsyCore::MetaDataFactory::CountPerUnit, countPerUnit(), GeopsyCore::MetaDataFactory::CountPerVolt, countPerVolt(), GeopsyCore::MetaData::data(), database(), GeopsyCore::MetaDataFactory::DataCount, GeopsyCore::SignalTemplate< double >::dataSizeMb(), GeopsyCore::DoubleSignal::deltaT(), GeopsyCore::MetaDataFactory::DeltaT, GeopsyCore::MetaDataFactory::Dummy, GeopsyCore::DoubleSignal::duration(), GeopsyCore::MetaDataFactory::Duration, GeopsyCore::MetaDataFactory::EndTime, endTime(), file(), GeopsyCore::MetaDataFactory::FileFormat, GeopsyCore::MetaDataFactory::FileName, GeopsyCore::MetaDataFactory::FileNumber, GeopsyCore::SignalDB::filePool(), GeopsyCore::SignalFile::format(), GeopsyCore::MetaDataFactory::HeaderModified, GeopsyCore::MetaDataIndex::id(), GeopsyCore::MetaDataFactory::ID, id(), GeopsyCore::MetaDataIndex::index(), GeopsyCore::SignalFilePool::indexOf(), isHeaderModified(), GeopsyCore::MetaDataFactory::IsOriginalFile, isOriginalFile(), GeopsyCore::MetaDataFactory::MaximumAmplitude, maximumAmplitude(), metaData(), GeopsyCore::SignalFile::name(), GeopsyCore::MetaDataFactory::Name, name(), GeopsyCore::SignalTemplate< double >::nSamples(), GeopsyCore::MetaDataFactory::NSamples, GeopsyCore::MetaDataFactory::NumberInFile, numberInFile(), GeopsyCore::MetaDataFactory::Pointer, receiver(), GeopsyCore::MetaDataFactory::ReceiverX, GeopsyCore::MetaDataFactory::ReceiverY, GeopsyCore::MetaDataFactory::ReceiverZ, GeopsyCore::MetaDataFactory::SampleSize, GeopsyCore::MetaDataFactory::SamplingFrequency, GeopsyCore::MetaDataFactory::ShortFileName, GeopsyCore::SignalFile::shortName(), source(), GeopsyCore::MetaDataFactory::SourceReceiverAzimuth, sourceReceiverAzimuth(), GeopsyCore::MetaDataFactory::SourceReceiverDistance, sourceReceiverDistance(), GeopsyCore::MetaDataFactory::SourceReceiverRoughAzimuth, GeopsyCore::MetaDataFactory::SourceX, GeopsyCore::MetaDataFactory::SourceY, GeopsyCore::MetaDataFactory::SourceZ, GeopsyCore::MetaDataIndex::subId(), GeopsyCore::MetaDataFactory::T0, t0(), GeopsyCore::MetaDataFactory::TimeReference, timeReferenceString(), GeopsyCore::SignalFileFormat::toString(), QGpCoreTools::tr(), TRACE, GeopsyCore::DoubleSignal::type(), GeopsyCore::MetaDataFactory::Type, GeopsyCore::DoubleSignal::typeString(), GeopsyCore::MetaDataFactory::UnitPerCount, unitPerCount(), GeopsyCore::MetaDataFactory::UnitPerVolt, unitPerVolt(), GeopsyCore::MetaDataFactory::VoltPerCount, voltPerCount(), GeopsyCore::MetaDataFactory::VoltPerUnit, voltPerUnit(), QGpCoreTools::Point2D::x(), QGpCoreTools::Point2D::y(), and QGpCoreTools::Point::z().
Referenced by GeopsyMainWindow::createNewGroup(), SignalTableItem::data(), GeopsyCore::SubSignalPool::exportTable(), GeopsyCore::SignalProcess::headerCore(), SignalTableItem::setData(), GeopsyCore::SignalExpression::value(), and writeGse().
{ TRACE; if(index.id()<MetaDataFactory::DataCount) { switch (index.id()) { case MetaDataFactory::ID: return id(); case MetaDataFactory::T0: return t0(); case MetaDataFactory::DeltaT: return deltaT(); case MetaDataFactory::NSamples: return nSamples(); case MetaDataFactory::Duration: return duration(); case MetaDataFactory::EndTime: return endTime(); case MetaDataFactory::ReceiverX: return receiver().x(); case MetaDataFactory::ReceiverY: return receiver().y(); case MetaDataFactory::ReceiverZ: return receiver().z(); case MetaDataFactory::SourceX: return source().x(); case MetaDataFactory::SourceY: return source().y(); case MetaDataFactory::SourceZ: return source().z(); case MetaDataFactory::Name: return name(); case MetaDataFactory::Component: return componentUserName(); case MetaDataFactory::Type: return typeString(type()); case MetaDataFactory::FileNumber: { return database()->filePool().indexOf(file()); } case MetaDataFactory::FileName: if(file()) return file() ->name(); else return tr("### Temporary signal ###"); case MetaDataFactory::ShortFileName: if(file()) return file() ->shortName(); else return tr("### Temporary signal ###"); case MetaDataFactory::FileFormat: if(file()) return file()->format().toString(); else return tr("### Temporary signal ###"); case MetaDataFactory::NumberInFile: return numberInFile(); case MetaDataFactory::TimeReference: return timeReferenceString(); case MetaDataFactory::MaximumAmplitude: return maximumAmplitude(); case MetaDataFactory::AverageAmplitude: return averageAmplitude(); case MetaDataFactory::IsOriginalFile: if(file() && file() ->isOriginalFile()) return tr("Original"); else return tr("Processed"); case MetaDataFactory::SamplingFrequency: return 1.0/deltaT(); case MetaDataFactory::Pointer: return QString::number((long) this, 16); case MetaDataFactory::CountPerVolt: return countPerVolt(); case MetaDataFactory::VoltPerCount: return voltPerCount(); case MetaDataFactory::VoltPerUnit: return voltPerUnit(); case MetaDataFactory::UnitPerVolt: return unitPerVolt(); case MetaDataFactory::CountPerUnit: return countPerUnit(); case MetaDataFactory::UnitPerCount: return unitPerCount(); case MetaDataFactory::AmplitudeUnit: return amplitudeUnitUserName(); case MetaDataFactory::SampleSize: return dataSizeMb(); case MetaDataFactory::HeaderModified: return isHeaderModified(); case MetaDataFactory::SourceReceiverDistance: return sourceReceiverDistance(); case MetaDataFactory::SourceReceiverAzimuth: case MetaDataFactory::SourceReceiverRoughAzimuth: return Angle::mathToGeographic(sourceReceiverAzimuth()); case MetaDataFactory::Dummy: return "####"; case MetaDataFactory::DataCount: break; } } else { const MetaData * d=metaData(index.id()); if(d) { return d->data(index.subId(), index.index()); } } return QVariant(); }
int GeopsyCore::Signal::id | ( | ) | const [inline] |
Referenced by GeopsyCore::StationSignals::addSignal(), StructureStationSignals::addSignals(), GeopsyCore::SubSignalPool::debugSignalSharing(), geopsyToFile(), header(), GeopsyCore::SignalHeaderObject::id(), MatFormat::load(), GeopsyCore::SignalFile::loadGeopsySignal(), MonoStation::SpectrumStationSignals::organizeSubPool(), StructureStation::save(), GeopsyCore::SignalDB::signal(), GeopsyCore::SignalDB::xml_polish(), and GeopsyCore::XMLSignal::xml_writeProperties().
{return _id;}
bool GeopsyCore::Signal::isHeaderModified | ( | ) | const [inline] |
Referenced by compare(), header(), and GeopsyCore::SignalHeaderObject::headerModified().
{return _isHeaderModified;}
bool GeopsyCore::Signal::isOriginalFile | ( | ) | const [inline] |
References isOriginalFile().
Referenced by compare(), header(), GeopsyCore::SignalHeaderObject::isOriginalFile(), and isOriginalFile().
{if(file() && file() ->isOriginalFile()) return true; else return false;}
bool GeopsyCore::Signal::isReadOnlySamples | ( | ) | const [inline] |
{return _isReadOnlySamples;}
double * GeopsyCore::Signal::lockSamples | ( | ) | [virtual] |
General function to be called before using the samples.
Reimplemented from GeopsyCore::SignalTemplate< double >.
References GeopsyCore::GeopsyCoreEngine::cache(), file(), GeopsyCore::geopsyCore, GeopsyCore::SignalTemplate< double >::isAllocated(), QGpCoreTools::Cache::makeAvailable(), GeopsyCore::SignalTemplate< double >::samples(), and TRACE.
{ TRACE; lockData(); if(isAllocated()) { return samples(); } if(isSaved() || !file()) { if(geopsyCore->cache()->makeAvailable(this)) { return samples(); } else { unlockData(); return 0; } } if(geopsyCore->cache()->makeAvailable(this)) { load(samples()); return samples(); } else { unlockData(); return 0; } }
double* GeopsyCore::Signal::lockSamples | ( | char * | file, |
int | line | ||
) | [inline] |
Reimplemented from GeopsyCore::SignalTemplate< double >.
References GeopsyCore::SignalTemplate< double >::lockSamples().
{return DoubleSignal::lockSamples(file, line);}
double GeopsyCore::Signal::maximumAmplitude | ( | int | itmin = 0 , |
int | itmax = 0 |
||
) | const |
Returns the maximum amplitude and store it in _maxAmplitude if itmin==0 and itmax==nSamples()-1 If itmin==itmax==0, it returns directly _maxAmplitude without re-checking it.
Reimplemented from GeopsyCore::DoubleSignal.
References _amplitudeMutex, _maxAmplitude, and TRACE.
Referenced by compare(), GeopsyCore::SubSignalPool::decimateAmplitude(), GeopsyGui::SignalLayer::drawingAmplitude(), GeopsyGui::SignalLayer::drawSignal(), header(), GeopsyGui::SignalLayer::maxAmplitude(), GeopsyCore::SignalHeaderObject::maximumAmplitude(), GeopsyGui::SignalLayer::minMaxY(), GeopsyGui::PickLayer::paintData(), Process::run(), T0Correlation::value(), and writeSeg2().
{ TRACE; // Better if amplitude mutex is not locked while signal mutex is blocked // A special case was encountered with DynamicSignal::set() and a drawing thread active // at the same moment. if(itmin==0 && itmax==0) { QMutexLocker ml(&_amplitudeMutex); if(_maxAmplitude!=1e99) return _maxAmplitude; itmax=_nSamples-1; } double v=DoubleSignal::maximumAmplitude(itmin, itmax); if(itmin <= 0 && itmax >= _nSamples-1) { QMutexLocker ml(&_amplitudeMutex); _maxAmplitude=v; } return v; }
double GeopsyCore::Signal::maximumAmplitudeAt | ( | const TimeRange & | r = TimeRange() | ) | const |
Returns the time of the maximum amplitude.
References GeopsyCore::DoubleSignal::_deltaT, _t0, GeopsyCore::TimeRange::end(), GeopsyCore::SignalTemplate< double >::nSamples(), GeopsyCore::TimeRange::start(), and TRACE.
{ TRACE; double t; if(r.start()==0.0 && r.end()==0.0) { t=DoubleSignal::maximumAmplitudeAt(0, nSamples()); } else { double f=1.0/_deltaT; t=DoubleSignal::maximumAmplitudeAt((r.start()-_t0)*f, (r.end()-_t0)*f); } return _t0+_deltaT*t; }
MetaData* GeopsyCore::Signal::metaData | ( | int | id | ) | [inline] |
References GeopsyCore::MetaData::data().
Referenced by comments(), compare(), guralpRecords(), GeopsyCore::DuplicateRays::hasIndex(), header(), MatFormat::load(), miniSeedRecords(), GeopsyGui::PickLayer::paintData(), roundTimePick(), setComments(), setGuralpRecords(), setHeader(), setMiniSeedRecords(), setTimePick(), timePick(), timePickCount(), writeSac(), and writeSeg2().
{return _optionalData.data(id);}
const MetaData* GeopsyCore::Signal::metaData | ( | int | id | ) | const [inline] |
References GeopsyCore::MetaData::data().
{return _optionalData.data(id);}
const MetaDataMap& GeopsyCore::Signal::metaDataMap | ( | ) | const [inline] |
Referenced by GeopsyCore::SharedMetaData::add().
{return _optionalData;}
const MiniSeedRecords & GeopsyCore::Signal::miniSeedRecords | ( | ) | const [inline] |
References metaData(), and GeopsyCore::MiniSeedRecords::staticId().
{ // MiniSeedRecords is always available in MetaDataFactory, hence o is never null const MiniSeedRecords * o=static_cast<const MiniSeedRecords *>(metaData(MiniSeedRecords::staticId())); return *o; }
QString GeopsyCore::Signal::name | ( | ) | const [inline] |
Referenced by GeopsyCore::StationList::addSignal(), GeopsyCore::SubSignalPool::associate3Components(), compare(), correlation(), GeopsyCore::SubSignalPool::debugSignalSharing(), geopsyToFile(), header(), StationCoordinates::keyName(), GeopsyCore::SubSignalPool::mergeStations(), GeopsyCore::StationSignals::name(), GeopsyCore::SignalHeaderObject::name(), normalizedCorrelation(), StructureStationSignals::organizeSubPool(), MonoStation::SpectrumStationSignals::organizeSubPool(), Process::run(), SpectrumStation::save(), GeopsyGui::TimeRangeParameterWidget::setPicks(), Convolution::setSubPool(), Correlations::setSubPool(), SubtractSignals::setSubPool(), MapWindow::signalsUpdate(), MapWindow::subPoolUpdate(), PtMotionResults::updateSignals(), warnReadOnlySamples(), writeGse(), writeMiniSeed(), writeSac(), and xml_writeProperties().
{return _name;}
QString GeopsyCore::Signal::nameComponent | ( | ) | const |
References component(), componentLetter(), and UndefinedComponent.
Referenced by TFAResults::compute(), DampingResults::compute(), correlation(), TFAResults::createObjects(), DampingResults::createObjects(), GeopsyCore::StationSignals::nameComponent(), normalizedCorrelation(), StructureStationSignals::organizeSubPool(), SignalViewer::setSignals(), ChronogramWindow::subPoolUpdate(), GraphicWindow::subPoolUpdate(), GeopsyGui::SignalLayer::subPoolUpdate(), and writeAscii().
{ if(_name.isEmpty()) { if(component()==Signal::UndefinedComponent) { return "id " + QString::number(_id); } else { return "id " + QString::number(_id) + componentLetter(_component); } } else { if(component()==Signal::UndefinedComponent) { return _name; } else { return _name + " " + componentLetter(_component); } } }
Signal * GeopsyCore::Signal::newCopy | ( | Signal * | sig | ) | [static] |
void GeopsyCore::Signal::normalizedCorrelation | ( | const Signal * | s1, |
const Signal * | s2, | ||
double | maxDelay | ||
) |
Correlates signal s1 to s2 and saves results in this signal. If this signal has the correct number of samples and the correct sampling frequency, the value of this signal are not cleaned and the results are stacked on existing values. If not, the signal is initialized with 0.
References component(), GeopsyCore::DoubleSignal::deltaT(), QGpCoreTools::Point::distanceTo(), QGpCoreTools::endl(), name(), nameComponent(), GeopsyCore::DoubleSignal::normalizedCorrelation(), GeopsyCore::SignalTemplate< double >::nSamples(), receiver(), setComponent(), setName(), setReceiver(), setT0(), GeopsyCore::DoubleSignal::setType(), t0(), QGpCoreTools::tr(), TRACE, UndefinedComponent, and GeopsyCore::DoubleSignal::Waveform.
Referenced by GeopsyCore::SubSignalPool::normalizedCorrelations().
{ TRACE; if(!DoubleSignal::normalizedCorrelation(s1, s2, maxDelay)) { App::stream() << tr("Error calculating normalized correlation between signals %1 and %2, probably an allocation error") .arg(s1->nameComponent()).arg(s2->nameComponent()) << endl; } // Change t0 according to tw and set x as the interdistance, name is the compound of both name // Use the effective maxDelay (given by signal length) maxDelay=(nSamples()-1)*deltaT()*0.5; setT0(-maxDelay+s1->t0()-s2->t0()); // Adjust for differences in T0 (not sure if it is the correct direction) setReceiver(Point(s1->receiver().distanceTo(s2->receiver()), 0.0, 0.0)); if(s1->component()==s2->component()) { setName(s1->name() + " & " + s2->name()); setComponent(s1->component()); } else { setName(s1->nameComponent() + " & " + s2->nameComponent()); setComponent(UndefinedComponent); } setType(Waveform); }
int GeopsyCore::Signal::numberInFile | ( | ) | const [inline] |
Referenced by GeopsyCore::AsciiSignalFormat::assign(), compare(), header(), MatFormat::load(), GeopsyCore::SignalHeaderObject::numberInFile(), GeopsyCore::SignalFile::xml_polish(), and xml_writeProperties().
{return _numberInFile;}
int GeopsyCore::Signal::offsetInFile | ( | ) | const [inline] |
Referenced by xml_writeProperties().
{return _offsetInFile;}
void GeopsyCore::Signal::pickCoppens | ( | const QString & | pickName, |
double | delta, | ||
double | end, | ||
double | start = 0. , |
||
bool | relative = false , |
||
double | mute = 0. |
||
) |
References GeopsyCore::DoubleSignal::_deltaT, _isHeaderModified, _t0, CONST_LOCK_SAMPLES, setTimePick(), TRACE, and UNLOCK_SAMPLES.
Referenced by GeopsyCore::SubSignalPool::pickCoppens().
{ TRACE; CONST_LOCK_SAMPLES(double, thisSamples, this) double vmax=0.; int ivmax=0; int iend=(int) ((end-_t0)/_deltaT); if(iend < 0) iend=0; if(iend >= _nSamples) iend=_nSamples-1; int i0; if(relative) i0=0; else i0=(int) ((start-_t0)/_deltaT); if(i0 < 0) i0=0; if(i0 >= _nSamples) i0=iend; int i; for(i=i0; i <= iend; i++) { if(fabs(thisSamples[ i ]) > vmax) { vmax=fabs(thisSamples[ i ]); ivmax=i; } } if(relative) i0=ivmax + (int) (start/_deltaT); if(i0 < 0) i0=0; if(i0 >= iend) i0=iend; int deltaN=(int) (delta/_deltaT); if(deltaN < 2) deltaN=2; if(deltaN > iend-i0) deltaN=iend-i0; double vmute=vmax * mute; double denom=0.; double num=0.; double max=0; int i_max=i0; double tmp; for(i=i0; i <= iend; i++) { if(fabs(thisSamples[ i ]) > vmute) { num+=thisSamples[ i ] * thisSamples[ i ]; denom+=thisSamples[ i ] * thisSamples[ i ]; } if(i > i0 + deltaN) { if(fabs(thisSamples[ i-deltaN ]) > vmute) num -= thisSamples[ i-deltaN ] * thisSamples[ i-deltaN ]; } if(denom) tmp=num/denom; else tmp=0; if(tmp > max) { max=0.999 * tmp; i_max=i-deltaN; } } setTimePick(pickName, _t0 + (double) i_max * _deltaT); _isHeaderModified=true; UNLOCK_SAMPLES(this) }
void GeopsyCore::Signal::pickMinMax | ( | const QString & | pickName, |
double | from, | ||
double | to, | ||
PickWhat | what | ||
) |
References GeopsyCore::DoubleSignal::_deltaT, _isHeaderModified, _t0, CONST_LOCK_SAMPLES, Max, Min, setTimePick(), TRACE, and UNLOCK_SAMPLES.
{ TRACE; CONST_LOCK_SAMPLES(double, thisSamples, this) int ifrom=(int) ((from-_t0)/_deltaT); if(ifrom < 0) ifrom=0; if(ifrom >= _nSamples) ifrom=_nSamples-1; int ito=int((to-_t0)/_deltaT); if(ito < 0) ito=0; if(ito >= _nSamples) ito=_nSamples-1; double extr=thisSamples[ ifrom ]; int iextr=ifrom; switch (what) { case Min: for(int i=ifrom + 1; i < ito; i++) { if(thisSamples[ i ] < extr) { iextr=i; extr=thisSamples[ i ]; } } break; case Max: for(int i=ifrom + 1; i < ito; i++) { if(thisSamples[ i ] > extr) { iextr=i; extr=thisSamples[ i ]; } } break; } setTimePick(pickName, _t0 + (double) iextr * _deltaT); _isHeaderModified=true; UNLOCK_SAMPLES(this) }
bool GeopsyCore::Signal::read | ( | FILE * | f, |
SignalDB * | db | ||
) |
Read header properties from stream for database db.
References All, CustomUnit, East, Horizontal, North, setComponent(), setDeltaT(), setHeaderModified(), setId(), setName(), setNSamples(), setT0(), setTimePick(), setTimeReference(), GeopsyCore::DoubleSignal::setType(), QGpCoreTools::Point2D::setX(), QGpCoreTools::Point2D::setY(), QGpCoreTools::Point::setZ(), TRACE, UndefinedComponent, UndefinedUnit, GeopsyCore::SignalDB::version(), and Vertical.
{ TRACE; int bufLen=256; char * buf=new char [ bufLen ]; File::readLine(buf, bufLen, f); if(strncmp(buf, "ID=", 3)==0) setId(atoi(buf + 3)); else return readError(buf); File::readLine(buf, bufLen, f); char * lastBufChar=buf + strlen(buf)-1; if(*lastBufChar=='\n') *lastBufChar='\0'; if(strncmp(buf, "NAME=", 5)==0) setName(buf + 5); else return readError(buf); File::readLine(buf, bufLen, f); if(strncmp(buf, "COMPONENT=", 10)==0) { int comp=atoi(buf + 10); // Due to historical reasons the number in the sdb file is not the same // as the number in the Signal structure switch (comp) { case 0: setComponent(Signal::Vertical); break; case 2: setComponent(Signal::North); break; case 1: setComponent(Signal::East); break; case 3: setComponent(Signal::UndefinedComponent); break; case 4: setComponent(Signal::Horizontal); break; case 5: setComponent(Signal::All); break; } } else return readError(buf); File::readLine(buf, bufLen, f); if(strncmp(buf, "T0=", 3)==0) setT0(atof(buf + 3)); else return readError(buf); File::readLine(buf, bufLen, f); if(strncmp(buf, "TIME REFERENCE=", 15)==0 || strncmp(buf, "TIME DATUM=", 11)==0) { char * valuePtr=buf; if(valuePtr[6]=='R') valuePtr+=15; else valuePtr+=11; if(strlen(valuePtr) > 0) { QTime t; QDate d; int dd=1, MM=1, yyyy=2004, hh=0, mm=0, ss=0; char * tmpPtr=strtok(valuePtr, "/"); if(tmpPtr) dd=atoi(tmpPtr); tmpPtr=strtok(NULL, "/"); if(tmpPtr) MM=atoi(tmpPtr); tmpPtr=strtok(NULL, " "); if(tmpPtr) yyyy=atoi(tmpPtr); d.setYMD(yyyy, MM, dd); tmpPtr=strtok(NULL, ":"); if(tmpPtr) hh=atoi(tmpPtr); tmpPtr=strtok(NULL, ":"); if(tmpPtr) { mm=atoi(tmpPtr); ss=atoi(tmpPtr + strlen(tmpPtr) + 1); } t.setHMS(hh, mm, ss); if(t.isValid() && d.isValid()) setTimeReference(QDateTime(d, t)); } } else return readError(buf); File::readLine(buf, bufLen, f); if(strncmp(buf, "DELTA T=", 8)==0) setDeltaT(atof(buf + 8)); else return readError(buf); // Transformation to complex is delayed when the file will be loaded File::readLine(buf, bufLen, f); if(strncmp(buf, "TYPE=", 5)==0) setType((DoubleSignal::SignalType) atoi(buf + 5)); else return readError(buf); File::readLine(buf, bufLen, f); // Compatibility with version 2 is ensured as PICK ID will also be read in this loop while(strncmp(buf, "PICK ", 4)==0) { double val; int i; sscanf(buf + 4, "%i=%lg", &i, &val); if(i>=1 && i<=10) setTimePick(QString::number(i-1), val); // Version 2 accept only pick from 1 to 10 File::readLine(buf, bufLen, f); } if(strncmp(buf, "RECEIVER=", 9)==0) { double x, y, z; sscanf(buf + 9, "%lg %lg %lg", &x, &y, &z); _receiver.setX(x); _receiver.setY(y); _receiver.setZ(z); } else return readError(buf); File::readLine(buf, bufLen, f); if(strncmp(buf, "SOURCE=", 7)==0) { double x, y, z; sscanf(buf + 7, "%lg %lg %lg", &x, &y, &z); _source.setX(x); _source.setY(y); _source.setZ(z); } else return readError(buf); if(db->version()>=3) { File::readLine(buf, bufLen, f); if(strncmp(buf, "N SAMPLES=", 10)==0) sscanf(buf + 10, "%i", &_nSamples); else return readError(buf); setNSamples(_nSamples); File::readLine(buf, bufLen, f); if(strncmp(buf, "N SAMPLES IN FILE=", 18)!=0) return readError(buf); File::readLine(buf, bufLen, f); if(strncmp(buf, "NUMBER IN FILE=", 15)==0) sscanf(buf + 15, "%i", &_numberInFile); else return readError(buf); File::readLine(buf, bufLen, f); if(strncmp(buf, "OFFSET IN FILE=", 15)==0) { long tmp; sscanf(buf + 15, "%li", &tmp); _offsetInFile=tmp; } else return readError(buf); File::readLine(buf, bufLen, f); if(strncmp(buf, "BYTE INCREMENT=", 15)==0) sscanf(buf + 15, "%i", &_byteIncrement); else return readError(buf); File::readLine(buf, bufLen, f); if(strncmp(buf, "CHECKSUM=", 9)!=0) return readError(buf); // not stored anymore File::readLine(buf, bufLen, f); if(strncmp(buf, "COUNT PER VOLT=", 15)==0) sscanf(buf + 15, "%lg", &_countPerVolt); else return readError(buf); File::readLine(buf, bufLen, f); if(strncmp(buf, "VOLT PER UNIT=", 14)==0) sscanf(buf + 14, "%lg", &_voltPerUnit); else return readError(buf); File::readLine(buf, bufLen, f); if(strncmp(buf, "AMPLITUDE UNIT=", 15)==0) { int tmp; sscanf(buf + 15, "%i", &tmp); if(tmp>=UndefinedUnit && tmp<=CustomUnit) _amplitudeUnit=static_cast<AmplitudeUnits>(tmp); } else return readError(buf); } setHeaderModified(false); delete [] buf; return true; }
const Point& GeopsyCore::Signal::receiver | ( | ) | const [inline] |
Referenced by GeopsyCore::SubSignalPool::addReceiver(), GeopsyCore::StationList::addSignal(), GeopsyCore::SubSignalPool::associate3Components(), GeopsyCore::SubSignalPool::azimuth(), compare(), StationCoordinates::coordinates(), GeopsyCore::StationSignals::coordinates(), correlation(), geopsyToFile(), header(), ShotRecord::isSameReceiverSet(), GeopsyCore::SubSignalPool::linearSearch(), GeopsyCore::SubSignalPool::mergeStations(), normalizedCorrelation(), ShotRecord::organizeSubPool(), MonoStation::SpectrumStationSignals::organizeSubPool(), GeopsyCore::SubSignalPool::receivers(), GeopsyCore::SignalHeaderObject::receiverX(), GeopsyCore::SignalHeaderObject::receiverY(), GeopsyCore::SignalHeaderObject::receiverZ(), GeopsyCore::SignalHeaderObject::setReceiverX(), GeopsyCore::SignalHeaderObject::setReceiverY(), GeopsyCore::SignalHeaderObject::setReceiverZ(), MapWindow::signalsUpdate(), writeSac(), and xml_writeProperties().
{return _receiver;}
void GeopsyCore::Signal::removeMetaData | ( | int | id | ) | [inline] |
{_optionalData.remove(id);}
void GeopsyCore::Signal::resetAmplitudes | ( | ) | const [inline] |
Referenced by GeopsyCore::SubSignalPool::fastFourierTransform(), setCountPerVolt(), setVoltPerUnit(), and Signal().
{_maxAmplitude=1e99; _averageAmplitude=1e99;}
double GeopsyCore::Signal::roundTimePick | ( | const QString & | name | ) | const |
Returns the time of the nearest sample for timePick named name.
References GeopsyCore::DoubleSignal::_deltaT, _t0, metaData(), GeopsyCore::TimePick::staticId(), and GeopsyCore::TimePick::value().
void GeopsyCore::Signal::setAmplitudeUnit | ( | AmplitudeUnits | u | ) | [inline] |
Referenced by GeopsyCore::SignalHeaderObject::setAmplitudeUnit(), setHeader(), and xml_setProperty().
{_amplitudeUnit=u;}
void GeopsyCore::Signal::setByteIncrement | ( | int | i | ) | [inline] |
Referenced by xml_setProperty().
{_byteIncrement=i;}
void GeopsyCore::Signal::setComments | ( | QString | c | ) | [inline] |
References metaData(), GeopsyCore::MetaString::setValue(), and GeopsyCore::Comments::staticId().
Referenced by GeopsyCore::CitySignal::loadSignals(), and GeopsyCore::GeopsyCoreEngine::showSignal().
{ // Comments is always available in MetaDataFactory, hence o is never null Comments * o=static_cast<Comments *>(metaData(Comments::staticId())); return o->setValue(c); }
void GeopsyCore::Signal::setComponent | ( | Components | c | ) | [inline] |
Referenced by GeopsyCore::AsciiSignalFormat::assign(), correlation(), MatFormat::load(), GeopsyCore::CitySignal::loadSignals(), GeopsyCore::SubSignalPool::merge(), normalizedCorrelation(), StructureStationSignals::organizeSubPool(), read(), GeopsyCore::SignalHeaderObject::setComponent(), setHeader(), and xml_setProperty().
{_component=c;}
void GeopsyCore::Signal::setCountPerVolt | ( | double | c | ) |
Set current recorder factor for converting counts into volts
References GeopsyCore::SignalTemplate< double >::isAllocated(), LOCK_SAMPLES, GeopsyCore::SignalTemplate< double >::multiply(), resetAmplitudes(), TRACE, and UNLOCK_SAMPLES.
Referenced by GeopsyCore::CitySignal::loadSignals(), GeopsyCore::SignalHeaderObject::setCountPerVolt(), setHeader(), and xml_setProperty().
{ TRACE; if(c!=_countPerVolt) { lockData(); // Lock without allocating the samples if(isAllocated() || isSaved()) { // Swaped signal must be corrected as well LOCK_SAMPLES(double, thisSamples, this) multiply(_countPerVolt/c); resetAmplitudes(); UNLOCK_SAMPLES(this) } unlockData(); _countPerVolt=c; } }
void GeopsyCore::Signal::setDatabase | ( | SignalDB * | db | ) | [inline] |
{_db=db;}
void GeopsyCore::Signal::setDeltaT | ( | double | newval | ) | [virtual] |
Reimplemented from GeopsyCore::DoubleSignal.
References _timeRange, GeopsyCore::SparseTimeRange::add(), GeopsyCore::SparseTimeRange::clear(), GeopsyCore::DoubleSignal::deltaT(), QGpCoreTools::endl(), endTime(), GeopsyCore::SparseTimeRange::scale(), t0(), QGpCoreTools::tr(), TRACE, TRACE_BUG, TRACE_BUG_DOUBLE, and TRACE_BUG_N.
Referenced by GeopsySLink::SeedLinkStream::initSignal(), MatFormat::load(), GeopsyCore::CitySignal::loadSignals(), GeopsyCore::SubSignalPool::merge(), read(), GeopsySLink::SeedLinkStream::set(), GeopsyCore::SignalHeaderObject::setDeltaT(), GeopsyCore::SignalHeaderObject::setDuration(), setHeader(), GeopsyCore::SignalHeaderObject::setSamplingFrequency(), GeopsyCore::GeopsyCoreEngine::showSignal(), and xml_setProperty().
{ TRACE; if(newVal<=0.0) { App::stream() << tr("Negative or null deltaT (%1) not accepted").arg(newVal) << endl; } else { if(deltaT()>0.0) { _timeRange.scale(t0(),newVal/deltaT()); DoubleSignal::setDeltaT(newVal); } else { TRACE_BUG; DoubleSignal::setDeltaT(newVal); _timeRange.clear(); TRACE_BUG_N(1); TRACE_BUG_DOUBLE(t0()); TRACE_BUG_DOUBLE(endTime()); _timeRange.add(TimeRange(t0(), endTime())); } } }
void GeopsyCore::Signal::setFile | ( | SignalFile * | f | ) | [inline] |
Referenced by MatFormat::load(), GeopsyCore::SignalFile::loadGeopsySignal(), GeopsyCore::CitySignal::loadSignals(), and GeopsyCore::SignalFile::xml_member().
{_file=f;}
void GeopsyCore::Signal::setGuralpRecords | ( | const GuralpRecords & | r | ) | [inline] |
References metaData(), and GeopsyCore::GuralpRecords::staticId().
{ // GuralpRecords is always available in MetaDataFactory, hence o is never null GuralpRecords * o=static_cast<GuralpRecords *>(metaData(GuralpRecords::staticId())); *o=r; }
bool GeopsyCore::Signal::setHeader | ( | const MetaDataIndex & | index, |
QVariant | val | ||
) |
References GeopsyCore::DoubleSignal::_deltaT, GeopsyCore::SignalTemplate< double >::_nSamples, GeopsyCore::MetaDataFactory::AmplitudeUnit, GeopsyCore::MetaDataFactory::Component, GeopsyCore::MetaDataFactory::CountPerVolt, GeopsyCore::MetaDataFactory::DataCount, GeopsyCore::MetaDataFactory::DeltaT, GeopsyCore::MetaDataFactory::Duration, GeopsyCore::MetaDataFactory::EndTime, GeopsyCore::MetaDataIndex::id(), GeopsyCore::MetaDataIndex::index(), metaData(), GeopsyCore::MetaDataFactory::Name, READONLY_STANDARD_METADATA, GeopsyCore::MetaDataFactory::ReceiverX, GeopsyCore::MetaDataFactory::ReceiverY, GeopsyCore::MetaDataFactory::ReceiverZ, GeopsyCore::MetaDataFactory::SamplingFrequency, setAmplitudeUnit(), setComponent(), setCountPerVolt(), GeopsyCore::MetaData::setData(), setDeltaT(), setHeaderModified(), setT0(), setTimeReference(), setUnitPerVolt(), setVoltPerCount(), setVoltPerUnit(), QGpCoreTools::Point2D::setX(), QGpCoreTools::Point2D::setY(), QGpCoreTools::Point::setZ(), GeopsyCore::MetaDataFactory::SourceX, GeopsyCore::MetaDataFactory::SourceY, GeopsyCore::MetaDataFactory::SourceZ, GeopsyCore::MetaDataIndex::subId(), GeopsyCore::MetaDataFactory::T0, GeopsyCore::MetaDataFactory::TimeReference, TRACE, GeopsyCore::MetaDataFactory::UnitPerVolt, userAmplitudeUnit(), userComponent(), GeopsyCore::MetaDataFactory::VoltPerCount, and GeopsyCore::MetaDataFactory::VoltPerUnit.
Referenced by GeopsyCore::AsciiSignalFormat::assign(), GeopsyCore::SubSignalPool::importTable(), SignalTableItem::setData(), GeopsyCore::SignalProcess::setHeaderCore(), and GeopsyCore::SignalExpression::setValue().
{ TRACE; if(index.id()<MetaDataFactory::DataCount) { switch (index.id()) { case MetaDataFactory::T0: setT0(Number::timeToSeconds(val.toString())); break; case MetaDataFactory::DeltaT: setDeltaT(val.toDouble()); break; case MetaDataFactory::ReceiverX: _receiver.setX(val.toDouble()); break; case MetaDataFactory::ReceiverY: _receiver.setY(val.toDouble()); break; case MetaDataFactory::ReceiverZ: _receiver.setZ(val.toDouble()); break; case MetaDataFactory::SourceX: _source.setX(val.toDouble()); break; case MetaDataFactory::SourceY: _source.setY(val.toDouble()); break; case MetaDataFactory::SourceZ: _source.setZ(val.toDouble()); break; case MetaDataFactory::Name: _name=val.toString(); break; case MetaDataFactory::Component: setComponent(userComponent(val.toString())); break; case MetaDataFactory::TimeReference: setTimeReference(val.toString()); break; case MetaDataFactory::SamplingFrequency: setDeltaT(1.0/val.toDouble()); break; case MetaDataFactory::Duration: setDeltaT(Number::timeToSeconds(val.toString())/(double)_nSamples); break; case MetaDataFactory::EndTime: setT0(Number::timeToSeconds(val.toString())-_deltaT * _nSamples); break; case MetaDataFactory::CountPerVolt: setCountPerVolt(val.toDouble()); break; case MetaDataFactory::VoltPerCount: setVoltPerCount(val.toDouble()); break; case MetaDataFactory::VoltPerUnit: setVoltPerUnit(val.toDouble()); break; case MetaDataFactory::UnitPerVolt: setUnitPerVolt(val.toDouble()); break; case MetaDataFactory::AmplitudeUnit: setAmplitudeUnit(userAmplitudeUnit(val.toString())); break; READONLY_STANDARD_METADATA return false; } } else { MetaData * d=metaData(index.id()); if(d) { if(!d->setData(index.subId(), index.index(), val)) { return false; } } else { return false; } } setHeaderModified(true); return true; }
void GeopsyCore::Signal::setHeaderModified | ( | bool | m | ) | [inline] |
Referenced by GeopsyCore::SubSignalPool::fastFourierTransform(), GeopsyCore::SubSignalPool::importTable(), GeopsyGui::PickLayer::mouseMoveEvent(), GeopsyGui::PickLayer::mousePressEvent(), read(), SignalTableItem::setData(), setHeader(), GeopsyMainWindow::setReceivers(), and GeopsyMainWindow::setSources().
{_isHeaderModified=m;}
void GeopsyCore::Signal::setId | ( | int | id | ) |
Sets signal ID. Called only by SignalDB::addSignal() (with id=-1) and when loading from an XML stream (id>-1).
References TRACE, and GeopsyCore::SignalDB::uniqueId().
Referenced by GeopsyCore::SignalDB::addSignal(), read(), and xml_setProperty().
void GeopsyCore::Signal::setMiniSeedRecords | ( | const MiniSeedRecords & | r | ) | [inline] |
References metaData(), and GeopsyCore::MiniSeedRecords::staticId().
{ // MiniSeedRecords is always available in MetaDataFactory, hence o is never null MiniSeedRecords * o=static_cast<MiniSeedRecords *>(metaData(MiniSeedRecords::staticId())); *o=r; }
void GeopsyCore::Signal::setName | ( | QString | n | ) | [inline] |
Referenced by correlation(), GeopsyCore::SubSignalPool::merge(), normalizedCorrelation(), StructureStationSignals::organizeSubPool(), read(), GeopsyCore::SignalHeaderObject::setName(), GeopsyCore::SignalFile::setSignalName(), GeopsyCore::GeopsyCoreEngine::showSignal(), and xml_setProperty().
{_name=n;}
void GeopsyCore::Signal::setNSamples | ( | int | n | ) | [virtual] |
Reimplemented from GeopsyCore::DoubleSignal.
Reimplemented in GeopsyCore::DynamicSignal.
References _timeRange, GeopsyCore::SparseTimeRange::add(), GeopsyCore::SparseTimeRange::clear(), endTime(), t0(), TRACE, TRACE_BUG, TRACE_BUG_DOUBLE, TRACE_BUG_INT, and TRACE_BUG_N.
Referenced by cut(), MatFormat::load(), GeopsyCore::CitySignal::loadSignals(), read(), Process::run(), GeopsyCore::GeopsyCoreEngine::showSignal(), and xml_setProperty().
{ TRACE; TRACE_BUG; TRACE_BUG_N(1); TRACE_BUG_INT(n); DoubleSignal::setNSamples(n); TRACE_BUG_N(2); _timeRange.clear(); TRACE_BUG_N(3); TRACE_BUG_DOUBLE(t0()); TRACE_BUG_DOUBLE(endTime()); _timeRange.add(TimeRange(t0(), endTime())); }
void GeopsyCore::Signal::setNumberInFile | ( | int | i | ) | [inline] |
Referenced by MatFormat::load(), GeopsyCore::SignalFile::loadGeopsySignal(), GeopsyCore::CitySignal::loadSignals(), GeopsyCore::SignalFile::xml_polish(), and xml_setProperty().
{_numberInFile=i;}
void GeopsyCore::Signal::setOffsetInFile | ( | int | o | ) | [inline] |
Referenced by MatFormat::load(), GeopsyCore::SignalFile::loadGeopsySignal(), GeopsyCore::SignalFile::save(), and xml_setProperty().
{_offsetInFile=o;}
void GeopsyCore::Signal::setReadOnlySamples | ( | bool | ro | ) | [inline] |
{_isReadOnlySamples=ro;}
void GeopsyCore::Signal::setReceiver | ( | const Point & | p | ) | [inline] |
void GeopsyCore::Signal::setSource | ( | const Point & | p | ) | [inline] |
void GeopsyCore::Signal::setT0 | ( | double | t | ) |
References _t0, _timeRange, GeopsyCore::SparseTimeRange::shift(), and TRACE.
Referenced by correlation(), cut(), GeopsySLink::SeedLinkStream::initSignal(), GeopsyCore::CitySignal::loadSignals(), GeopsyCore::SubSignalPool::merge(), normalizedCorrelation(), read(), Process::run(), GeopsySLink::SeedLinkStream::set(), GeopsyCore::SignalHeaderObject::setEndTime(), setHeader(), GeopsyCore::SignalHeaderObject::setT0(), GeopsyCore::GeopsyCoreEngine::showSignal(), T0Correlation::value(), and xml_setProperty().
{ TRACE; _timeRange.shift(t-_t0); _t0=t; }
void GeopsyCore::Signal::setTemporary | ( | ) |
Called by copy contructor, but can also be called for a new signal created with other constructor (before first allocation of data samples)
Usually initial reference count is set to 0. We decrease it to -1 without checking and deleting Adding signal to db set its reference count to 0 Next the temporary signal will be added to one or more visual subpool When the last visual subpool is closed, the count drops to 0 and the signal is deleted, the destructor remove it from database automatically. If the signal is not displayed or added to a subpool then you must delete it manually.
References _isHeaderModified, _isReadOnlySamples, QGpCoreTools::SharedObject::removeReference(), and TRACE.
Referenced by GeopsyCore::SubSignalPool::convolution(), GeopsyCore::SubSignalPool::correlations(), GeopsyCore::SubSignalPool::normalizedCorrelations(), and Signal().
{ TRACE; _file=0; _numberInFile=0; _offsetInFile=0; _byteIncrement=0; _isReadOnlySamples=false; _isHeaderModified=true; removeReference(); /* Adding signal to db set its reference count to 1 We decrease it to 0 without checking and deleting Next the temporary signal will be added to one or more visual subpool When the last visual subpool is closed, the count drops to 0 and the signal is deleted, the destructor remove it from database automatically. */ }
void GeopsyCore::Signal::setTimePick | ( | const QString & | name, |
double | time | ||
) | [inline] |
Set time for pick with index. Time picks are optional data members
References metaData(), GeopsyCore::TimePick::setValue(), and GeopsyCore::TimePick::staticId().
Referenced by GeopsyGui::PickLayer::mouseMoveEvent(), GeopsyGui::PickLayer::mousePressEvent(), pickCoppens(), pickMinMax(), read(), and Process::run().
{ // TimePick is always available in MetaDataFactory, hence o is never null TimePick * o=static_cast<TimePick *>(metaData(TimePick::staticId())); o->setValue(name, time); }
void GeopsyCore::Signal::setTimeRange | ( | const SparseTimeRange & | r | ) |
Set available signal within the range defined by t0() and endTime().
References _timeRange, GeopsyCore::SparseTimeRange::intersection(), and GeopsyCore::SparseTimeRange::range().
Referenced by cut().
{ _timeRange=r.intersection(_timeRange.range()); }
void GeopsyCore::Signal::setTimeReference | ( | QDateTime | t | ) | [inline] |
void GeopsyCore::Signal::setTimeReference | ( | QString | t | ) | [inline] |
{_timeReference=QDateTime::fromString(t, "dd/MM/yyyy hh:mm:ss" );}
void GeopsyCore::Signal::setUnitPerVolt | ( | double | c | ) | [inline] |
Referenced by setHeader(), and GeopsyCore::SignalHeaderObject::setUnitPerVolt().
{setVoltPerUnit(1.0/c);}
void GeopsyCore::Signal::setVoltPerCount | ( | double | c | ) | [inline] |
Referenced by setHeader(), and GeopsyCore::SignalHeaderObject::setVoltPerCount().
{setCountPerVolt(1.0/c);}
void GeopsyCore::Signal::setVoltPerUnit | ( | double | c | ) |
Set current sensor factor for converting volts into amplitudeUnit
References GeopsyCore::SignalTemplate< double >::isAllocated(), LOCK_SAMPLES, GeopsyCore::SignalTemplate< double >::multiply(), resetAmplitudes(), TRACE, and UNLOCK_SAMPLES.
Referenced by setHeader(), GeopsyCore::SignalHeaderObject::setVoltPerUnit(), and xml_setProperty().
{ TRACE; if(c!=_voltPerUnit) { lockData(); // Lock without allocating the samples if(isAllocated() || isSaved()) { // Swaped signal must be corrected as well LOCK_SAMPLES(double, thisSamples, this) multiply(_voltPerUnit/c); resetAmplitudes(); UNLOCK_SAMPLES(this) } unlockData(); _voltPerUnit=c; } }
const Point& GeopsyCore::Signal::source | ( | ) | const [inline] |
Referenced by GeopsyCore::SubSignalPool::addSource(), GeopsyCore::SubSignalPool::azimuth(), compare(), SourceCoordinates::coordinates(), geopsyToFile(), header(), ToolLinearFKActive::initStations(), GeopsyCore::SubSignalPool::linearSearch(), ShotRecord::organizeSubPool(), GeopsyCore::SignalHeaderObject::setSourceX(), GeopsyCore::SignalHeaderObject::setSourceY(), GeopsyCore::SignalHeaderObject::setSourceZ(), GeopsyCore::StationSignals::source(), GeopsyCore::SubSignalPool::sources(), GeopsyCore::SignalHeaderObject::sourceX(), GeopsyCore::SignalHeaderObject::sourceY(), GeopsyCore::SignalHeaderObject::sourceZ(), and xml_writeProperties().
{return _source;}
double GeopsyCore::Signal::sourceReceiverAzimuth | ( | ) | const [inline] |
Referenced by compare(), header(), ToolRefra::initStations(), and GeopsyCore::StationSignals::sourceReceiverAzimuth().
{return _source.azimuthTo(_receiver);}
double GeopsyCore::Signal::sourceReceiverDistance | ( | ) | const [inline] |
Referenced by compare(), header(), ToolRefra::initStations(), LinearFKActiveStationSignals::normalize(), GeopsyCore::SignalHeaderObject::sourceDistance(), and GeopsyCore::StationSignals::sourceReceiverDistance().
{return _source.distanceTo(_receiver);}
Signal::AmplitudeUnits GeopsyCore::Signal::standardAmplitudeUnit | ( | QString | u | ) | [static] |
Returns amplitude unit from a string containing standardized names
References Acceleration, CustomUnit, Displacement, TRACE, and Velocity.
Referenced by GeopsyCore::SignalHeaderObject::setAmplitudeUnit(), and xml_setProperty().
{ TRACE; static QMap<QString, AmplitudeUnits> unitMap; if(unitMap.isEmpty()) { unitMap.insert("Displacement", Displacement); unitMap.insert("Velocity", Velocity); unitMap.insert("Acceleration", Acceleration); } QMap<QString,AmplitudeUnits>::iterator it=unitMap.find(u); if(it!=unitMap.end()) { return it.value(); } else { return CustomUnit; } }
Signal::Components GeopsyCore::Signal::standardComponent | ( | QString | c | ) | [static] |
Returns component from a string containing standardized component names
References All, East, Horizontal, North, TRACE, UndefinedComponent, and Vertical.
Referenced by GeopsyCore::SignalHeaderObject::setComponent(), GeopsyCore::AsciiSignalFormatComponent::xml_setProperty(), and xml_setProperty().
{ TRACE; static QMap<QString, Components> m; if(m.isEmpty()) { m.insert("Vertical", Vertical); m.insert("North", North); m.insert("East", East); m.insert("Horizontal", Horizontal); m.insert("All", All); } QMap<QString,Components>::iterator it=m.find(c); if(it!=m.end()) { return it.value(); } else { return UndefinedComponent; } }
QString GeopsyCore::Signal::standardName | ( | Components | c | ) | [static] |
Return standard name for component
References All, East, Horizontal, North, TRACE, and Vertical.
Referenced by GeopsyCore::AsciiSignalFormatComponent::xml_writeProperties().
QString GeopsyCore::Signal::standardName | ( | AmplitudeUnits | u | ) | [static] |
Returns the theoretical name of the units for amplitude.
References Acceleration, Displacement, TRACE, and Velocity.
{ TRACE; switch (u) { case Displacement: return "Displacement"; case Velocity: return "Velocity"; case Acceleration: return "Acceleration"; default: break; } return "Custom"; }
double GeopsyCore::Signal::t0 | ( | ) | const [inline] |
Referenced by add(), GeopsyCore::SubSignalPool::associate3Components(), compare(), TFAResults::compute(), DampingResults::compute(), GeopsyCore::StationProcessSignals::copyOriginalSignal(), copySamplesFrom(), correlation(), cut(), GeopsyGui::TimeRangeParameterWidget::getParameters(), header(), ToolLinearFKActive::initStations(), GeopsyCore::SubSignalPool::merge(), GeopsyCore::SubSignalPool::mergeStations(), GeopsyCore::StationSignals::minTime(), GeopsyGui::PickLayer::mouseMoveEvent(), normalizedCorrelation(), GeopsyGui::TimeRangeParameterWidget::on_fromType_activated(), StructureStationSignals::organizeSubPool(), ShotRecord::organizeSubPool(), MonoStation::SpectrumStationSignals::organizeSubPool(), Process::run(), GeopsySLink::SeedLinkStream::set(), setDeltaT(), GeopsyCore::StationSignals::setKeep(), setNSamples(), ShotRecord::t0(), GeopsyCore::StationSignals::t0(), GeopsyCore::SubSignalPool::timeRange(), GeopsyGui::SignalLayer::updateGrid(), PtMotionResults::updateSignals(), T0Correlation::value(), GeopsyGui::SignalLayer::visibleSamples(), writeGse(), writeMiniSeed(), writeSac(), writeSegySu(), and xml_writeProperties().
{return _t0;}
TIME GeopsyCore::Signal::t0AsTIME | ( | ) | const [inline] |
{return DateTime::capAddSecs(_timeReference, t0());}
bool GeopsyCore::Signal::taper | ( | const TimeRange & | t, |
const TaperParameters & | param | ||
) | [inline] |
Applies a taper window to the signal over the range t.
Returns false if not processed due to memory problem.
Reimplemented from GeopsyCore::DoubleSignal.
References _t0, GeopsyCore::TimeRange::shifted(), and TRACE.
Referenced by GeopsyCore::SubSignalPool::taper().
{ TRACE; return DoubleSignal::taper(tw.shifted(-_t0), param); }
double GeopsyCore::Signal::timePick | ( | const QString & | name | ) | const [inline] |
References metaData(), GeopsyCore::TimePick::staticId(), and GeopsyCore::TimePick::value().
Referenced by geopsyToFile(), GeopsyGui::TimeRangeParameterWidget::getParameters(), GeopsyGui::TimeRangeParameterWidget::on_fromType_activated(), GeopsyGui::TimeRangeParameterWidget::on_toType_activated(), GeopsyGui::PickLayer::paintData(), Process::run(), GeopsyGui::SignalLayer::visibleSamples(), writeSac(), writeSeg2(), and ManualPick::~ManualPick().
{ // TimePick is always available in MetaDataFactory, hence o is never null const TimePick * o=static_cast<const TimePick *>(metaData(TimePick::staticId())); return o->value(name); }
int GeopsyCore::Signal::timePickCount | ( | ) | const [inline] |
References GeopsyCore::TimePick::count(), metaData(), and GeopsyCore::TimePick::staticId().
{ // TimePick is always available in MetaDataFactory, hence o is never null const TimePick * o=static_cast<const TimePick *>(metaData(TimePick::staticId())); return o->count(0); }
const SparseTimeRange& GeopsyCore::Signal::timeRange | ( | ) | const [inline] |
Referenced by cut(), GeopsyGui::SignalLayer::drawGaps(), GeopsyGui::ChronogramLayer::exportGaps(), StructureStationSignals::organizeSubPool(), GeopsyGui::ChronogramLayer::rangeUpdate(), Process::run(), GeopsyGui::ChronogramLayer::selection(), GeopsyCore::StationSignals::setKeep(), and GeopsyCore::StationSignals::setSampling().
{return _timeRange;}
QDateTime GeopsyCore::Signal::timeReference | ( | ) | const [inline] |
Referenced by compare(), ToolLinearFKActive::initStations(), GeopsySLink::SeedLinkStream::localTime(), ShotRecord::organizeSubPool(), Process::run(), GeopsySLink::SeedLink::run(), GeopsySLink::SeedLinkStream::set(), ShotRecord::setSignals(), GeopsyCore::StationSignals::timeReference(), writeGse(), writeMiniSeed(), writeSac(), and writeSegySu().
{return _timeReference;}
QString GeopsyCore::Signal::timeReferenceString | ( | ) | const [inline] |
Referenced by header(), GeopsyCore::SignalHeaderObject::timeReference(), and xml_writeProperties().
{return _timeReference.toString( "dd/MM/yyyy hh:mm:ss" );}
double GeopsyCore::Signal::unitPerCount | ( | ) | const [inline] |
Referenced by compare(), header(), GeopsyCore::CitySignal::loadSignals(), GeopsyCore::SignalHeaderObject::unitPerCount(), and writeGse().
{return 1.0/countPerUnit();}
double GeopsyCore::Signal::unitPerVolt | ( | ) | const [inline] |
Referenced by compare(), header(), and GeopsyCore::SignalHeaderObject::unitPerVolt().
{return 1.0/_voltPerUnit;}
Signal::AmplitudeUnits GeopsyCore::Signal::userAmplitudeUnit | ( | QString | u | ) | [static] |
REturns amplitude unit from a string entered by the user (hence in its own language)
References Acceleration, CustomUnit, Displacement, QGpCoreTools::tr(), TRACE, and Velocity.
Referenced by setHeader().
{ TRACE; static QMap<QString, AmplitudeUnits> unitMap; if(unitMap.isEmpty()) { unitMap.insert(tr("Displacement"), Displacement); unitMap.insert(tr("Velocity"), Velocity); unitMap.insert(tr("Acceleration"), Acceleration); } QMap<QString,AmplitudeUnits>::iterator it=unitMap.find(u); if(it!=unitMap.end()) { return it.value(); } else { return CustomUnit; } }
Signal::Components GeopsyCore::Signal::userComponent | ( | QString | c | ) | [static] |
Returns component from a string entered by the user (hence in its own language)
References All, East, Horizontal, North, QGpCoreTools::tr(), TRACE, UndefinedComponent, and Vertical.
Referenced by setHeader().
{ TRACE; static QMap<QString, Components> m; if(m.isEmpty()) { m.insert(tr("Vertical"), Vertical); m.insert(tr("North"), North); m.insert(tr("East"), East); m.insert(tr("Horizontal"), Horizontal); m.insert(tr("All"), All); } QMap<QString,Components>::iterator it=m.find(c); if(it!=m.end()) { return it.value(); } else { return UndefinedComponent; } }
QString GeopsyCore::Signal::userName | ( | Components | c | ) | [static] |
Return name for component in user's own language
References All, East, Horizontal, North, QGpCoreTools::tr(), TRACE, and Vertical.
Referenced by GeopsyCore::StationSignals::addSignal(), and GeopsyCore::StationSignals::hasAllComponents().
QString GeopsyCore::Signal::userName | ( | AmplitudeUnits | u | ) | [static] |
Returns the theoretical name of the units for amplitude in user own language
References Acceleration, Displacement, QGpCoreTools::tr(), TRACE, and Velocity.
{ TRACE; switch (u) { case Displacement: return tr("Displacement"); case Velocity: return tr("Velocity"); case Acceleration: return tr("Acceleration"); default: break; } return tr("Custom"); }
double GeopsyCore::Signal::voltPerCount | ( | ) | const [inline] |
Referenced by compare(), header(), and GeopsyCore::SignalHeaderObject::voltPerCount().
{return 1.0/_countPerVolt;}
double GeopsyCore::Signal::voltPerUnit | ( | ) | const [inline] |
Referenced by compare(), header(), GeopsyCore::SignalHeaderObject::voltPerUnit(), and xml_writeProperties().
{return _voltPerUnit;}
bool GeopsyCore::Signal::warnReadOnlySamples | ( | ) | const [inline] |
References _isReadOnlySamples, QGpCoreTools::endl(), name(), QGpCoreTools::tr(), and TRACE.
Referenced by GeopsyCore::SubSignalPool::agc(), GeopsyCore::SubSignalPool::decimateAmplitude(), GeopsyCore::SubSignalPool::filter(), GeopsyCore::SubSignalPool::multiply(), GeopsyCore::SubSignalPool::rotateComponents(), GeopsyCore::SubSignalPool::shift(), GeopsyCore::SubSignalPool::stddevClip(), GeopsyCore::SubSignalPool::subtractSignal(), GeopsyCore::SubSignalPool::subtractSignals(), GeopsyCore::SubSignalPool::subtractValue(), GeopsyCore::SubSignalPool::taper(), GeopsyCore::SubSignalPool::unglitch(), GeopsyCore::SubSignalPool::waveletTransform(), and GeopsyCore::SubSignalPool::whiten().
{ TRACE; if(_isReadOnlySamples) { App::stream() << tr("Trying to modify read only signal %1, aborted").arg(name()) << endl; return true; } else return false; }
bool GeopsyCore::Signal::writeAscii | ( | QFile & | f, |
int | numInFile | ||
) | const |
References GeopsyCore::DoubleSignal::_deltaT, GeopsyCore::SignalTemplate< double >::_nSamples, GeopsyCore::DoubleSignal::amplitude(), CONST_LOCK_SAMPLES, GeopsyCore::DoubleSignal::isComplex(), GeopsyCore::DoubleSignal::isReal(), nameComponent(), GeopsyCore::DoubleSignal::phase(), TRACE, and UNLOCK_SAMPLES.
{ TRACE; QByteArray buf; buf+="# channel "; buf+=QByteArray::number(numInFile+1); buf+=" "; buf+=nameComponent(); buf+="\n"; if(f.write(buf)!=buf.count()) return false; CONST_LOCK_SAMPLES(double, thisSamples, this) if(isReal()) { for(int i=0; i < _nSamples; i ++) { buf.clear(); buf+=QByteArray::number(thisSamples[ i ], 'g', 15); buf+="\n"; if(f.write(buf)!=buf.count()) return false; } } else if(isComplex()) { double fNyquist=0.5/_deltaT; int nSamples2=_nSamples >> 1; double df=fNyquist/(double) nSamples2; for(int i=1; i <= nSamples2; i++) { buf.clear(); buf+=QByteArray::number(df * (double) i, 'g', 15); buf+="\t"; buf+=QByteArray::number(amplitude(thisSamples, i), 'g', 15); buf+="\t"; buf+=QByteArray::number(phase(thisSamples, i), 'g', 15); buf+="\n"; if(f.write(buf)!=buf.count()) return false; } } UNLOCK_SAMPLES(this) return true; }
bool GeopsyCore::Signal::writeGse | ( | QFile & | f | ) | const |
References GeopsyCore::SignalTemplate< double >::_nSamples, QGpCoreTools::DateTime::addSeconds(), GeopsyCore::Gse::checksum(), component(), GeopsyCore::Gse::compress6(), CONST_LOCK_SAMPLES, countPerUnit(), GeopsyCore::DoubleSignal::deltaT(), GeopsyCore::Gse::diff(), East, header(), name(), North, GeopsyCore::SignalTemplate< double >::nSamples(), GeopsyCore::DoubleSignal::restoreType(), GeopsyCore::DoubleSignal::saveType(), t0(), timeReference(), QGpCoreTools::DateTime::toString(), QGpCoreTools::tr(), TRACE, unitPerCount(), UNLOCK_SAMPLES, Vertical, and GeopsyCore::DoubleSignal::Waveform.
{ TRACE; const DoubleSignal * sig=saveType(Waveform); static const QString errorMsg(tr("[GSE] Error while writing %1")); // Build header line // Index 0 QString header("WID2 "); DateTime t(timeReference()); t.addSeconds(t0()); // Index 6 header+=t.toString("yyyy/MM/dd hh:mm:ssz").left(23)+" "; // Index 30 header+=name().leftJustified(5, QChar(' '), true)+" "; /* See http://www.iris.edu/manuals/seed/SEEDManual_V2.4_Appendix-A.pdf for FDSN channel codes Geopsy always export in HH, which means High Broad Band with high gain. */ // Index 36 switch (component()) { case Vertical: header+="HHZ "; break; case North: header+="HHN "; break; case East: header+="HHE "; break; default: header+=" "; break; } // Index 45 header+="CM6 "; // Index 49 header+=QString::number(nSamples()).leftJustified(8, QChar(' '), true)+" "; // Index 58 header+=QString::number(1.0/deltaT()).leftJustified(11, QChar(' '), true)+" "; // Index 70: calibration factor at calper header+=QString::number(1e9*unitPerCount()).leftJustified(10, QChar(' '), true)+" "; // Index 81: calibration period header+=" 1.000 "; // Index 89: Instrument type header+=" NONE "; // Index 96: horizontal orientation of sensor (from north) // Index 102: vertical horientation switch(component()) { case Vertical: header+=" -1.0 "; header+=" 0.0 "; break; default: header+=" 0.0 "; header+="90.0 "; break; } header+="\n"; header+="DAT2\n"; if(f.write(header.toAscii().data(), header.count())!=header.count()) return writeError(sig, errorMsg.arg(tr("header"))); // Samples int iComp=0,nComp=0; CONST_LOCK_SAMPLES(double, sigSamples, sig) double conversionFactor=countPerUnit(); int * decomp=new int[_nSamples]; for(int i=0; i < _nSamples; i ++) { decomp[i]=(int) floor(sigSamples[ i ] * conversionFactor + 0.5); } int cs=Gse::checksum(decomp, _nSamples); Gse::diff(decomp, _nSamples); Gse::diff(decomp, _nSamples); char * comp=Gse::compress6(_nSamples, decomp, nComp); nComp-=80; // Force last line to be written after loop for(iComp=0;iComp<nComp;iComp+=80) { if(f.write(comp+iComp,80)!=80 || f.write("\n")!=1) { return writeError(sig, errorMsg.arg(tr("compressed samples"))); } } nComp+=80; // Recover orignal nComp // Write beginning of last line nComp-=iComp; // Get the number of chars of last line if(f.write(comp+iComp,nComp)!=nComp) { return writeError(sig, errorMsg.arg(tr("compressed samples (last line)"))); } // Fill the rest with spaces for(;nComp<80; nComp++) { if(f.write(" ", 1)!=1) { return writeError(sig, errorMsg.arg(tr("compressed samples (last line)"))); } } // Write checksum header="\nCHK2 "; header+=QString::number(cs); header+="\n"; if(f.write(header.toAscii().data(),header.count())!=header.count()) { return writeError(sig, errorMsg.arg(tr("check sum"))); } delete [] comp; delete [] decomp; UNLOCK_SAMPLES(sig); restoreType(sig); return true; }
bool GeopsyCore::Signal::writeMiniSeed | ( | QFile & | f | ) | const |
References GeopsyCore::SignalTemplate< double >::_nSamples, All, component(), CONST_LOCK_SAMPLES, countPerUnit(), East, QGpCoreTools::endl(), Horizontal, name(), North, GeopsyCore::SignalTemplate< double >::samples(), GeopsyCore::DoubleSignal::samplingFrequency(), t0(), timeReference(), QGpCoreTools::tr(), TRACE, UndefinedComponent, UNLOCK_SAMPLES, and Vertical.
{ TRACE; LibMSeed::MSRecord * msr=LibMSeed::msr_init(0); msr->reclen=512; // Always output 512 byte records compatible with seiscomp mseedscan plugin msr->encoding=DE_FLOAT32; msr->numsamples=_nSamples; msr->sampletype='f'; msr->byteorder=1; // Big endian msr->dataquality= 'D'; if(name().indexOf("_")==2 && name().count()<=8) { strcpy(msr->network, name().left(2).toAscii().data()); strcpy(msr->station, name().mid(3, 5).toAscii().data()); } else { // Non standard signal names App::stream() << tr("Non standard signal name (NN_SSSSS), skip network code (NN)") << endl; strcpy(msr->network, ""); strcpy(msr->station, name().left(11).toAscii().data()); } strcpy(msr->location, ""); // Set start time LibMSeed::BTime t; QDateTime st=timeReference(); double t0round=round(t0()*10000.0); int t0secs=(int)floor(t0round*0.0001); st=st.addSecs(t0secs); t.year=st.date().year(); t.day=QDate(t.year, 1,1).daysTo(st.date())+1; t.hour=st.time().hour(); t.min=st.time().minute(); t.sec=st.time().second(); t.fract=(quint16) (t0round-t0secs*10000.0); msr->starttime=LibMSeed::ms_btime2hptime (&t); switch (component()) { case All: case Horizontal: case UndefinedComponent: case Vertical: strcpy(msr->channel, "BHZ"); break; case North: strcpy(msr->channel, "BHN"); break; case East: strcpy(msr->channel, "BHE"); break; } msr->samprate=samplingFrequency(); int packedSamples; double * samples=new double[_nSamples]; msr->datasamples=samples; CONST_LOCK_SAMPLES(double, thisSamples, this) double factor=countPerUnit(); for (int i=0; i<_nSamples; i++) { samples[i]=(float)(thisSamples[i]*factor); } UNLOCK_SAMPLES(this) msr_pack(msr, &miniSeedRecordHandler, &f, &packedSamples, 1, 0); msr->datasamples=0; delete [] samples; msr_free(&msr); return packedSamples==_nSamples; }
bool GeopsyCore::Signal::writeSac | ( | QDataStream & | s | ) | const |
References GeopsyCore::SignalTemplate< double >::_nSamples, _t0, Acceleration, amplitudeUnit(), GeopsyCore::SACHeader::bools, GeopsyCore::SACHeader::chars, component(), componentLetter(), CONST_LOCK_SAMPLES, countPerUnit(), countPerVolt(), GeopsyCore::DoubleSignal::deltaT(), Displacement, QGpCoreTools::endl(), GeopsyCore::SACHeader::field, GeopsyCore::SACHeader::floats, GeopsyCore::SACHeader::ints, metaData(), name(), GeopsyCore::SignalTemplate< double >::nSamples(), receiver(), GeopsyCore::TimePick::registered(), GeopsyCore::DoubleSignal::restoreType(), GeopsyCore::DoubleSignal::saveType(), GeopsyCore::TimePick::staticId(), t0(), timePick(), timeReference(), QGpCoreTools::tr(), TRACE, UNLOCK_SAMPLES, Velocity, GeopsyCore::DoubleSignal::Waveform, GeopsyCore::SACHeader::write(), QGpCoreTools::Point2D::x(), QGpCoreTools::Point2D::y(), and QGpCoreTools::Point::z().
{ TRACE; const DoubleSignal * sig=saveType(Waveform); static const QString errorMsg(tr("[SAC] Error while writing %1")); SACHeader h; h.floats.field.USER7=receiver().x(); h.floats.field.USER8=receiver().y(); h.floats.field.USER9=receiver().z(); switch (amplitudeUnit()) { case Displacement: h.ints.field.IDEP=6; break; case Velocity: h.ints.field.IDEP=7; break; case Acceleration: h.ints.field.IDEP=8; break; default: h.ints.field.IDEP=5; break; } h.ints.field.NVHDR=6; // SAC version 6 compatible (2002) h.ints.field.IFTYPE=1; // iftype is time series h.bools.field.LEVEN=0xffffffff; // leven is true h.ints.field.NPTS=nSamples(); h.floats.field.DELTA=deltaT(); h.floats.field.SCALE=countPerVolt(); if(name().length() > 8) strncpy(h.chars.field.KSTNM, name().toAscii().data(), 8); else strncpy(h.chars.field.KSTNM, name().toAscii().data(), name().length()); strncpy(h.chars.field.KCMPNM, componentLetter(component()).toAscii().data(), 1); QDateTime td=timeReference(); int secs=(int) floor(t0()); td=td.addSecs(secs); QDate tdd=td.date(); QTime tdt=td.time(); h.ints.field.NZYEAR=tdd.year(); h.ints.field.NZJDAY=QDate(tdd.year(), 1, 1).daysTo(tdd) + 1; h.ints.field.NZHOUR=tdt.hour(); h.ints.field.NZMIN=tdt.minute(); h.ints.field.NZSEC=tdt.second(); double t0=_t0-(double) secs; h.ints.field.NZMSEC=(int) floor(t0 * 1000); t0 -= (double) h.ints.field.NZMSEC * 0.001; h.floats.field.B=t0; // Picks: SAC can store only ten without names // save only pick named SAC_0 to SAC_9 bool hasSacPick=false; const TimePick * tp=static_cast<const TimePick *>(metaData(TimePick::staticId())); for(int i=0;i<10;i++) { QString pn="SAC_"+QString::number(i); if(TimePick::registered(pn) && tp->hasIndex(0, pn)) { h.floats.field.T[i]=timePick(pn); hasSacPick=true; } } if(!hasSacPick) { App::stream() << tr("SAC header can store only 10 unamed time picks.\n" "Only picks named 'SAC_0' to 'SAC_9'") << endl; } if(!h.write(s)) return writeError(sig, errorMsg.arg(tr("header"))); qint64 offset=s.device()->pos(); CONST_LOCK_SAMPLES(double, sigSamples, sig) float val; double conversionFactor=countPerUnit(); for(int i=0; i < _nSamples; i ++) { val=(float) (sigSamples[ i ] * conversionFactor); s << val; } UNLOCK_SAMPLES(sig); if(s.device()->pos()-offset!=_nSamples*(int)sizeof(float)) return writeError(sig, errorMsg.arg(tr("samples"))); restoreType(sig); return true; }
bool GeopsyCore::Signal::writeSeg2 | ( | QFile & | f | ) | const |
References GeopsyCore::SignalTemplate< double >::_nSamples, _t0, CONST_LOCK_SAMPLES, GeopsyCore::DoubleSignal::deltaT(), QGpCoreTools::endl(), maximumAmplitude(), metaData(), GeopsyCore::TimePick::names(), GeopsyCore::SignalTemplate< double >::nSamples(), GeopsyCore::DoubleSignal::restoreType(), GeopsyCore::DoubleSignal::saveType(), GeopsyCore::TimePick::staticId(), str, timePick(), QGpCoreTools::tr(), TRACE, UNLOCK_SAMPLES, GeopsyCore::DoubleSignal::Waveform, QGpCoreTools::Point2D::x(), QGpCoreTools::Point2D::y(), and QGpCoreTools::Point::z().
{ TRACE; const DoubleSignal * sig=saveType(Waveform); char buf[ 32 ]; double factor=32767./maximumAmplitude(); unsigned long pos=f.pos(); unsigned long posEnd; qint16 blocksize=32; qint16 length; int rem4, val; static const QString errorMsg(tr("[SEG2] Error while writing %1")); static const QString errorLengthMsg(errorMsg.arg("%1 (written length %2, instead of %3)")); QString str; *reinterpret_cast<qint16*>(buf)=0x4422; *reinterpret_cast<long*>(buf+4)=nSamples()*4; *reinterpret_cast<long*>(buf+8)=nSamples(); *reinterpret_cast<qint16*>(buf+12)=2; if(f.write(buf, 32)!=32) return writeError(sig, errorMsg.arg("header")); str=QString("DELAY %1\n").arg(_t0, 0, 'g'); length=str.length()+2; if(f.write((const char *)&length, 2)!=2) return writeError(sig, errorLengthMsg.arg("DELAY").arg(length-2)); if(f.write(str.toAscii().data(), length-2)!=length-2) return writeError(sig, errorLengthMsg.arg("DELAY").arg(length-2)); blocksize+=length; str=QString("SAMPLE_INTERVAL %1\n").arg(deltaT(), 0, 'g'); length=str.length() + 2; if(f.write((char*) &length, 2)!=2) return writeError(sig, errorLengthMsg.arg("SAMPLE_INTERVAL").arg(length-2)); if(f.write(str.toAscii().data(), length-2)!=length-2) return writeError(sig, errorLengthMsg.arg("SAMPLE_INTERVAL").arg(length-2)); blocksize+=length; str=QString("DESCALING_FACTOR %1\n").arg(1./factor, 0, 'g'); length=str.length() + 2; if(f.write((char*) & length, 2)!=2) return writeError(sig, errorLengthMsg.arg("DESCALING_FACTOR").arg(length-2)); if(f.write(str.toAscii().data(), length-2)!=length-2) return writeError(sig, errorLengthMsg.arg("DESCALING_FACTOR").arg(length-2)); blocksize+=length; str="STACK 1\n"; length=str.length() + 2; if(f.write((char*) & length, 2)!=2) return writeError(sig, errorLengthMsg.arg("STACK").arg(length-2)); if(f.write(str.toAscii().data(), length-2)!=length-2) return writeError(sig, errorLengthMsg.arg("STACK").arg(length-2)); blocksize+=length; str=QString("SOURCE_LOCATION %1 %2 %3\n") .arg(_source.x(), 0, 'f') .arg(_source.y(), 0, 'f') .arg(_source.z(), 0, 'f'); length=str.length() + 2; if(f.write((char*) & length, 2)!=2) return writeError(sig, errorLengthMsg.arg("SOURCE_LOCATION").arg(length-2)); if(f.write(str.toAscii().data(), length-2)!=length-2) return writeError(sig, errorLengthMsg.arg("SOURCE_LOCATION").arg(length-2)); blocksize+=length; str=QString("RECEIVER_LOCATION %1 %2 %3\n") .arg(_receiver.x(), 0, 'f') .arg(_receiver.y(), 0, 'f') .arg(_receiver.z(), 0, 'f'); length=str.length() + 2; if(f.write((char*) & length, 2)!=2) return writeError(sig, errorLengthMsg.arg("RECEIVER_LOCATION").arg(length-2)); if(f.write(str.toAscii().data(), length-2)!=length-2) return writeError(sig, errorLengthMsg.arg("RECEIVER_LOCATION").arg(length-2)); blocksize+=length; const TimePick * tp=static_cast<const TimePick *>(metaData(TimePick::staticId())); QStringList picks=tp->names(); for(QStringList::iterator it=picks.begin(); it!=picks.end(); it++) { QString pn=*it; if(pn.isEmpty() || pn.contains(" ")) { App::stream() << tr("SEG2 header cannot store arrival times named with complex names (\"%1\").").arg(pn) << endl; } else { double p=timePick(pn); if(p!=0.0) { str=QString("ARRIVAL_TIME %1 %2\n").arg(pn).arg(p, 0, 'g'); length=str.length()+2; if(f.write((char*) &length, 2)!=2) return writeError(sig, errorLengthMsg.arg("ARRIVAL_TIME %3").arg(length-2).arg(pn)); if(f.write(str.toAscii().data(), length-2)!=length-2) return writeError(sig, errorLengthMsg.arg("ARRIVAL_TIME %3").arg(length-2).arg(pn)); blocksize+=length; } } } str=QString("NAME\n%1\n").arg(_name); length=str.length() + 2; if(f.write((const char*) & length, 2)!=2) return writeError(sig, errorLengthMsg.arg("NAME").arg(length-2)); if(f.write(str.toAscii().data(), length-2)!=length-2) return writeError(sig, errorLengthMsg.arg("NAME").arg(length-2)); blocksize+=length; length=-1; if(f.write((const char*) &length, 2)!=2) return writeError(sig, errorMsg.arg("end of signal header (length)")); blocksize+=2; rem4=blocksize % 4; if(rem4>0) { if(f.write(buf, rem4)!=rem4) return writeError(sig, errorMsg.arg("alignment of signal header(%1)").arg(rem4)); blocksize+=rem4; } CONST_LOCK_SAMPLES(double, sigSamples, sig) for(int i=0; i<_nSamples; i++) { val=(int)(sigSamples[i]*factor); if(f.write((const char*) &val, 4)!=4) { return writeError(sig, errorMsg.arg("signal sample(%1)").arg(i)); } } UNLOCK_SAMPLES(sig); posEnd=f.pos(); f.seek(pos + 2); if(f.write((const char*) &blocksize, 2)!=2) return writeError(sig, errorMsg.arg("signal block size")); f.seek(posEnd); restoreType(sig); return true; }
bool GeopsyCore::Signal::writeSegySu | ( | QDataStream & | s, |
int | indexInFile, | ||
bool | su | ||
) | const |
Writes this signal as a SEGY or SU trace with IEEE floating point. For SU export, sets su to true.
References GeopsyCore::SignalTemplate< double >::_nSamples, _t0, CONST_LOCK_SAMPLES, countPerUnit(), GeopsyCore::DoubleSignal::deltaT(), GeopsyCore::SEGYTraceHeader::field, GeopsyCore::SignalTemplate< double >::nSamples(), GeopsyCore::DoubleSignal::restoreType(), GeopsyCore::DoubleSignal::saveType(), GeopsyCore::SEGYTraceHeader::setCoordinateFactor(), GeopsyCore::SEGYTraceHeader::setElevationFactor(), GeopsyCore::SEGYTraceHeader::setNSamples(), GeopsyCore::SEGYTraceHeader::setReceiver(), GeopsyCore::SEGYTraceHeader::setSource(), GeopsyCore::SEGYTraceHeader::setSUT0(), GeopsyCore::SEGYTraceHeader::setT0(), t0(), timeReference(), TRACE, UNLOCK_SAMPLES, GeopsyCore::DoubleSignal::Waveform, and GeopsyCore::SEGYTraceHeader::write().
{ TRACE; const DoubleSignal * sig=saveType(Waveform); SEGYTraceHeader h; h.field.traceNumberInLine=indexInFile+1; h.field.traceNumberInFile=indexInFile+1; h.field.originalRecordNumber=1; h.field.traceNumberInRecord=_numberInFile+1; h.field.traceIndentificationCode=1; h.field.numberSumVertical=1; h.field.numberStackHorizontal=1; h.field.dataUse=1; // Production data if(!h.setNSamples(nSamples())) { return false; } h.field.sampleInterval=(qint16)round(1.e+6*deltaT()); // Calculate scale factor to apply on coordinates and elevations if(!h.setCoordinateFactor(_receiver, _source)) { return false; } if(!h.setElevationFactor(_receiver, _source)) { return false; } h.setReceiver(_receiver); h.setSource(_source); QDateTime td=timeReference(); int secs=(int)floor(t0()); td=td.addSecs(secs); QDate tdd=td.date(); QTime tdt=td.time(); h.field.year=tdd.year(); quint16 year; year=tdd.year(); h.field.day=QDate(year, 1, 1).daysTo(tdd) + 1; h.field.hour=tdt.hour(); h.field.minute=tdt.minute(); h.field.second=tdt.second(); if(su) { if(!h.setSUT0(_t0)) { return false; } } else { if(!h.setT0(_t0)) { return false; } } h.field.timeBase=4; // UTC time base h.field.gainType=1; // Fixed gain h.field.correlated=1; // Not correlated h.write(s); ASSERT(sizeof(float)==4); CONST_LOCK_SAMPLES(double, sigSamples, sig) double conversionFactor=countPerUnit(); for(int i=0; i<_nSamples; i++) { s << (float) (sigSamples[i]*conversionFactor); } UNLOCK_SAMPLES(this) restoreType(sig); return true; }
XMLMember GeopsyCore::Signal::xml_member | ( | XML_MEMBER_ARGS | ) | [virtual] |
Re-implement this function to offer XML restore (children and properties) support to your class.
From tag and map (with contains the attibute value) return a unique identifier under the format of a XMLMember. XMLMember is initialized with 3 types of contructors:
Map of attributes can be inspected in this way (can be achived also in xml_setProperty()):
static const QString tmp("childrenName"); XMLRestoreAttributeIterator it=map.find(tmp); if(it!=map.end()) { // found attribute "childrenName" }
If the map of attributes is not used:
Q_UNUSED(attributes); if(tag=="x1") return XMLMember(0); else if(tag=="y1") return XMLMember(1); else if(tag=="x2") return XMLMember(2); else if(tag=="y2") return XMLMember(3); else return XMLMember(XMLMember::Unknown);
Arithmetic operations + and - apply to XMLMember to avoid confusion of property id numbers between inherited objects. Offset 3 corresponds to the number of properties defined in this object.
if(tag=="anInteger") return XMLMember(0); else if(tag=="aString") return XMLMember(1); else if(tag=="aDouble") return XMLMember(2); return AbstractLine::xml_member(tag, attributes, context)+3;
For the arguments of this function use Macro XML_MEMBER_ARGS.
Reimplemented from QGpCoreTools::XMLClass.
References GeopsyCore::MetaDataMap::add(), GeopsyCore::MetaDataMap::data(), QGpCoreTools::endl(), QGpCoreTools::XMLClassFactory::id(), GeopsyCore::MetaDataFactory::instance(), GeopsyCore::SignalDB::resolveMetaData(), GeopsyCore::MetaData::storeAsXML(), QGpCoreTools::tr(), and QGpCoreTools::XMLClass::xml_tagName().
Referenced by GeopsyCore::XMLSignal::xml_member().
{ Q_UNUSED(context); // First look for standard members if(tag.size()>=2) { switch (tag[0].unicode()) { case 'A': if(tag=="AmplitudeUnit") return XMLMember(11); break; case 'B': if(tag=="ByteIncrement") return XMLMember(15); break; case 'b': // Special tag handled by XMLParser directly, avoid meta data queries if(tag=="binDataFile") return XMLMember(XMLMember::Unknown); break; case 'C': if(tag.size()>=4) { switch (tag[3].unicode()) { case 'c': if(tag=="CheckSum") return XMLMember(16); break; case 'n': if(tag=="CountPerVolt") return XMLMember(9); break; case 'p': if(tag=="Component") return XMLMember(2); break; default: break; } } break; case 'D': if(tag=="DeltaT") return XMLMember(5); break; case 'I': if(tag=="ID") return XMLMember(0); break; case 'N': switch (tag[1].unicode()) { case 'a': if(tag=="Name") return XMLMember(1); break; case 'S': if(tag=="NSamples") return XMLMember(7); break; case 'u': if(tag=="NumberInFile") return XMLMember(8); break; default: break; } break; case 'O': if(tag=="OffsetInFile") return XMLMember(14); break; case 'R': if(tag=="Receiver") return XMLMember(12); break; case 'S': if(tag=="Source") return XMLMember(13); break; case 'T': switch (tag[1].unicode()) { case '0': if(tag=="T0") return XMLMember(3); break; case 'i': if(tag=="TimeReference") return XMLMember(4); break; case 'y': if(tag=="Type") return XMLMember(6); break; default: break; } break; case 'V': if(tag=="VoltPerUnit") return XMLMember(10); break; default: break; } } // Not a standard data name, look for non-standard ones... static QString sharedAtt="sharedId"; XMLRestoreAttributeIterator it=attributes.find(sharedAtt); if(it!=attributes.end()) { // It is a link to shared data MetaData * d=_db->resolveMetaData(it.value().toInt()); if(d) { if(tag==d->xml_tagName()) { _optionalData.add(d); return XMLMember(101); } else { App::stream() << tr("Mismatch resolving shared meta data shared id %1: expecting type %2, found %3.") .arg(it.value().toInt()).arg(tag.toString()).arg(d->xml_tagName()) << endl; } } } else { // Not shared int id=MetaDataFactory::instance()->id(tag.toString()); if(id>-1) { MetaData * d=_optionalData.data(id); if(d->storeAsXML()) { return XMLMember(d); } else { return XMLMember(100); } } else { App::stream() << tr("Unknown MetaData %1").arg(tag.toString()) << endl; } } return XMLMember(XMLMember::Unknown); }
bool GeopsyCore::Signal::xml_setProperty | ( | XML_SETPROPERTY_ARGS | ) | [virtual] |
Re-implement this function to offer XML restore properties support to your class.
From memberID set the corresponding property with value content. The map of attributes is given as a supplementary information (not useful in all cases).
For a general case:
Q_UNUSED(attributes); double val=content.toDouble(); switch (memberID) { case 0: _x1=val; return true; case 1: _y1=val; return true; case 2: _x2=val; return true; case 3: _y2=val; return true; default: return false; }
For classes inheriting other classes (see also xml_member())
switch (memberID) { case 0: _anInteger=content.toString(); return true; case 1: _aString=content.toInt(); return true; case 2: _aDouble=content.toDouble(); return true; default: return AbstractLine::xml_setProperty(memberID-3, map, content);
For the arguments of this function use Macro XML_SETPROPERTY_ARGS.
Reimplemented from QGpCoreTools::XMLClass.
References GeopsyCore::MetaDataMap::data(), GeopsyCore::MetaData::fromString(), QGpCoreTools::Point::fromString(), GeopsyCore::MetaDataFactory::instance(), setAmplitudeUnit(), setByteIncrement(), setComponent(), setCountPerVolt(), setDeltaT(), setId(), setName(), setNSamples(), setNumberInFile(), setOffsetInFile(), setReceiver(), setSource(), setT0(), setTimeReference(), GeopsyCore::DoubleSignal::setType(), setVoltPerUnit(), standardAmplitudeUnit(), standardComponent(), and GeopsyCore::DoubleSignal::type().
Referenced by GeopsyCore::XMLSignal::xml_setProperty().
{ Q_UNUSED(context); switch (memberID) { case 0: setId(content.toInt()); return true; case 1: setName(content.toString()); return true; case 2: setComponent(standardComponent(content.toString())); return true; case 3: setT0(content.toDouble()); return true; case 4: setTimeReference(content.toString()); return true; case 5: setDeltaT(content.toDouble()); return true; case 6: setType(type(content.toString())); return true; case 7: setNSamples(content.toInt()); return true; case 8: setNumberInFile (content.toInt()); return true; case 9: setCountPerVolt (content.toDouble()); return true; case 10: setVoltPerUnit (content.toDouble()); return true; case 11: setAmplitudeUnit(standardAmplitudeUnit(content.toString())); return true; case 12: { Point p; p.fromString(content); setReceiver(p); return true; } case 13: { Point p; p.fromString(content); setSource(p); return true; } case 14: setOffsetInFile (content.toInt()); return true; case 15: setByteIncrement (content.toInt()); return true; case 16: // checksum, ignored, not stored anymore return true; case 100: { // Meta data already exist, tested before... MetaData * d=_optionalData.data(MetaDataFactory::instance()->id(tag.toString())); static const QString tmp("index"); XMLRestoreAttributeIterator it=attributes.find(tmp); if(it!=attributes.end()) { d->fromString(it.value().toString(), content.toString()); } else { d->fromString(0, content.toString()); } } return true; case 101: return true; default: return false; } }
virtual const QString& GeopsyCore::Signal::xml_tagName | ( | ) | const [inline, virtual] |
Implements QGpCoreTools::XMLClass.
{return xmlSignalTag;}
void GeopsyCore::Signal::xml_writeChildren | ( | XML_WRITECHILDREN_ARGS | ) | const [virtual] |
Reimplemented from QGpCoreTools::XMLClass.
References QGpCoreTools::SortedVector< Key, T >::at(), GeopsyCore::MetaDataMap::count(), GeopsyCore::MetaData::isStored(), QGpCoreTools::SharedObject::referenceCount(), GeopsyCore::MetaData::storeAsXML(), GeopsyCore::MetaDataMap::vector(), QGpCoreTools::XMLClass::xml_attributes(), and QGpCoreTools::XMLClass::xml_save().
{ Q_UNUSED(context); // Optional meta data (only if not shared) int n=_optionalData.count(); const SortedVector<int, MetaData>& v=_optionalData.vector(); for(int i=0; i<n; i++) { const MetaData * d=v.at(i); if(d->isStored() && d->storeAsXML() && d->referenceCount()==1) { XMLSaveAttributes att; d->xml_attributes(att, context); d->xml_save(s, context, att); } } }
void GeopsyCore::Signal::xml_writeProperties | ( | XML_WRITEPROPERTIES_ARGS | ) | const [virtual] |
Reimplemented from QGpCoreTools::XMLClass.
References amplitudeUnitStandardName(), QGpCoreTools::SortedVector< Key, T >::at(), byteIncrement(), componentStandardName(), GeopsyCore::MetaDataMap::count(), countPerVolt(), GeopsyCore::DoubleSignal::deltaT(), GeopsyCore::MetaData::isStored(), name(), GeopsyCore::SignalTemplate< double >::nSamples(), numberInFile(), offsetInFile(), receiver(), QGpCoreTools::SharedObject::referenceCount(), source(), GeopsyCore::MetaData::storeAsXML(), t0(), timeReferenceString(), GeopsyCore::DoubleSignal::type(), GeopsyCore::DoubleSignal::typeString(), GeopsyCore::MetaDataMap::vector(), voltPerUnit(), GeopsyCore::MetaData::writeProperties(), QGpCoreTools::XMLClass::writeProperty(), QGpCoreTools::XMLClass::xml_attributes(), and GeopsyCore::MetaData::xml_writeLink().
Referenced by GeopsyCore::XMLSignal::xml_writeProperties().
{ Q_UNUSED(context); writeProperty(s, "ID", id()); writeProperty(s, "Name", name()); writeProperty(s, "Component", componentStandardName()); writeProperty(s, "T0", t0()); writeProperty(s, "TimeReference", timeReferenceString()); writeProperty(s, "DeltaT", deltaT()); writeProperty(s, "Type", typeString(type())); writeProperty(s, "NSamples", nSamples()); writeProperty(s, "CountPerVolt", countPerVolt()); writeProperty(s, "VoltPerUnit", voltPerUnit()); writeProperty(s, "AmplitudeUnit", amplitudeUnitStandardName()); writeProperty(s, "NumberInFile", numberInFile()); writeProperty(s, "Receiver", receiver().toString(15)); writeProperty(s, "Source", source().toString(15)); writeProperty(s, "OffsetInFile", offsetInFile()); writeProperty(s, "ByteIncrement", byteIncrement()); // Optional data int n=_optionalData.count(); const SortedVector<int, MetaData>& v=_optionalData.vector(); for(int i=0; i<n; i++) { const MetaData * d=v.at(i); if(d->isStored()) { if(d->referenceCount()>1) { d->xml_writeLink(s); } else if(!d->storeAsXML()) { XMLSaveAttributes att; d->xml_attributes(att, context); d->writeProperties(s, att); } } } }
QMutex GeopsyCore::Signal::_amplitudeMutex [mutable, protected] |
Referenced by averageAmplitude(), and maximumAmplitude().
double GeopsyCore::Signal::_averageAmplitude [mutable, protected] |
Referenced by averageAmplitude().
uint GeopsyCore::Signal::_isHeaderModified [protected] |
Referenced by pickCoppens(), pickMinMax(), setTemporary(), and Signal().
uint GeopsyCore::Signal::_isReadOnlySamples [protected] |
Referenced by setTemporary(), Signal(), and warnReadOnlySamples().
double GeopsyCore::Signal::_maxAmplitude [mutable, protected] |
Referenced by maximumAmplitude().
double GeopsyCore::Signal::_t0 [protected] |
SparseTimeRange GeopsyCore::Signal::_timeRange [protected] |
Referenced by copyBasicProperties(), setDeltaT(), setNSamples(), setT0(), and setTimeRange().
uint GeopsyCore::Signal::_unused [protected] |
const QString GeopsyCore::Signal::xmlSignalTag = "Signal" [static] |
